Reference Manual
12G-SDI Frame Synchronizer
This Manual Supports Device Revisions:
PVD 5400 Firmware Revision
LynxCentraal
APPolo Server
Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form
or by any means, electronic or mechanical for any purpose, without express written permission of LYNX Technik AG.
LYNX Technik AG may have patents, patent applications, trademarks, copyrights or other intellectual property rights covering the subject
matter in this document. Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to
patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
PVD 5400 O
Revision 1.1 – May 2025
© 2025 LYNX Technik AG all rights reserved
1249
1.8.0
8.22.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LYNXTechnik 5000 Series
Summary of Contents for LYNXTechnik 5000 Series
- Page 1 Reference Manual PVD 5400 O 12G-SDI Frame Synchronizer Revision 1.1 – May 2025 This Manual Supports Device Revisions: PVD 5400 Firmware Revision 1249 LynxCentraal 1.8.0 APPolo Server 8.22.0 Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical for any purpose, without express written permission of LYNX Technik AG.
-
Page 2: Table Of Contents
Programmable Output Delay ................11 Audio Processing ..................12 Module Layout .................... 12 Connections ................. 13 Video ......................13 Optional Fiber (PVD 5400 O) ............... 13 Installation ................... 13 Settings and Control ..............15 © 2025 LYNXTechnik ® Page 2 of 33... - Page 3 Output Combo-Box..................27 Output Timing Node ................... 28 User Presets Tab ..................28 Save a Preset ...................... 28 Load a Saved Preset ..................29 Params Tab ....................30 Info Tab ...................... 31 © 2025 LYNXTechnik ® Page 3 of 33...
- Page 4 Events Tab ....................32 Log in GUI Function .................... 32 Alarm Activation ....................32 SNMP Support ....................32 Service ..................33 Parts List ....................33 Technical Support ..................33 Contact Information ..............33 © 2025 LYNXTechnik ® Page 4 of 33...
-
Page 5: Warranty
TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. LYNX TECHNIK AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER LYNX TECHNIK OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. © 2025 LYNXTechnik ® Page 5 of 33... -
Page 6: Regulatory Information
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. © 2025 LYNXTechnik ® Page 6 of 33... -
Page 7: Getting Started
Connect the strap to any solid grounding source such as any exposed metal on the rack chassis or any other unpainted metal surface. Caution Periodically check the resistance value of the antistatic strap. The measurement should be between 1 and 10 Megohms. © 2025 LYNXTechnik ® Page 7 of 33... -
Page 8: Product Description
The PVD 5400-O is a robust, scalable, and reliable tool for managing high-bandwidth video workflows, providing unparalleled flexibility and performance for modern broadcast applications. © 2025 LYNXTechnik ® Page 8 of 33... -
Page 9: Functional Diagram
For input signals mismatched with the connected reference frame rate, the synchronizer will show this as an asynchronous source (indicated by a yellow status indication in the GUI) and any output signal derived from this “async” source can show video disturbances. © 2025 LYNXTechnik ® Page 9 of 33... -
Page 10: Input Reference Signal
"Flywheel" functionality, which intelligently compensates for missing synchronization pulses in the input signal. By accurately predicting the timing of these missing pulses, the module seamlessly restores them, ensuring a stable and uninterrupted output. © 2025 LYNXTechnik ® Page 10 of 33... -
Page 11: Video Processing
This adjustment will delay the SDI video output, including the embedded audio, relative to the connected reference by the delay setting specified. (+ fixed delay) © 2025 LYNXTechnik ® Page 11 of 33... -
Page 12: Audio Processing
PCM Audio using the sample rate converters will be free from any audio interference (“pops and clicks”) when frames are dropped or repeated by the frame synchronizer. Module Layout Module Rear Termination Panels Module Front © 2025 LYNXTechnik ® Page 12 of 33... -
Page 13: Connections
Please ensure that the surfaces of fiber cables and LC connectors are always protected against scratching and dust when no fiber cables are connected. Dust and/or scratches will lead to high attenuation of the optical power transmitted. © 2025 LYNXTechnik ® Page 13 of 33... -
Page 14: Installation
The use of the optional control system is mandatory for the control and setup of this module. If you do not have the control system, then please contact your LYNX representative for details on how to upgrade your installation with the LYNX control system. © 2025 LYNXTechnik ® Page 14 of 33... -
Page 15: Settings And Control
This LED indicates the status of the Reference signal LED Color Indication Green REF present and ok REF missing, but not required (self-lock on SDI input) Yellow REF ok, but not matching a fixed frequency setting (odd/even) REF missing © 2025 LYNXTechnik ® Page 15 of 33... -
Page 16: Sdi Status
The LED on the lower edge of the module indicates the presence of power supply voltages (main power supply and redundant power supply), and the locate option. LED 1 Indication Green Power from Main PSU is ok • Fan Failure Red (blinking) • Over Temperature • Wrong backplane © 2025 LYNXTechnik ® Page 16 of 33... -
Page 17: Control System Gui
There are several “Tabs” along the top of the screen which split up the module settings into several logical displays. The various GUI screens and primary functions are described below. © 2025 LYNXTechnik ® Page 17 of 33... -
Page 18: Main Tab
Functions of the module can be selected by clicking on the tabs on top of the screen or by clicking directly into the respective box (Sync and Video Proc). General Video Settings The first area covers some General setup parameters for the external reference operation. © 2025 LYNXTechnik ® Page 18 of 33... -
Page 19: External Reference Source
Also, this value will not be restored to 50Hz following a “Restore Factory Defaults” operation, the stored setting will be preserved. The “Current Frequency” area shows the frequency the frame synchronizer is running in currently (useful if the follow last reference selection is made) © 2025 LYNXTechnik ® Page 19 of 33... - Page 20 If activated the embedded audio-to-video delay at the output is always minimal. This should be used for clock-synchronized signals only, because the audio is automatically delayed compensating for the AV delay, which can cause audio disturbances with asynchronous sources. © 2025 LYNXTechnik ® Page 20 of 33...
-
Page 21: Input Combo-Box
3G Level B input signal. The available options are Stream A and Stream B, corresponding to the two multiplexed audio streams in a 3G Level B signal. © 2025 LYNXTechnik ® Page 21 of 33... -
Page 22: Input Y & C Vpid Display
01") define the signal's characteristics, such as resolution, frame rate, and format. • Input C-VPID: Displays the VPID values for the chroma (C) component of the input signal, which should align with the Y component but is independently identified. © 2025 LYNXTechnik ® Page 22 of 33... -
Page 23: Frame Sync Combo-Box
Clip to Narrow If activated all Luminance (Y) values below 64 and above 940, and all Chrominance (Cr, CB) values below 64 and above 864 will be clipped. © 2025 LYNXTechnik ® Page 23 of 33... -
Page 24: H Flip
Yellow • Cyan • Green • Magenta • • Blue • Black • Colorbar • White/black • Colorbar over red • EQ/PLL path. • EQ path. • PLL path. • Grey 15% © 2025 LYNXTechnik ® Page 24 of 33... -
Page 25: Standard
DCI mode, which supports only 1080p (2K) and 2160p (4K) resolutions. To resolve the issue, ensure the test pattern or video standard is adjusted i.e 1080p for 2K and 2160p for 4K to match one of these DCI-supported formats before proceeding. © 2025 LYNXTechnik ® Page 25 of 33... -
Page 26: Video Adjustment
The enable checkbox activates adjustment, ensuring the feature is applied only when needed for precise output customization. Note: Aperture correction OFF is the same as a Zero setting in the adjustment range © 2025 LYNXTechnik ® Page 26 of 33... -
Page 27: Output Combo-Box
(Stream A or Stream B) to embed in the Level B format. The VPID section provides the option to either automatically generate VPID values or manually define them, ensuring compliance with specific workflow requirements. © 2025 LYNXTechnik ® Page 27 of 33... -
Page 28: Output Timing Node
3. Using the radio button to select the preset location you wish to save the settings to and type in a name. 4. Click “Save” and the all the current module settings are stored in the named preset. © 2025 LYNXTechnik ® Page 28 of 33... -
Page 29: Load A Saved Preset
It is also possible to switch to the preset in which case the device becomes “read-only” with the selected preset configuration © 2025 LYNXTechnik ® Page 29 of 33... -
Page 30: Params Tab
Additional options include exporting the parameter configurations to HTML or XML formats for backup or further analysis, making this interface essential for monitoring and managing device operations effectively. © 2025 LYNXTechnik ® Page 30 of 33... -
Page 31: Info Tab
• Audio Pinning: This sub-tab (if populated) would detail the specific channel mapping for audio streams; however, in this case, no audio pinning data is available. © 2025 LYNXTechnik ® Page 31 of 33... - Page 32 Internal LYNX error logging and external SNMP traps can be configured independently. Note: A simulated event is part of the GUI simulator and allows us to force a particular error condition for testing and demonstration purposes. © 2025 LYNXTechnik ® Page 32 of 33...
-
Page 33: Parts List
E-Mail info@lynx-technik.com LYNX Technik manufactures a complete range of high-quality modular products for broadcast and Professional markets. Please contact your local representative or visit our web site for more product information. © 2025 LYNXTechnik ® Page 33 of 33...
