Samsung Lennox M1WD Instructions Manual

M1WD CASSETTE | One-Way
Cassette Indoor Units | One-Way |
R E S I D E N T I A L / C O M M E R C I A L
P R O D U C T S P E C I F I C AT I O N S ( E H B )
M OD EL NU MBER ID EN T IF IC AT ION
Series Type
M = Mini-Split
1W = Cassette Indoor Units | One-Way
Major Design Sequence
R-32 | 60 Hz
M1WD One-Way Cassette Unit (shown with
Optional Wireless Remote Controller)
M 1W D 012 S 6 - 1 P
Unit Type
D = 4th Generation
Nominal Cooling Capacity
009 = 0.75 tons
012 = 1.0 tons
018 = 1.5 tons
M I N I - S P L I T S Y S T E M S
0.75 to 1.5 Tons
Voltage
P = 208/230V-1 phase-60Hz
Minor Design Sequence
1 = 1st Revision
Refrigerant Type
6 = R-32
Zone Type
S = Single
Form Number 211082 | March 2025
Supersedes all previous versions
