ZooZ ZAC93 LR User Manual

800LR Z-WAVE GPIO MODULE
Z-Wave Plus Static Controller to easily
Ÿ
add Z-Wave communication to your
smart home ecosystem
Latest S2 security protocol for a truly
Ÿ
private network
800 Series Long Range Z-Wave for fast,
Ÿ
low-power direct communication
Extended range up to a mile in open
Ÿ
space when using Long Range
Designed for Raspberry Pi and Home
Ÿ
Assistant Yellow hardware
Model Number: ZAC93 LR
Ÿ
Z-Wave Frequency: 908.42 MHz
Ÿ
Power: 3.3 VDC
Ÿ
Operating Temperature: 32-104° F
Ÿ
Operating Humidity: Up to 85%
Ÿ
Installation and Use: Indoor only
Ÿ
Dimensions:
Ÿ
Use this 800 Series Z-Wave Plus GPIO
Module as a wireless radio for your host
controller, such as Raspberry Pi. Follow
the detailed instructions in the link
below to connect the module. Please
proceed with caution when installing the
device.
Once the controller is set up and
connected to your home automation
so ware, you can enjoy a fully secure,
private Z-Wave Plus mesh network. If the
so ware supports Z-Wave Long Range,
enable direct communication between
your devices and the controller for
supreme range up to 1 mile and a larger
network size up to 4000 nodes.
Questions? ask@getzooz.com
GPIO MODULE AS SECONDARY
CONTROLLER
You can use the GPIO module as a
secondary controller to your current Z-
Wave system if it accepts additional
controllers.
To enroll the module in your current
system, send the inclusion command
and put the module into learning mode,
using the SerialAPI mode in the interface.
The GPIO Module can only be reset by
the host so ware while it's in SerialAPI
mode. The device is reset once an
appropriate command from the host
so ware is sent to reset the Z-Wave
network.
There is no way to manually reset the
module without a connection to the
host so ware.
www.getzooz.com/register
USER MANUAL
zooz
smart move
ZAC93 LR
www.getzooz.com
FEATURES
SPECIFICATIONS
1.1" x 1.1"
SET-UP
Scan the code with your
phone's camera and click
on the link to access
detailed installation
instructions for the GPIO
module.
FACTORY RESET
FCC ID: ZAZAV-101222-ZAC93
Scan to register your
product for extended
warranty, priority
customer service, and
more perks.
