- Page 1 Amphenol Antenna Solutions APM50-H1 MOUNTING KIT INSTALLATION INSTRUCTIONS REV. 3.0 | 2023.09 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions...
-
Page 2: Table Of Contents
6. Installation Without U-shaped Connecting Plate ....................... 4 7. Installation Without Downtilt kit ..........................4 8. Installation With Downtilt Kit ............................5 9. Antenna Mechanical Downtilt Range ........................... 7 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions... -
Page 3: Applications
4. INSTALLATION TOOLS Inclinometer 13mm combination wrench（2pcs） Torque wrench 17mm combination wrench（2pcs） 19mm combination wrench（2pcs） MAXIMUM TORQUE 20 Nm 40 Nm 75 Nm 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions... -
Page 4: Brackets
The same installation method applies to both upper and lower clamps. Install and tighten the nuts. c. Check and tighten all the nuts when the installation is complete. 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions... -
Page 5: Installation With Downtilt Kit
Tighten all the nuts before lifting the antenna onto the tower. Ensure the bracket is fully folded. The same installation method applies to both upper and lower brackets. Install and tighten the nuts. 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions... - Page 6 Example of a scale plate (8 Scale plate ° Method 2：Use an inclinometer. Method 2 is used to precisely adjust the mechanical tilt. Tighten the upper and lower bracket. 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions...
-
Page 7: Antenna Mechanical Downtilt Range
L ≥ 2600 2200 ≤ L < 2600 0-10 1800 ≤ L < 2200 0-12 1000 ≤ L < 1800 0-16 600 ≤ L < 1000 0-20 L < 600 0-30 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions... - Page 8 EMEA & LATAM Conover & Meriden Shanghai Amboise & Lannion +1 (779) 970-1605 +86 (21) 3773 8888 Technical Support Technical Support Technical Support support@amphenol-antennas.com apac.bsa.support@amphenol-antennas.com techsupport@amphenol-antennas.com 10000022033 | Revision 3.0 | SEPT 2023 | Amphenol Antenna Solutions For more information, visit www.rfstechnologies.com...
