- Page 1 APM40-6 MOUNTING KIT INSTALLATION INSTRUCTIONS REV. 9 | 2024.04 10000001078| Revision 9 | APR 2024 |...
-
Page 2: Table Of Contents
INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit SUMMARY 1. Application ..................................3 2. Features ...................................3 3. Mechanical Specifications .............................4 4. Tools required for installation ............................4 5. Item numbers for the Mount Kit Hardware ........................4 6. Assembly of components to antenna .........................5 7. -
Page 3: Application
Mounting Instructions for APM40-6 Kit 1. APPLICATION The APM40-6/6C Mounting Kit is a mounting hardware option to be used for Base Station Antennas with 1.3m or 0.5m (Only for APM40-6) in length (See Figure 10), which uses mounting interface brackets as shown below. -
Page 4: Mechanical Specifications
INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit 抱杆直径：50-120 毫米 Mechanical downtilt: 0~10° for 1.3m antennas. 0~20° for 0.5m antennas (Only for APM40-6) 机械下倾角：1.3 米天线的下倾角调整范围为 0~10°；0.5 米天线的下倾角调整范围为 0~20°(只适用于 APM40-6) 3. MECHANICAL SPECIFICATIONS Weight of Kit (kg) 安装件重量... -
Page 5: Assembly Of Components To Antenna
INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit FLAT WASHER M12N HOT GALVA STEEL SPRING LOCK WASHER W12 HOT GALVA STEEL HEX. NUT M12 HOT GALVA STEEL M8X25mm LARGE CARRIAGE BOLT STL GAL HM8x25 Hot dip Galva ISO4017 class 4.8... - Page 6 INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit Figure 6a: Detailed left view for top mounting kits 图 6a：该组装配用于天线顶端固定。 Figure 6b: Detailed left view for bottom mounting kits 图 6b：该组装配用于天线底端固定。 10000001078| Revision 9 | APR 2024 |...
-
Page 7: Adjusting The Tilt With Short Beam Assembly
调整机械倾角时，拧松上下摇臂的螺栓和天线底部支架的螺栓（如图中箭头所示），调节上下摇臂之间的夹角直至得 到所需倾角位置，并对准倾角指示器的倾角刻度，最后，拧紧螺母固定。（见图 9 、 10 、 11 ） Figure 12 : 0~10° for 1.3m antennas Figure 13 : 0~20° for 0.5m antennas (Only for APM40-6) 图 12： 1.3 米天线机械下倾 0~10°标记线 图 13：0.5 米天线机械下倾 0~20°标记线(只适用于 APM40-6) 10000001078| Revision 9 | APR 2024 |... - Page 8 INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit 转动来调整倾角 Figure 9 : Adjusting Tilt Figure 11 : 10º Tilt Figure 10 : 0º Tilt 图 9：调整倾角 图 11： 倾角 10º时 图 10：倾角 0º 时 10000001078| Revision 9 | APR 2024 |...
-
Page 9: Tightening Torque Values
INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit 8. TIGHTENING TORQUE VALUES Unless otherwise stated, the following general tightening torque values shall be used for metric hexagon bolts and screws, coarse pitch threads, property class 4.6 or over. MAKE SURE THAT ALL BOLTS ARE FASTENED BY THE FOLLOWING TORQUE DURING SITE OPERATION. - Page 10 INSTALLATION INSTRUCTIONS Mounting Instructions for APM40-6 Kit APAC EMEA & LATAM Conover & Meriden Shanghai Amboise & Lannion +1 (779) 970-1605 +86 21 3773 8888 Technical Support Technical Support Technical Support support@amphenol-antennas.com APAC.BSA.Support@amphenol-antennas.com techsupport@amphenol-antennas.com For more information, visit www.amphenol-antennas.com...
