- Page 1 User manual RAX1801 Smart Wi-Fi Router Tech Support :Support@hnknet.com 17.P6.2G3019S01...
-
Page 4: Connect The Router
3. Turn on the modem, and then wait about 2 minutes for it to restart. 4. Connect the power adapter to the router. 5. Verify the power LED on the top panel is solid on (green) . 6. Connect your computer or smartphone to the wifi named HNK-RAX1801 or HNK-RAX1801-5Ghz. USB LED... -
Page 5: Wizard Page
4.Wizard Page 4.2.2 PPPoE Settings 4.1 Wizard Page Browser Type 192.168.0.1 , automatically jump to the configuration wizard page NO password in default Figure 4-3 Figure 4-1 4.2 WAN Connection Settings There are several connection types to choose: Static IP, DHCP and PPPoE. If you are unsure of your connection method, please contact your Internet Service Provider. - Page 6 4.2.3 Static IP Settings 4.3 Wireless SSID and Password Settings After configuring the static IP access method, please click “Next” to complete the wireless SSID configuration and wireless password settings. Figure 4-5 Figure 4-7 4.4 Admin Password Settings After configuring the wifi, click “Next” to set the user (Admin) password, and then click “Next”...
- Page 7 6.Home Page Home page information is displayed. Figure 4-9 5.Web Management Landing Page 5.1 Management Page Login After completing the configuration wizard, please enter 192.168.0.1 in the browser to Figure 6-0 log in to the router management page. Admin Password The Device admin Password you set on Wizard Page. 6.1 Internet Information Display Page Internet connection status and connection information.
- Page 8 6.3 Connected Clients Information Display Page 6.2 WiFi Information Display Page Connected Clients information display page: It shows Connected Clients information. 6.2.1 Router Mode Home>>RAX1801 Display Extender IPv4 mac address and wireless SSID. Figure 6-4 Figure 6-2 6.2.2 Repeater Mode Display the Extender IPv4 mac address and the uplink router’s wireless SSID.
-
Page 9: Function Configuration
7.Function Configuration Complete 2.4G advanced configuration, such as channel, security mode, 802.11 mode. 7.1 WIFI Setting Use this section to configure the wireless settings for your Router. Please note that settings made in this section may also need to be synchronized on your Wireless Client. Figure 7-3 Figure 7-1 Complete 5G advanced configuration, such as channel, security mode, 802.11... - Page 10 7.1.2 Smart Connect 7.1.3 Guest Zone After the smart connection is closed, the extender 2.4G WIFI and the 5G WIFI can This feature lets you enable and configure a Wi-Fi Guest Zone. It allows you to create be searched on the terminal wireless device respectively, and there are two wireless bands a separate network for your guests to secure the main network.
- Page 11 Advanced settings. Figure 7-9 7.2.2 IPV6 Settings All of your IPv6 Internet and network connection details are displayed on this page. Figure 7-12 Click on Advanced Setting, reset your Host Name (e.g. RAX1801), then click on Save. Figure 7-10 Figure 7-13...
- Page 12 7.3 Network Function Configuration 7.3.3 Network Advanced Settings Use this section to configure the network settings for your devices. You can enter a Set LAN advanced settings, UPnP function. name for your device in the management link field and use the link to access web UI in a web browser.
-
Page 13: Features Setting
Select the router 2.4G or 5G WIFI SSID and enter the signal extension password. Figure 7-20 Figure 7-22 Click the scan function after entering the page to scan the uplink router wireless. 8.Features Setting 8.1 QOS Click on Home >> Connected Clients. Connected clients can be assigned Internet access priority. - Page 14 8.2.1 Website Filter After the above setting, click on Features >> QoS Engine. The website filter feature allows you to set rules that you can restrict access to a specified web address (URL) or block specified keywords in the URL. You can use Website Filter to restrict access to potentially harmful and inappropriate websites.
- Page 15 Create a new rule. 8.2.4 Remote Management Open Firewall Status>>Save>>IPv4 Rules>> Add Rule HTTP Remote Management Figure 8-10 Figure 8-7 8.2.5 WAN Ping 8.2.3 IPv6 Rules The IPv6 will also be supported by your router's built-in firewall. Some applications or clients may require special adjustments for better performance or extra protection. Figure 8-11 Figure 8-8 Create a new rule.
- Page 16 8.3.1 Port Forwarding Your router helps to share a single IP address assigned by your ISP among several clients in your home. Port forwarding allows traffic requests from a specified application to be directed to a specified client inside. Figure 8-16 8.3.3 Virtual Server Your router helps to share a single IP address assigned by your Internet service Figure 8-13...
-
Page 17: Management Page
9. Management Page 9.1 Time and Schedule 9.1.1 Time Your router's internal clock is used for data logging and schedules for features. The date and time can be synchronized with a public time server on the Internet, or set manually. Figure 8-19 8.4 DDNS Dynamic Domain Name Service(DDNS) allows your router to associate an easy-to-re-... - Page 18 Figure 9-3 9.1.3 Led Time Your router's internal clock is used for data logging and schedules for features. The Figure 9-5 date and time can be synchronized with a public time server on the Internet, or set 9.3 Admin Page Settings manually.
- Page 19 9.4 System Page Setup Figure 9-9 Figure 9-7 9.4.1 Save Settings to Local Hard Drive Export the configuration file to the local PC for saving, so that you can quickly After modifying the administrator password, the browser will jump to the login page. restore the configuration information.
- Page 20 9.4.2 Load Settings from Local Hard Drive 9.5 Upgrade Page Settings Import the configuration file to the Router to quickly configure the router or restore configuration information. Figure 9-14 Figure 9-11 9.4.3 Restore to Factory Default Settings 9.5.1 Firmware Information Display Clear all router configuration and restore the router settings to factory default.
- Page 21 10.Hardware 9.5.2 Online Firmware Upgrade Settings This page will display your current firmware version. Click on the ‘Check for New 10.1 LED Indicator Firmware’ button for detecting the latest firmware version. If have, you can upgrade your The power light is steady green: The device is on. firmware to the latest version.
- Page 22 11. Manage the Router via the HNK Router App Method 1: Log in to the App Store or Google Store, search for "HNK Router", download and install the APP. Method 2: Scan the QR code below to download and install the APP.
- Page 24 24hour Online After-Sales Service Scan QR Code To Visit https://hnk.afterservice.vip HUIZHOU MTN WEIYE TECHNOLOGY DEVELOPMENT CO.,LTD. Address: NO.2 Huitai Road,Huinan High-tech Industrial Park,Huiao Avenue,Huizhou City,Guangdong Province,China Tech Support :Support@hnknet.com Copyright©2021SHENZHEN ZK TECHNOLOGY CO., LTD. ALL right reserved. The content of this document maybe updated from time to time...
