- Page 1 INOGENI U-BRIDGE 3 WP User guide Version 1.0 April 30, 2025...
-
Page 2: Table Of Contents
INOGENI Maestro application ............................... 7 Mechanical specification ............................... 8 PC HOST module ................................8 DEVICE wallplate ................................9 INO – MOUNT ................................10 Power supply .................................. 11 Troubleshooting section ..............................12 Support....................................13 Certifications ..................................13 – U-BRIDGE 3 WP User Guide... -
Page 3: Introduction
INTRODUCTION The U-BRIDGE 3 WP is a USB 3.2 Gen 1 extension over CAT6A that can extend a 5Gbps signal between a host and devices. This is a two-boxes solution, which are called PCHOST and DEVICE modules. The DEVICE module is a wall plate that can be mounted to the wall. -
Page 4: Device Interfaces
Optional +24VDC power input. We recommend to power up the whole system from the PC HOST module for a clean installation. HDBaseT link. DEVICE Front led. USB-C device connection. USB-A device connection. RS232 connection. – U-BRIDGE 3 WP User Guide... -
Page 5: Leds Behavior
HDBaseT connection detected. Here is the behavior on the front LED of the wallplate: FRONT LED No power or no HDBaseT link. SOLID System powered with USB 3.0 connection. BLINK System powered with USB 2.0 connection. – U-BRIDGE 3 WP User Guide... -
Page 6: Specifications
SPECIFICATIONS Here is the complete specification. Main feature The U-BRIDGE 3 WP USB 3.2 Gen 1 extender enables superspeed USB 3.0 connection of up to Description 100m/330ft. over a single CAT6A Link Technology HDBaseT-USB3 Range Direct connect up to 100m (330ft) over CAT6A U/FTP... -
Page 7: Serial Connection
FCC, CE, UKCA, CB, UL, TUV, EMC TAA-Compliant SERIAL CONNECTION Here is the serial connection of the U-BRIDGE 3 WP. A serial port from a DUT can be extended when using our device. This is the pinout of the serial connection: PC HOST module... -
Page 8: Inogeni Maestro Application
INOGENI MAESTRO APPLICATION The support for U-BRIDGE 3 WP under INOGENI Maestro application is still under development. We will have the support inside the next software version. – U-BRIDGE 3 WP User Guide... -
Page 9: Mechanical Specification
MECHANICAL SPECIFICATION You can find the mechanical specification of the device. All dimensions are in mm [in]. PC HOST MODULE Figure 1: PC HOST module dimensions – U-BRIDGE 3 WP User Guide... -
Page 10: Device Wallplate
DEVICE WALLPLATE 24.8 30.60 4 .0 3. 0 69.0 27.6 23.7 24.8 38.4 6.36 46.2 Figure 2: DEVICE module dimensions – U-BRIDGE 3 WP User Guide... -
Page 11: Ino - Mount
INO – MOUNT Figure 3: Bracket dimensions for PC host module – U-BRIDGE 3 WP User Guide... -
Page 12: Power Supply
POWER SUPPLY Figure 4: Power supply bracket dimensions – U-BRIDGE 3 WP User Guide... -
Page 13: Troubleshooting Section
USB 3.0 devices are detected in USB2.0 mode only on my computer. to see if this resolves the issue. I cannot extend USB-C video from The device does not support USB-C DisplayPort Alternate Mode. laptop to my USB-C monitor – U-BRIDGE 3 WP User Guide... -
Page 14: Support
© Copyright 2025 by INOGENI INC. All Rights Reserved. INOGENI name and logo are trademarks or registered trademarks of INOGENI. Use of this product is subject to the terms and conditions of the license and limited warranty in effect at the time of purchase. Product specifications can change without notice.
