- Page 1 INOGENI U-BRIDGE 3 User guide Version 1.0 October 11, 2024...
-
Page 2: Table Of Contents
INOGENI Maestro application..............................7 Mechanical specification ................................8 PCHOST module ..................................8 DEVICE module ..................................9 INO – CLIP ..................................... 10 Power supply ..................................11 Troubleshooting section ................................12 Support ....................................... 13 Certifications ....................................13 – U-BRIDGE 3 User Guide – Version 1.0... -
Page 3: Introduction
INTRODUCTION The U-BRIDGE 3 is a USB 3.2 Gen 1 extension over CAT6A that can extend a 5Gbps signal between a host and devices. This is a two-boxes solution, which are called PCHOST and DEVICE modules. CONNECTIVITY DIAGRAM Here is a simple U-BRIDGE 3 connectivity diagram. You can plug the power supply to any module to power up the whole system. -
Page 4: Device Interfaces
+24VDC power input. If power supply is connected here, the DEVICE will be powered locally. HDBaseT link. RS232 connection. DEVICE USB-C device connection. USB-A device connection. USB-A device connection. USB-mini management connection. – U-BRIDGE 3 User Guide – Version 1.0... -
Page 5: Leds Behavior
Here are the LEDs behavior on the HDBaseT link connection: GREEN LED No power. SOLID System powered with USB connection detected. BLINK System powered with no USB connection detected. ORANGE LED No HDBaseT connection detected. SOLID HDBaseT connection detected. – U-BRIDGE 3 User Guide – Version 1.0... -
Page 6: Specifications
SPECIFICATIONS Here is the complete specification. Main feature The U-BRIDGE 3 USB 3.2 Gen 1 extender enables superspeed USB 3.0 connection of up to 100m/330ft. Description over a single CAT6A Range Direct connect up to 100m (330ft) over CAT6A U/FTP USB 3.2 Gen1 / USB 3.1 Gen1 / USB 3.0: up to 5 Gbps... -
Page 7: Serial Connection
Warranty 5 years SERIAL CONNECTION Here is the serial connection of the U-BRIDGE 3. A serial port from a DUT can be extended when using our device. This is the pinout of the serial connection: 1 2 3 4 Pin 1: Receive... -
Page 8: Inogeni Maestro Application
USB-C connection on PCHOST module. You can also use the USB-mini connector to upgrade the modules. This is a preview of the upcoming Maestro application. More detailed configurations will be added to an updated version of the user guide. – U-BRIDGE 3 User Guide – Version 1.0... -
Page 9: Mechanical Specification
MECHANICAL SPECIFICATION You can find the mechanical specification of the device. All dimensions are in mm [in]. PCHOST MODULE Figure 1: PC HOST module dimensions – U-BRIDGE 3 User Guide – Version 1.0... -
Page 10: Device Module
DEVICE MODULE Figure 2: DEVICE module dimensions – U-BRIDGE 3 User Guide – Version 1.0... -
Page 11: Ino - Clip
INO – CLIP Figure 3: Bracket dimensions – U-BRIDGE 3 User Guide – Version 1.0... -
Page 12: Power Supply
POWER SUPPLY Figure 4: Power supply bracket dimensions – U-BRIDGE 3 User Guide – Version 1.0... -
Page 13: Troubleshooting Section
USB cables are too long or not working properly. Too much power drawn on USB ports, the maximum current consumption is 1.8A USB 3.0 ports are shutting down total for the 3 ports. – U-BRIDGE 3 User Guide – Version 1.0... -
Page 14: Support
© Copyright 2024 by INOGENI INC. All Rights Reserved. INOGENI name and logo are trademarks or registered trademarks of INOGENI. Use of this product is subject to the terms and conditions of the license and limited warranty in effect at the time of purchase. Product specifications can change without notice.
