I N F I N I T Y P L U S
Frontals
Hinge Adjustment - Drawer
Pull the drawer out
In order to adjust the drawer frontal, the
drawer must be pulled out on the runners.
Adjusting the frontal horizontally
Use the fixing clips, which are found under
the drawer's front, to adjust the drawer.
Step 1 - Press the fixing clips half way to meet
the runners on the underside of the drawer.
Step 2 - Slide the drawer to the left or right to
adjust.
Step 3 - Lock the frontal in place, by
releasing the fastening clips on both sides of
the drawer.
Page 1
Advertisement
Related Manuals for Wren Kitchens INFINITY PLUS Frontals
Summary of Contents for Wren Kitchens INFINITY PLUS Frontals
- Page 1 I N F I N I T Y P L U S Frontals Hinge Adjustment - Drawer Pull the drawer out In order to adjust the drawer frontal, the drawer must be pulled out on the runners. Adjusting the frontal horizontally Use the fixing clips, which are found under the drawer’s front, to adjust the drawer.
- Page 2 Adjusting the frontal height To adjust the height of the frontal, use a screwdriver as required at points 1 and 2. Step 1 - Loosen both of the screws at point 1. Step 2 - Turn the screw at point 2 to adjust the frontal’s height.
