CENTR FUSION BENCH User Manual page 9

PARTS LIST
No. Part Number
1 104360
104361
2
3 104395
104411
4
5 104403
6 104404
7 104405
9 104422
8 104419
9 102393
10 103111
11 102390
12 102391
13 104429
14 103097
15 104431
16 103223
17 103128
18 104422
19 104925
80242-EN-V2025-04-28
Description
MAIN FRAME
ASSY, BENCH ADJ ARM
TRANSPORT HANDLE
SEAT ADJUSTMENT ARM
BENCH BACK ASSEMBLY
TRANSPORT WHEEL
SEAT BENCH ASSEMBLY
RUBBER FOOT PADS
BOLT, M8 X 1.25 X 70P, BH, CL 8.8, BZ
WASHER, FLAT, 8.5 X 16 X 1.6, BZ
BOLT, M10 X 1.5 X 85, SH, CL 8.8, BZ
WASHER, FLAT, 10.5 X 20 X 2, BZ
NUT, M10 X 1.5 X 10, LOCK, CL 8, BZ
BOLT, M10 X 1.5 X 20, SH, CL 8.8, BZ
WASHER, SPLIT LOCK, M10, BZ
BOLT, M10 X 1.5 X 230P, SH, CL 12.9, BZ
BOLT, M8 X 1.25 X 45P, BH, CL 10.9, BZ
NUT, M8 X 1.25 X 8, LOCK, CL 8, BZ
SCREW, M5 X 0.8 X 12 PH BZ
WASHER, FLAT, 5.5 X 10 X 1.0 BZ
Qty.
1
1
2
1
1
2
1
6
6
1
1
1
1
1
4
2
2
4
12
12
Pg. 9
