Thermorail 12V Horizontal Towel Rail
Electric Heated Towel Rails for use in bathrooms
Stock Code
DSR6BG
Seven year
Safe for use
warranty
in bathrooms
PLEASE NOTE: Specifications are for information purposes only. Whilst every effort has been made to ensure the product specifications are accurate, due to continuing
product development and improvement the specifications are subject to change. Specifications can be used to rough in and fit timber supports in the wall however we
recommend no holes are drilled without having the product on site or verifying the details with the manufacturer. Thermogroup cannot be held liable or responsible for errors
Note: All dimensions are in millimeters (mm)
Rails are sold individually.
Finish
Size (mm)
Brushed Gold
W632 x H32 x D100
Quality
Safe for use
stainless steel
in wet areas
due to updated specifications.
Thermorail 12V Range DSR6BG
Output (W)
18
Right hand
Transformer
concealed
included
wiring
(12 month warranty)
No. of Bars
1
Recommended
Lead on rail
to be installed
in a set of 3+
1300 368 631
sales@thermogroup.com.au
www.thermogroup.com.au
Advertisement
Table of Contents
Related Manuals for Thermogroup Thermorail DSR4
Summary of Contents for Thermogroup Thermorail DSR4
- Page 1 Specifications can be used to rough in and fit timber supports in the wall however we recommend no holes are drilled without having the product on site or verifying the details with the manufacturer. Thermogroup cannot be held liable or responsible for errors due to updated specifications.
- Page 2 Consult your electrician for wiring requirements in your area. (Diagram for illustrative purposes only) Call us on 1300 368 631 or visit www.thermogroup.com.au...
- Page 3 Thermorail Towel Rail 12Volt Single Horizontal Bar Heated Towel Rail Installation Guide Please read these instructions carefully and in full before installation. Hardwire Installation should be carried out by a quali ed electrician.
-
Page 4: Table Of Contents
What’s in the box? ....................Standard Installation ................... Mounting System Installation ................Wiring Diagram ....................Operating Instructions ..................Technical Speci cations ..................Safety & Care Information ................... Warranty Information ................... Warranty Registration ..................Contact Us ......................1300 368 631 | www.thermogroup.com.au... -
Page 5: What's In The Box
*Please note the mounting brackets for DSC6, DSP6, DSP6B and DSP6BR look slightly different You will also need: • Cross Head Screwdriver • Pencil • Spirit Level • Tape Measure • 6mm Drill Bit • Cordless Drill • Electrical Supply 1300 368 631 | www.thermogroup.com.au... -
Page 6: Standard Installation
Remove the grub screws from the rail and locate over the mounting brackets. Connect the cable clips and x the rail in position and tighten with the grub screws and allen key provided. Ensure the connection clips are clipped together securely. Repeat for all rails. 1300 368 631 | www.thermogroup.com.au... -
Page 7: Mounting System Installation
Wire up the connection cable(s) to the transformer ensuring that multiple rails are wired in parallel. Ensure the transformer is wired up correctly according to the diagram on page 7. 1300 368 631 | www.thermogroup.com.au... - Page 8 Connect the cable clips and t the towel rail in position and tighten with the grub screws and allen keys provided. Ensure the connection clips are clipped together securely. Repeat for all rails. 1300 368 631 | www.thermogroup.com.au...
-
Page 9: Wiring Diagram
Electric Heated Towel Rails are designed to dry and gently warm a towel and are not designed as a towel heater or room heater. 1300 368 631 | www.thermogroup.com.au... -
Page 10: Technical Speci Cations
W632 x H40 x D70 IP45 DSP6B Black W632 x H40 x D70 IP45 DSP6BR Brushed W632 x H40 x D70 IP45 Supply Voltage 240V 50Hz Transformer Voltage Wiring Side Right Wiring Method Hardwired Warranty on Transformer 1 Year 1300 368 631 | www.thermogroup.com.au... -
Page 11: Safety & Care Information
The nish of your Thermorail Heated Towel Rail is hard wearing and easy to maintain. However, any harsh scrubbing, scratching or acid based cleaning products will damage the surface of your towel rail. Cleaning with a soft cloth and a non-abrasive cleaning agent will give the best results. 1300 368 631 | www.thermogroup.com.au... -
Page 12: Warranty Information
Warranty Information Thermogroup covers all its products with a satisfaction guarantee. In addition, Thermogroup will supply a replacement product where a fault is shown to be caused by manufacture, materials or workmanship providing the goods have been installed correctly and according to installation instructions. This guarantee does not include removal, freight or installation costs. -
Page 13: Warranty Registration
Fill out and sign below to declare that all the information recorded on this form correlates to the installation Customer Installer Name: ..........Name: ..........Email: ..........Email: ..........Address: ......... Address: ......... Postcode: ........Postcode: ........Phone: ..........Phone: ..........Signature: ........Signature: ........1300 368 631 | www.thermogroup.com.au... -
Page 14: Contact Us
Contact Us Phone: 1300 368 631 | Technical Helpline: 1300 989 464 sales@thermogroup.com.au | www.thermogroup.com.au...
