TF1800 Thermofan
Installation Guide
YOUR STEP-BY-STEP GUIDE TO
THE PERFECT INSTALLATION
!
PLEASE ENSURE YOU HAVE READ
AND FULLY UNDERSTOOD THIS
GUIDE BEFORE INSTALLATION!
BATHROOM FAN HEATERS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Thermofan TF1800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermogroup Thermofan TF1800

  • Page 1 PLEASE ENSURE YOU HAVE READ AND FULLY UNDERSTOOD THIS GUIDE BEFORE INSTALLATION! TF1800 Thermofan Installation Guide YOUR STEP-BY-STEP GUIDE TO THE PERFECT INSTALLATION BATHROOM FAN HEATERS...
  • Page 2 Leave the heater operating in small rooms if Remove and clean the filter at least every 6 the room is unoccupied or the occupant is months unable to leave the room or turn the unit off Visit our website www.thermogroup.com.au WWW.
  • Page 3: Installation

    TF1800 Positioning The TF1800 Bathroom Fan Heater is designed to be mounted on the wall in the vertical position. The Heater has a double insulation electrical circuit (class II) and therefore does not require an earth connection. The TF1800 has an IP rating of IPX4 which means it can be used in bathrooms and areas subject to humidity as long as it is not installed within the perimeter of baths and showers.
  • Page 4 The automatic electronic power selection, instead, manages the consumption through an accurate and comfortable regulation in order to automatically keep constant the selected temperature, according to what has previously been set on the electronic thermostat. Visit our website www.thermogroup.com.au WWW.
  • Page 5 TF1800 The TF1800 Bathroom Fan Heater has two modes that you can use to program your heater. Automatic Mode The TF1800 is set to work at a comfort temperature whenever someone is detected in the room. Should no one be detected in the room for 10 minutes, the heater will automatically go into the Eco mode (3.5°C less than the set Comfort temperature).
  • Page 6 3 seconds to enter the settings menu: Set the time: The 2 digits of the hour start flashing: set the current hour using buttons. Press to confirm The 2 digits of the minutes start flashing: set the current minutes using buttons Visit our website www.thermogroup.com.au WWW.
  • Page 7 TF1800 Press to confirm Set the day of the week (1 = Monday): After confirming the time, the day of the week starts flashing – set the current day of the week using buttons Press to confirm Set the Comfort Temperature (Eco = Comfort – 3.5C): After confirming the day of the week the comfort temperature will start flashing;...
  • Page 8 If a difference between set temperature and room temperature is detected in stable working conditions, measure the difference and then increase or decrease the comfort temperature on the product of the exact value of measured difference. Visit our website www.thermogroup.com.au WWW.
  • Page 9 TF1800 Weekly Program The Programmed mode allows the unit to be set to come on when you want the unit to come on every day of the week independently or the same and you can set the desired temperature at which you would like the unit to heat up to.
  • Page 10 At any time, you can abandon the procedure for editing the program deleting unsaved changes by pressing the Stand-By Button While programming the unit the heating elements are disconnected and the product will not heat. Visit our website www.thermogroup.com.au WWW.
  • Page 11 TF1800 Frost Free Mode To activate the FROST FREE Mode hold the button for 3 seconds. The thermostat is now set to maintain 7±3°C. To deactivate the FROST FREE position just press the or the buttons. FROST FREE mode will activate automatically when no one has been detected for at least 36 hours. In this case, the comfort temperature will be automatically activated once presence is detected again.
  • Page 12 Presence sensor for energy savings  IF24 splash protection  Double electrical insulation  Plug in or concealed wiring  Integrated Towel Rail  4 Hidden Hooks for extra towels  Frost Free Function  Made in Italy Visit our website www.thermogroup.com.au WWW.
  • Page 13 If the product develops a fault within the warranty period due to normal wear and tear, Thermogroup at its discretion will recognise whether it’s a faulty product or not. If it is impossible or not economical for the manufacturer to repair the product, the manufacturer...
  • Page 14 TF1800 Thermogroup 19 Ridley Avenue LEETON NSW 2705 1300 368 631 sales@thermogroup.com.au www.thermogroup.com.au E&OE © Thermogroup 2016 Visit our website www.thermogroup.com.au WWW.
