- Page 1 MyEye Bullet Lite Dome Lite IP Smart Bullet Camera IP Smart Dome Camera EN - Instructions and warnings for installation and use v0.1...
-
Page 2: Table Of Contents
C ONTENT IMPORTANT SAFEGUARDS AND WARNINGS 1.1 - Privacy protection notice 1.2 - About the manual 1.3 - Transportation and storage requirements 1.4 - Installation requirements 1.5 - Operation requirements DEVICE DESCRIPTION CONFIGURATION FLOW DEVICE INITIALIZATION LOGIN 5.1 - Device login 5.2 - Resetting password LIVE... - Page 3 11.3 - Record Control 12 - SYSTEM 12.1 - General 12.2 - Date & Time 12.3 - Account 12.3.1 - User 12.3.2 - User Group 12.3.3 - ONVIF User 13 - SAFETY 13.1 - IP Filter 13.2 - System Service 13.3 - HTTPS 14 -...
-
Page 4: Important Safeguards And Warnings
IMPORTANT SAFEGUARDS AND WARNINGS INSTALLATION AND CONFIGURATION 1.1 - Privacy protection notice As the device user or data controller, you might collect the personal data of others such as their face, fingerprints, and license plate number. You need to be in compliance with your local privacy protection laws and regulations to protect the legitimate rights and interests of other people by implementing measures which include but are not limited: Providing clear and visible identification to inform people of the existence of the surveillance area and provide required contact information. -
Page 5: Device Description
DEVICE DESCRIPTION Internet Protocol camera (IPC) is a type of digital video camera that receives control data and sends image data through the Internet. They can be used for surveillance and require no local recording device, but only a local network connection. The device is a multi-channel camera where you can set the parameters for each channel. -
Page 6: Configuration Flow
CONFIGURATION FLOW Figure 2: Configuration flow Table 1 - MyEye Bullet and Dome Lite - Configuration flow Configuration Description Reference Open a web browser and enter IP address to log into the device. The camera Login 5 - LOGIN IP address is 192.168.1.108 by default. Initialization Initialize the camera when you use it for the first time. -
Page 7: Device Initialization
DEVICE INITIALIZATION Device initialization is required for the first-time use. This manual is based on the operation on the web page. You can also initialize device using ConfigTool, recorder, or platform devices. To ensure the device safety, keep the password properly after initialization and change the password regularly. When initializing the device, keep the PC IP and device IP in the same network. -
Page 8: Login
LOGIN 5.1 - Device login You need to initialize the camera before logging in the web page. For more information, see 4 - DEVICE INITIALIZATION. When initializing the camera, keep the PC IP and camera IP in the same network. Follow the instruction to download and install the plug-in for the first login. - Page 9 time. You have to reset the device to get a security code or wait 24 hours to get it again. Figure 8: Resetting password 2 5. Enter Security Code and click Next. 6. Reset and confirm the password. The password must consist of 8 to 32 non-blank characters and contain at least two types of characters among upper case, lower case, number, and special character (excluding ' "...
-
Page 10: Live
LIVE In the Live section you can view the real-time monitoring image. Figure 9: Live section Table 3 - MyEye Bullet and Dome Lite - Elements of live section Function Description Live Displays the real-time monitoring image Playback Enables playing back or downloading recorded videos and image files Setting Enables configuration of camera functions Alarm... -
Page 11: Playback
PLAYBACK This section includes video and picture playback. Before playing back video or a snapshot you need to configure record time range, record schedule and record control. For more information, 11- STORAGE. 7.1 - Playback interface Figure 10: Playback interface Table 4 - MyEye Bullet and Dome Lite - Playback interface Function Description... -
Page 12: Camera
CAMERA 8.1 - Conditions 8.1.1 - Picture To improve the scene clarity configure picture parameters. Procedure: 1. Go to Settings > Camera > Conditions > Conditions > Picture. Figure 12: Conditions section 2. Configure picture parameters listed in the table below. Table 5 - MyEye Bullet and Dome Lite - Picture parameters Parameter Description... -
Page 13: Exposure
8.1.2 - Exposure Configure iris and shutter to improve image clarity. Note Cameras with true WDR don't support long exposure when WDR is enabled in Backlight. Procedure: 1. Go to Settings > Camera > Conditions > Conditions > Exposure. Figure 13: Exposure section 2. -
Page 14: Day/Night
8.1.4 - WB WB function makes the image colors display precisely. When in WB mode, white objects would always display white color in different environments. Procedure: 1. Go to Settings > Camera > Conditions > Conditions > WB. 2. Select one of the modes from a drop-down-list. Modes are listed in the table below. Table 7 - MyEye Bullet and Dome Lite - WB modes WB mode Description... -
Page 15: Illuminator
8.1.6 - Illuminator This configuration is available only when the device is equipped with illuminator. Procedure: 1. Go to Settings > Camera > Conditions > Conditions > Illuminator. 2. Select one of the following modes: • Manual - You can adjust the brightness of illuminator manually for the system to supply illuminator to the image accordingly. •... -
Page 16: Video Setting
8.2 - Video setting 8.2.1 - Video In this section you can configure video stream parameters. Click Default to restore device to default configuration. Click Refresh to view the latest configuration. Procedure: 1. Go to Settings > Camera > Video > Video. Figure 18: Video settings 2. -
Page 17: Snapshot
8.2.2 - Snapshot Click Default to restore device to default configuration. Click Refresh to view the latest configuration. Procedure: 1. Go to Settings > Camera > Video > Snapshot. Figure 19: Snapshot settings 2. Configure snapshot parameters listed in the table below. Table 10 - MyEye Bullet and Dome Lite - Snapshot parameters Parameter Description... -
Page 18: Channel Title
8.2.4 - Channel Title With this function enabled you can display channel title in the video image. Procedure: 1. Go to > Setting > Camera > Video > Overlay > Channel Title. 2. Tick the checkbox next to Enable. 3. Enter Input Channel Title. 4. -
Page 19: Audio
Figure 23: ROI 8.3 - Audio Procedure: 1. Go to Setting > Camera > Audio. 2. Tick the checkbox next to Enable in Main Stream or Sub Stream. Carefully activate the audio acquisition function according to the actual requirements. Figure 24: Audio parameters 3. -
Page 20: Network
NETWORK 9.1 - TCP/IP You can configure IP address and Domain Name System (DNS) server according to network plan. Procedure: 1. Connect the camera to the network. 2. Go to Setting > Network > TCP/IP. Figure 25: TCP/IP 3. Configure TCP/IP parameters listed in the table below. Table 12 - MyEye Bullet and Dome - TCP/IP parameters Parameter Description... -
Page 21: Multicast
2. Configure Port parameters listed in the table below. Note • 0–1024, 1900, 3800, 5000, 5050, 9999, 37776, 37780–37880, 39999, 42323 are reserved for specific uses. • Don't use the same value for any other port during port configuration. Table 13 - MyEye Bullet and Dome Lite - Port parameters Parameter Description The maximum number of users, including web client, platform, and mobile client, accessing the recorder the device... -
Page 22: Wifi
9.4 - WiFi Procedure: 1. Go to Setting > Network > WiFi. 2. Tick the checkbox next to Enable. 3. Tick the checkbox in the ID List column next to chosen Service Set Identifier (SSID) to connect to this network. You can also click Add SSID to add a WiFi network manually or click Search SSID for the device to find more WiFi networks. -
Page 23: Rtmp
9.5.2 - RTMP Through RTMP, you can access a third-party platform, such as YouTube, to realize video live view. RTMP can be configured by admin only. RTMP supports only the H.264, H.264 B and H.264H video formats, and the AAC audio format. Procedure: 1. -
Page 24: Event
EVENT 10.1 - Video Detection 10.1.1 - Motion Detection The system performs an alarm linkage when a moving object appears in the image and its moving speed reaches the configured sensitivity. If you enable motion detection and smart motion detection simultaneously, and configure the linked activities, the linked activities take effect as follows: •... -
Page 25: Video Tampering
Figure 33: Setting area for motion detection 12. Tick the checkbox next to Record and set Record Delay for the system to start recording when the alarm is triggered. 13. Tick the checkbox next to Snapshot for the system to take a snapshot when the alarm is triggered. 14. -
Page 26: Audio Detection
Figure 35: Motion Detection 10.3 - Audio Detection The system performs alarm linkage when vague voice, tone change, or rapid change of sound intensity is detected. Procedure: 1. Go to Setting > Event > Audio Detection. 2. Tick the checkboxes next to Input Abnormal and Intensity Change. 3. -
Page 27: Network
Figure 37: SD card abnormality 10.4.2 - Network Procedure: 1. Go to Setting > Event > Network. 2. Select Event Type choosing Disconnection or IP Conflict. 3. Tick the checkbox next to Enable. 4. Tick the checkbox next to Record and set Record Delay for the system to start recording when the alarm is triggered. 5. -
Page 28: Storage
STORAGE In this section you can manage saved resources (such as recorded video) and storage space. 11.1 - Schedule 11.1.1 - Record After the corresponding alarm type, General, Event, or Alarm, is enabled, the record channel links recording. Procedure: 1. Go to Setting > Storage > Schedule > Record. Figure 40: Record Schedule 2. -
Page 29: Destination
Figure 42: Holiday Schedule Note When Holiday Schedule setting isn't the same as the General setting, the Holiday Schedule setting is prior to the General setting. 11.2 - Destination 11.2.1 - Path Go to Setting > Storage > Destination > Path to select Event Type(s) to be saved on the internal SD card. Event Types include Scheduled, Event and Alarm. -
Page 30: System
SYSTEM 12.1 - General Procedure: 1. Go to Setting > System > General. 2. Enter the device Name. 3. Select Video Standard choosing PAL or NTSC. 4. Click Save. Figure 44: General section 12.2 - Date & Time Procedure: 1. Go to Setting > System > General > Date & Time. Figure 45: Date and time 2. -
Page 31: Account
12.3 - Account You can manage users. Users include admin, added users and ONVIF users. Managing users and groups are only available for administrator users. You can manage users through single user or group. Duplicating usernames or group names isn't allowed. A user can only be in one group at a time, and the group users can own authorities within group authority range. -
Page 32: User Group
Related Operations • Click the icon to edit password, group, remarks or authorities. For admin account, you can only edit the password. To change password tick the Modify Password checkbox, enter Old Password and New Password. • Click the icon to delete the added users. Admin user can't be deleted. •... -
Page 33: Onvif User
12.3.3 - ONVIF User Procedure of adding an ONVIF user: 1. Go to Setting > System > Account > Onvif User. 2. Click Add User. Figure 49: Adding ONVIF user 3. Configure the ONVIF user parameters listed in the table below. Table 19 - MyEye Bullet and Dome - ONVIF user parameters Parameter Description... -
Page 34: Safety
SAFETY 13.1 - IP Filter Configure the IP or MAC hosts, devices allowed to visit the camera. Only the hosts in the trusted sites list can log into the web interface. Procedure: 1. Go to Go to Setting > System > Safety > IP Filter. 2. -
Page 35: Https
13.3 - HTTPS Create a certificate or upload an authenticated certificate so that you can log in the camera through HTTPS using your PC. The HTTPS can protect page authenticity on all types of websites, secure accounts, and keep user communications, identity, and web browsing private. Procedure: 1. - Page 36 Figure 55: Certificate information 7. Click Install Certificate. Figure 56: Certificate import wizard 8. Click Next. Figure 57: Storing certificate 9. Select the storage location and click Next.
- Page 37 Figure 58: Completing certificate installation 10. Click Finish and a dialog box showing The import was successful pops up. Figure 59: Import succeeds...
-
Page 38: Default
DEFAULT Go to Setting > System > Default to restore the device to default configuration or factory settings. • Click Default to reset all the configurations except IP address and account to default. • Click Factory Default to reset all the configurations to factory settings. Figure 60: Default section... -
Page 39: Import/Export
IMPORT/EXPORT Figure 61: Import/Export section 15.1 - Import Import system configuration file to make quick configuration or recover system configuration. Procedure: 1. Go to Setting > System > Import/Export. 2. Click Import. 3. Select local configuration file, and click Open to import the local system configuration file to the system. 4. -
Page 40: Auto Maintain
AUTO MAINTAIN You can restart the system manually, and set the time of auto reboot and auto deleting old files. This function is disabled by default. Procedure: 1. Go to Setting > System > Auto Maintain. Figure 62: Auto Maintain section 2. -
Page 41: Upgrade
UPGRADE Upgrading to the latest system version can improve camera functions and stability. Procedure: 1. Go to Setting > System > Upgrade. Figure 63: Upgrade section 2. Select upgrading method according to the actual needs: • File Upgrade - Click Browse to upload upgrade file, which should be a .bin file. Click Upgrade for the upgrade to start. •... -
Page 42: Information
INFORMATION 18.1 - Version Go to Setting > System > Version to view the following information: • Device Type • System Version • WEB Version • ONVIF Version • S/N • Security Baseline Version 18.2 - Log You can view and back up logs. Procedure: 1. -
Page 43: Remote Log
18.3 - Remote Log Configure remote log, and you can get the related log by accessing the set address. Procedure: 1. Go to Setting > Information > Log > Remote Log. Figure 65: Remote log configuration 2. Tick the Enable checkbox to enable remote log function. 3. -
Page 44: Alarm
ALARM You can subscribe alarm event. When a subscribed alarm event is triggered, the system records detailed alarm information at the right side of the interface. Procedure: 1. Click the Alarm tab. Figure 66: Alarm section 2. Select Alarm Type(s) ticking checkboxes next to chosen types from the list below: •... -
Page 45: Cybersecurity Recommendations
Auto-check for updates function to obtain timely information of firmware updates released by the manufacturer. We recommend to down- load and use the latest version of client software. “Nice to have” recommendations to improve your network security: 1. Use physical protection... -
Page 46: Regulations
Simplified EU declaration of conformity: Hereby, Nice SpA Oderzo TV declares that the MyEye Bullet and MyEye Dome are in compliance with Directives 2014/53/EU, 2014/35/EU, 2011/65/EU and 2014/30/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.niceforyou.com/en/professional-area/download?v=18 under the download section. - Page 47 Nice SpA Oderzo TV Italia www.niceforyou.com info@niceforyou.com...
