Summary of Contents for Nice MyEye Bullet
- Page 1 MyEye Bullet Dome IP Smart Bullet Camera IP Smart Dome Camera EN - Instructions and warnings for installation and use v0.1...
-
Page 2: Table Of Contents
C ONTENT IMPORTANT SAFEGUARDS AND WARNINGS 1.1 - Privacy protection notice 1.2 - About the manual 1.3 - Transportation and storage requirements 1.4 - Installation requirements 1.5 - Operation requirements DEVICE DESCRIPTION CONFIGURATION FLOW DEVICE INITIALIZATION LOGIN 5.1 - Device login 5.2 - Resetting password HOME PAGE... - Page 3 10.3 - Setting Exception 10.3.1 - SD Card Exception 10.3.2 - Network Exception 10.3.3 - Voltage Exception 10.4 - Video Detection 10.4.1 - Motion Detection 10.4.2 - Video Tampering 10.4.3 - Scene Changing 10.5 - Audio Detection 10.6 - Disarming 11 - STORAGE 12 -...
- Page 4 19 - PICTURE 19.1 - Playing back picture 19.1.1 - Downloading snapshots 19.2 - Setting snapshot parameters 19.3 - Setting snapshot plan 19.4 - Storage 19.5 - Setting upload method 20 - CYBERSECURITY RECOMMENDATIONS 21 - REGULATIONS...
-
Page 5: Important Safeguards And Warnings
IMPORTANT SAFEGUARDS AND WARNINGS INSTALLATION AND CONFIGURATION 1.1 - Privacy protection notice As the device user or data controller, you might collect the personal data of others such as their face, fingerprints, and license plate number. You need to be in compliance with your local privacy protection laws and regulations to protect the legitimate rights and interests of other people by implementing measures which include but are not limited: Providing clear and visible identification to inform people of the existence of the surveillance area and provide required contact information. -
Page 6: Device Description
DEVICE DESCRIPTION Internet Protocol camera (IPC) is a type of digital video camera that receives control data and sends image data through the Internet. They can be used for surveillance and require no local recording device, but only a local network connection. The device is a multi-channel camera where you can set the parameters for each channel. -
Page 7: Configuration Flow
CONFIGURATION FLOW Figure 2: Configuration flow Table 1 - MyEye Bullet and Dome - Configuration flow Configuration Description Reference Open a web browser and enter IP address to log into the device. The camera Login 5 - LOGIN IP address is 192.168.1.108 by default. -
Page 8: Device Initialization
DEVICE INITIALIZATION Device initialization is required for the first-time use. This manual is based on the operation on the web page. You can also initialize device using ConfigTool, recorder, or platform devices. To ensure the device safety, keep the password properly after initialization and change thepassword regularly. When initializing the device, keep the PC IP and device IP in the same network. -
Page 9: Parameter Description
5. Set the password for admin account. Figure 5: Password setting Table 2 - MyEye Bullet and Dome - Password parameters Parameter Description Username The default username is admin. Password The password needs to consist of 8 to 32 non-blank characters and contain at least two types of characters among upper case, lower case, number, and special character (excluding ' "... -
Page 10: Login
LOGIN 5.1 - Device login You need to initialize the camera before logging in the web page. For more information, see 4 - DEVICE INITIALIZATION. When initializing the camera, keep the PC IP and camera IP in the same network. Follow the instruction to download and install the plug-in for the first login. -
Page 11: Home Page
HOME PAGE Click the icon in the upper-left corner of the page to display the home page. Figure 8: Home page Home page contains the following sections: • Live - enabling you to see the real-time monitoring image • Al - enabling you to configure AI functions of the camera. •... -
Page 12: Local
> Local. 2. Click Browse to select the storage path for live snapshot, live record, playback snapshot, playback download, and video clips. Figure 9: Local section Table 3 - MyEye Bullet and Dome - Local parameters Parameter Description Select the network transmission protocol by ticking one of the options: •... -
Page 13: Camera
CAMERA 8.1 - Image 8.1.1 - Page layout Go to Camera > Image to improve the scene clarity, and ensure that surveillance goes properly. You can select one of the following Working Modes: • Self-adaptive - The camera adjusts the image according to the environment. Figure 10: Self-adaptive page layout •... -
Page 14: Ai Ssa
• Day/night Switch - In this mode you can configure diffferent settings for day and night. Figure 12: Day/Night Switch page layout 8.1.2 - AI SSA With AI Scene Self-adaptation (AI SSA) enabled the camera can detect environmental conditions, such as rain, fog, backlight, low light or flicker. The camera adjust the parameters of the image to the conditions to ensure clear images. - Page 15 8.1.4 - WB Table 4 - MyEye Bullet and Dome - Image parameters Parameter Description Select one of the following options: • Soft - default image style displaying the actual color of the image Style • Standard - the hue of the image is weaker than the actual one and contrast is smaller •...
-
Page 16: Day/Night
Figure 15: Day and night settings 2. Configure day and night parameters listed in the table below. Table 6 - MyEye Bullet and Dome - Day and night parameters Parameter Description Day/Night configuration is independent from profile management configuration. You can select one of the options: •... -
Page 17: Encode
1. Go to > Camera > Encode > Encode. Figure 17: Encode settings 2. Configure illuminator parameters listed in the table below. Table 8 - MyEye Bullet and Dome - Encode parameters Parameter Description Sub Stream It's enabled by default. If not, click the button to enable. -
Page 18: Overlay
8.3 - Overlay You can configure overlay settings tol be displayed on the Live page. 8.3.1 - Privacy Masking You can enable this function to protect the privacy of some area of the video image. You can select the following types of the masking: •... -
Page 19: Time Title
8.3.3 - Time Title With this function enabled you can display time in the video image. Procedure: 1. Go to > Camera > Encode > Overlay > Time Title. 2. Click the button next to Enable. 3. Click the button next to Week Display to display the day of week. 4. -
Page 20: Picture Overlay
Figure 22: Font Properties 8.3.6 - Picture Overlay With this function enabled you can display picture information in the video image. Note Text overlay and picture overlay can't work at the same time. Procedure: 1. Go to > Camera > Encode > Overlay > Picture Overlay. 2. -
Page 21: Audio
Carefully activate the audio acquisition function according to the actual requirements. Figure 25: Audio parameters 3. Configure audio parameters listed in the table below. Table 9 - MyEye Bullet and Dome - Audio parameters Parameter Description You can set audio Encode Mode selecting one of the following options: •... -
Page 22: Alarm Tone
8.4.2 - Alarm Tone You can record or upload an alarm audio file. The audio file is played when the alarm is triggered. Procedure: 1. Go to > Camera > Audio Tone. 2. Click Add. Figure 26: Adding alarm tone 3. -
Page 23: Network
2. Go to > Network > TCP/IP. Figure 28: TCP/IP 3. Configure TCP/IP parameters listed in the table below. Table 10 - MyEye Bullet and Dome - TCP/IP parameters Parameter Description Host Name Enter the host name no longer than 15 characters This function is enabled by default. -
Page 24: Port
• 0–1024, 1900, 3800, 5000, 5050, 9999, 37776, 37780–37880, 39999, 42323 are reserved for specific uses. • Don't use the same value for any other port during port configuration. Table 11 - MyEye Bullet and Dome - Port parameters Parameter... -
Page 25: Pppoe
Figure 31: DDNS 3. Click the button to enable the function. 4. Configure DDNS parameters listed in the table below. Table 12 - MyEye Bullet and Dome - DDNS parameters Parameter Description Type Before configuration, check the type of DNS server supported by the camera. -
Page 26: Email
Figure 32: Email setting 2. Click the button next to Enable. 3. Configure Email parameters listed in the table below. Table 13 - MyEye Bullet and Dome - Email parameters Parameter Description SMTP Server SMTP server address: smtp.gmail.com The port number of the SMTP server. -
Page 27: Upnp
9.6 - UPnP Universal Plug and Play (UPnP) is a protocol that establishes mapping relation between local area and wide area networks. This function enables you to access local area device through wide area IP address. Before starting the procedure: •... - Page 28 Figure 34: SNMP 3. In Trap Address enter the IP address of the PC that has MIB Builder or MG-SOFT MIB Browser installed, and leave other parameters to the default. Table 14 - MyEye Bullet and Dome - SNMP parameters Parameter Description Version Tick the checkbox of SNMP version that you are using.
-
Page 29: Bonjour
1. Go to Figure 37: Auto Registration 2. Click the button next to Enable and configure parameters listed in the table below. Table 15 - MyEye Bullet and Dome - Auto Registration parameters Parameter Description Server Address The IP address or domain name of the server to be registered... -
Page 30: Qos
9.11 - QoS You can solve problems such as network delay and congestion with this function. It helps to assure bandwidth, reduce transmission delay, packet loss rate, and delay jitter to improve experience. 0–63 means 64 degrees of priority; 0 for the lowest and 63 the highest. Procedure: 1. -
Page 31: Rtmp
Note Make sure that the IP address is trustable when enabling RTMP. Figure 41: RTMP 3. Configure RTMP parameters listed in the table below. Table 16 - MyEye Bullet and Dome - RTMP parameters Parameter Description Stream Type The stream for live view. Make sure that the video format is H.264, H.264 B and H.264H, and the audio format is AAC. - Page 32 2. Enable the basic service listed in the table below according to the actual needs. Table 17 - MyEye Bullet and Dome - Basic Service parameters Function Description Used to perform safety management Multicast/Broadcast With this function enabled multiple users viewing the device video image simultaneously through network can find Search your device with multicast/broadcast protocol.
-
Page 33: Event
EVENT 10.1 - Alarm Linkage When an alarm is triggered by the device connected to the alarm-in port, the system performs the defined alarm linkage. Procedure: 1. Go to > Event > Alarm. 2. Click the button next to Enable. Figure 43: Alarm linkage 3. -
Page 34: Record Linkage
> Event > Alarm. 2. Click the button next to Send Email. 10.2 - Subscribing Alarm Table 18 - MyEye Bullet and Dome - Description of alarm types Alarm Type Description Preparation Motion detection is enabled. For more information, see Motion Detection The alarm is triggered when moving object is detected. -
Page 35: Setting Exception
When a subscribed alarm event is triggered, the system records detailed alarm information at the right side of the page. Figure 45: Alarm subscription Procedure: 1. Click the icon at the right-upper corner of the main page. 2. Click the button next to Enable. -
Page 36: Voltage Exception
Figure 47: Network Exception 2. Click the button next to chosen network detection functions. 3. Set alarm linkage actions.For more information, see 10.1 - Alarm Linkage. 4. Click Apply. 10.3.3 - Voltage Exception When the input voltage is higher or lower than the rated value of the device, the system performs alarm linkage. Procedure: 1. -
Page 37: Video Tampering
Procedure: 1. Go to > Event > Video Detection > Motion Detection. Figure 49: Motion Detection button next to the Motion Detection function. 2. Click the 3. Click Setting next to Area to set an area for motion detection. Figure 50: Area setting 4. -
Page 38: Scene Changing
Figure 51: Video tampering 2. Configure the parameters listed in the table below. Table 19 - MyEye Bullet and Dome - Description of video temper parameters Parameter Description Video Tampering is the only available option. When the percentage of the tampered image and the duration exceed the Event Type configured values, an alarm is triggered. -
Page 39: Audio Detection
1. Go to > Event > Video Detection > Audio Detection. Figure 53: Audio detection 2. Configure the parameters listed in the table below. Table 20 - MyEye Bullet and Dome - Description of Audio Detection parameters Parameter Description Audio Exeption Click the button next to Audio Exception for the alarm to be triggered when the system detects abnormal sound input. -
Page 40: Storage
STORAGE This section displays the information of the local SD card. Go to > Storage. You can select one of the following options: • Read-Only - the SD card is set to read only. • Read & Write - the SD card is set to read & write. •... -
Page 41: System
> System > General > Date & Time. Figure 57: Date and time 2. Configure the parameters listed in the table below. Table 21 - MyEye Bullet and Dome - Description of Date & Time parameters Parameter Description • Manually Setting - for manual parameters configuration Time •... -
Page 42: User
12.3.1 - User You are admin user by default. There is one admin by default who has the highest authority. You can add users, and configure different permissions. You can have 18 users at most. Procedure of adding a new user: 1. -
Page 43: User Group
3. Configure the user parameters listed in the table below. Table 22 - MyEye Bullet and Dome - User parameters Parameter Description User’s unique identification. You can't use existed username. The max length of the user name is 31 characters including Username numbers, letters, underline, dash, dot and @. -
Page 44: Onvif User
2. Click Add. Figure 64: Adding an ONVIF user 3. Configure the ONVIF user parameters listed in the table below. Table 23 - MyEye Bullet and Dome - ONVIF user parameters Parameter Description User’s unique identification. You can't use existed username. The max length of the user name is 31 characters including Username numbers, letters, underline, dash, dot and @. -
Page 45: Manager
12.4 - Manager To make sure the system runs normally, maintain it as the following requirements: • Check surveillance images regularly. • Clear regularly user and user group information that aren't frequently used. • Change the password every three months. •... -
Page 46: Default
12.4.3 - Default To restore the device to default configuration or factory settings go to > System > Manager > Default. • Click Default to reset to default all the configurations except IP address and account. • Click Factory Default to reset to factory settings all the configurations. Figure 67: Default 12.5 - Upgrade Upgrading to the latest system can refine camera functions and improve stability. -
Page 47: Log
, 2000, and the end time should be earlier than December 31 , 2037. 3. Select a log type choosing one of options listed in the table below. Table 24 - MyEye Bullet and Dome - Log types Type Description... -
Page 48: Live
15.1 - Live Page Log in and click the Live tab. Figure 71: Live - single channel Figure72: Live - multiple channels Table 25 - MyEye Bullet and Dome - Description of function bar Function Description Channel list Displays all channels. You can select the channel as needed and set the stream type. -
Page 49: Live View Function Bar
15.3 - Live View function bar Table 26 - MyEye Bullet and Dome - Description of live view top function bar Icon Function Description Auxiliary Instalation Click the icon to enable or disable IVS as AI rule Warning Light Click the icon to enable or disable Warning Light... -
Page 50: Ai: Ivs
AI: IVS Basic requirements on scene selection for intelligent video system (IVS) are as follows: • The target should occupy no more than 10% of the whole image. • The target size in the image should be at least 10 × 10 pixels. The target height and width should be no more than a third of the image height and width. -
Page 51: Security
SECURITY 17.1 - Security Status Scan the security modules to check the security status of the camera so that when abnormality appears you can process it timely. • User and service detection - Detect login authentication, user status, and configuration securityto check whether the current configuration conforms to recommendation. -
Page 52: Https
Figure 78: 802.1x - PEAP Figure 79: 802.1x - TLS 17.2.2 - HTTPS HTTPS protects page authenticity on all types of websites, secure accounts, and keep user communications, identity, and web browsing private. Procedure: 1. Go to Security > System Service > HTTPS. 2. -
Page 53: Attack Defense
17.3 - Attack Defense 17.3.1 - Firewall Configure firewall to limit access to the camera. Procedure: 1. Go to Security > Attack Defense > Firewall. Figure 81: Firewall 2. Click the button next to Enable. 3. Select the mode choosing one of the options: •... -
Page 54: Anti-Dos Attack
17.3.3 - Anti-DoS Attack You can enable SYN Flood Attack Defense and ICMP Flood Attack Defense to defend the device against Dos attack. Procedure: 1. Go to Security > Attack Defense > Anti-DoS Attack. 2. Select SYN Flood Attack Defense or ICMP Flood Attack Defense. Figure 84: Setting Anti-DoS attack 17.4 - CA Certificate 17.4.1 - Creating Device Certificate... -
Page 55: Importing Third-Party Ca Device Certificate
17.4.2 - Importing third-party CA Device Certificate Procedure: 1. Go to Security > CA Certificate > Device Certificate. 2. Select Install Device Certificate. 3. Select Apply for CA Certificate and Import (Recommended) and click Next. Figure 86: Selecting installation mode 4. -
Page 56: Installing Trusted Ca Certificate
Figure 88: Certificate and private key 4. Click Browse to select the Certificate Path and Private Key file. 5. Enter the Private Key Password. 6. Click Install and Import. After the certificate is created successfully, you can view this certificate on the Device Certificate page. Related Operations •... -
Page 57: Security Warning
2. Configure A/V encryption parameter listed in the table below. Table 28 - MyEye Bullet and Dome - A/V encryption parameters Area Parameter Description Enables stream frame encryption by using private protocol. There might be safety risk if this service is Enable disabled. -
Page 58: Record
The video playback page is displayed. Figure 89: Search video Figure 93: Video playback page Table 29 - MyEye Bullet and Dome - Description of video playback page No. Function Description Displays all searched recorded video files. -
Page 59: Clipping Video
18.1.1 - Clipping video Procedure: 1. Click the icon. 2. Drag the clipping box on the progress bar to select the start time and end time of the target video. Figure 94: Clipping video 3. Click OK to download the video. 4. -
Page 60: Record Control
1. Click the Record section on the home page. 2. Click the Record Control tab. Figure 97: Record Control 3. Set parameters listed in the table below. Table 30 - MyEye Bullet and Dome - Description of record control parameters Parameter Description Max Duration The time for packing each video file The time to record the video in advance of a triggered alarm event. -
Page 61: Storage
Procedure: 1. Go to Record > Storage. Figure 100: Setting storage 2. Set storage parameters listed in the table below. Table 31 - MyEye Bullet and Dome - Description of storage parameters Parameter Description Event Type Select from Scheduled, Motion Detection and Alarm. -
Page 62: Nas
Figure 101: FTP setting 6. Set FTP parameters listed in the table below. Table 32 - MyEye Bullet and Dome - Description of FTP parameters Parameter Description Server IP The IP address of the FTP server Port The port number of the FTP server... - Page 63 Figure 102: NAS setting 5. Set NAS parameters listed in the table below. Table 33 - MyEye Bullet and Dome - Description of NAS parameters Parameter Description Server IP The IP address of the NAS server Storage Path The destination path in the NAS server Username When selecting SMB protocol, you are required to enter username and password.
-
Page 64: Picture
6. Point to the searched picture, and then click the icon in the picture to play back the selected video. The video playback page is displayed. Figure 104: Picture playback Table 34 - MyEye Bullet and Dome - Description of video playback page No. Function Description Snapshot Displays all searched snapshots. -
Page 65: Downloading Snapshots
19.1.1 - Downloading snapshots Download a snapshot to a defined path. You can download a single snapshot, or download them in batches. For more information on viewing or setting storage path, see 7 - LOCAL. Operations might vary with different browsers. Procedure: 1. -
Page 66: Setting Snapshot Plan
1. Go to Picture > Auto Upload. icon next to Enable. 2. Click the Figure 108: Image Upload Table 31 - MyEye Bullet and Dome - Description of HTTP mode parameters Parameter Description IP/Domain name The IP address and port number of the server which the report is uploaded to. -
Page 67: Cybersecurity Recommendations
Auto-check for updates function to obtain timely information of firmware updates released by the manufacturer. We recommend to down- load and use the latest version of client software. “Nice to have” recommendations to improve your network security: 1. Use physical protection... -
Page 68: Regulations
Simplified EU declaration of conformity: Hereby, Nice SpA Oderzo TV declares that the MyEye Bullet and MyEye Dome are in compliance with Directives 2014/53/EU, 2014/35/EU, 2011/65/EU and 2014/30/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.niceforyou.com/en/professional-area/download?v=18 under the download section. - Page 69 Nice SpA Oderzo TV Italia www.niceforyou.com info@niceforyou.com...
