Strong SRT41 Manual

INTRODUCTION

Thank you for choosing the 4K Ultra HD Google TV Stick supplied by STRONG. It has been produced with the latest new technology and offers extensive entertainment and great versatility. We wish you many hours of new great experiences exploring the Google world!

STORAGE

Please follow the instructions below:
This user manual provides complete instructions for installing and using this product. The symbols will serve as follows:

Indicates warning information.
NOTE: Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the product.
Move to Represents a menu item within a window.

PACKAGE CONTENT

• 1x Google TV-Stick
• 1x Voice Enabled Remote
• 1x 5V/1A-Power USB Adaptor
• 2x AAA-Batteries
• 1x Installation instructions

The batteries should not be recharged, disassembled, electrically short- circuited, be mixed or used with other types of batteries. If rechargeable accumulators instead of batteries are going to be used (e.g. NiMH), we recommend using types with low selfdischarge to ensure long time operation of your remote control.

NOTE : Only use the original USB power adaptor of 1 Ampere. Other adaptors only use 0,5 Ampere which is not enough to supply this Google TV Stick.

TV STICK PANEL

PANEL

REMOTE CONTROL

1. Press to turn the TV/ Stick to On or Standby.
2. Select the input source mode.
3. Press to activate the voice control function*.

4. Select TV inputs after setup remote button configuration

5. Press to access the TV settings.

6. Navigate the menu. Confirm the selection.

7. Press to go back to previously viewed channel. In menu: Back to previous menu.
8. Call account menu to select between accounts

9. Enter the home desktop.

10. VOL +/- Adjust the volume up or down.
11. Press to mute or restore the volume.

12. Change programmes up or down.

13. YouTube Press for direct access to YouTube.
14. NETFLIX Press for direct access to Netflix**
15. prime video Press for direct access to prime video***.
16. Disney+ Press for direct access to Disney+****.

*Voice control and some other functions could work only when this RCU paired with your TV.
** Membership is not included. Netflix is available in selected countries. Streaming Netflix requires to set up an account. Broadband Internet required. See www.netflix.com/TermsOfUse for details.
*** Membership is not included. Prime is available in selected countries. Streaming prime video requires to set up an account. Broadband Internet required. See www.primevideo.com for details.
**** Membership is not included. Disney+ is available in selected countries. Streaming Disney+ requires to set up an account. Broadband Internet required. See www.disneyplus.com for details.

INSTALLING THE BATTERIES

Open the cover on the remote control and insert 2x AAA batteries into the compartment. The correct position of batteries polar diagram is shown inside the batteries compartment.

1. Open the cover.
2. Insert the batteries.
3. Close the lid.

The batteries should not be recharged, disassembled, electrically short- circuited, be mixed or used with other types of batteries.

CONNECTION GUIDE

Refer to the diagram below for connecting your Google TV Stick to the TV.

NOTE: Before getting started, please turn off all devices to be connected.

NOTE: The SRT41 stick supports Wi-Fi 2.4GHz and 5 GHz. To connect, go to Settings → Network.

NOTE: Before turning on your device, please switch the signal input of the TV to the correct source

SETTING UP YOUR DEVICE

You may turn on your TV stick after properly connecting all hardware. To be able to use Google Assistant on your remote, you must first pair your Bluetooth Remote to your TV Stick. Follow the pairing instruction on the screen.

To be able to use Google Assistant on your remote, please pair the remote to your TV Stick.

Step 1: Language

Select your preferred language on the Welcome Page.

Step 2: Location Settings

Choose whether to allow Google to use your location to improve the experience.

Step 3: Set up Google TV

Select set up Google TV to configure the apps that will be installed on your TV and linked to your Google Account.

Step 4: Set up with the Google Home App

Set up the TV stick by downloading / opening the Google Home app on your phone. Please, scan the QR code on your phone and follow the instructions to start this Google home.

Alternatively, start the setup directly on the TV screen by pressing the down button to begin manual entry. Please, follow the instructions on your TV screen.

Step 5: Wi-Fi

Select your Wi-Fi Network from the list and enter its password.

Step 6: Google Account

Sign in with your Google Account.

Step 7: Terms of Service & Privacy Policy

Read and accept the Terms of Services & Privacy Policy.

Select Got it.

Step 8: Google Services

Select the services that you want to configure from the list. Select turn off for the features that you want to deactivate.

Select Accept.

Step 9: Meet your Google Assistant

Turn on the Google Assistant function for the functionality to work on your remote.

Step 10: Search across your TV apps

Select an option from the list

Step 11: Select your subscriptions

Select the apps for which you want to receive recommendations. Theses apps will be installed as well as the main streaming services from your area. Select confirm to launch the installation of your apps.

Step 12: Wait for your apps to be installed

Step 13: Select options that suit your needs

Select the option that suits your needs if you have to restrict the access to certain types of contents. And follow the steps on your screen. If you don't need to restrict access to certain types of content, select "Go to Google TV". Explore the features of your device in this walkthrough. Click "DONE" to complete it and start using your device. You're all set!

SETTINGS

Press the setting button to open Settings Select Settings to check the device information, add/remove accounts and make changes to the system settings.

Wi-Fi Settings
Under Network Settings, select and enable Wi-Fi in order to connect to the network. Once the device scans and lists nearby Wi-Fi networks, select the appropriate network name, if required put in the password and select Connect.

Language Settings

Under Settings > System select Language to change the language previously set.

Bluetooth Pairing
Select Settings in the Menu Launcher, click "Add accessory" and select the device you want to connect. Make sure that the device you want to pair is in pairing mode.

Remove a Bluetooth Device
Select Settings from the Menu Launcher. From the Remote & Accessories menu, select the Bluetooth device you want to remove. Click "Forget" to remove this device.

Adding Accounts
For new Google users: sign up for a new Google account using the TV for easier login and payment security. Add an account or switch accounts under Accounts in the Settings Menu.

Factory Reset
Under Settings, select System > About > Reset Click Factory data reset to erase everything. Once this option has been selected, all manually installed apps and user data information will be deleted.

About
You can check information about your device by clicking on ABOUT in the Settings Menu. This panel will show you the model of your device, version, firmware version and more. You can also update your system by clicking on System update from this menu.

DOWNLOADING APPS

Apps are available for download on the Google Play Store. Select "Search" and type name or press microphone and tell name.

GOOGLE CAST

Cast from a Mobile Device
Certain apps allow you to cast to your TV. To cast, simply follow the following steps: Open a Google cast compatible app on your mobile device Navigate to the screen you wish to cast

Cast from Google Chrome
This device has Google Cast built-in. To cast from Google Chrome, click the Settings icon [ ]: located on the top right corner of the browser, then click "Cast".

GOOGLE ASSISTANT

Say it to Play it
Ask it to play your favorite show, video, or music. Or find the latest blockbuster to enjoy.

Movies & TV shows:
Play Stranger Things on Netflix. Video clips: Play cat videos. Apps: Open YouTube. Search: Search for sitcoms. Info: Tell me about Game of Thrones.

Control
Playback: Pause. Stop. Resume Volume: Louder. Softer. Power: Turn off.

Play music, news, or podcasts
Music: Play music by Sia. (Learn how to choose your music service provider.)
News: Play the news. What's the latest news from BBC?

Ask Google
Sports: How did the Patriots do? When is the next Warriors game?
Calculations: What's 20% of 80?
Dictionary: What does "ludic" mean?
Find answers: How far away is the moon? How do you remove stains in arug?
Unit conversions: How many teaspoons in a cup?

NOTE: To be able to use Google Assistant on your remote, you must first pair your Bluetooth Remote to your TV Stick.

SIMPLE TROUBLESHOOTING

TECHNICAL SPECIFICATIONS

Data Protection:
Please be aware that STRONG, its manufacturing partners, the application providers and the providers of the services may collect and use technical data and related information, including but not limited to technical information about this device, system and application software and peripherals. STRONG, its manufacturing partners, the application providers and the providers of the services may use such information to improve its products or to provide services or technologies to you, as long as it is in a form that does not personally identify you.

Additionally, please keep in mind that some services provided - already in the device or installed by you - may request a registration for which you have to provide personal data. Beside that, please be aware that some services which are not pre-installed but can be installed may collect personal data even without providing additional warnings and that STRONG cannot be held liable for a possible breach of data protection by services not pre-installed.

* Availability of apps depending on the country. STRONG cannot be held liable for services by third parties. Offers by third parties may be changed or removed at any time, may not be available in all regions and may require a separate subscription.

SAFETY INSTRUCTIONS

Read all of the instructions before operating the set. Keep these instructions well for later use.

• Only use attachments/accessories specified or provided by the manufacturer (such as the exclusive supply adapter, battery etc.).
• Please refer to the information on the exterior back enclosure for electrical and safety information before installing or operating the apparatus.
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• The ventilation should not be impeded by covering the ventilation openings with items, such as newspaper, table-cloths, curtains, etc.
• The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
• The mark indicates a risk of electric shock. The external wires must be installed by an instructed person or ready-made leads or cords must be used.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
• Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent types.
• The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like.
• Excessive sound pressure from earphones and headphones can cause hearing loss.
• Listening to music at high volume levels and for extended durations can damage one's hearing.
• In order to reduce the risk of damage to hearing, one should lower the volume to a safe, comfortable level, and reduce the amount of time listening at high levels.
• The mains plug or appliance coupler is used as disconnect device, it shall remain readily operable. When not in use and during movement, please take care of the power cord set, e.g. tie up the power cord set with cable tie or something like that. It shall be free from sharp edges or similar which can cause abrasion of the power cord set. When put into use again, please make sure the power cord is not damaged. In case of damages, please get the power cord replaced by a similar one with the same specifications. The absence of a light indication on the apparatus does not mean that it is fully disconnected from the mains. To disconnect the apparatus completely, the mains plug must be pulled out.
• Attention should be drawn to environmental aspects of battery disposal.
• No naked flame sources, such as lighted candles, should be placed on the apparatus.
• To prevent the spread of fire, keep candles or other open flames away from this product at all times.
• A USB terminal can provide a maximum of 500 mA.
• Equipment with this symbol is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth.

Operating Environment

• Do not install this equipment in a confined space such as a bookcase or similar unit.
• Do not use the set near damp, and cold areas, protect the set from overheating.
• Keep away from direct sunlight.
• Do not use the set near dust place.
• Do not attach candle to accessible opening area, to avoid flammable foreign material from entering the TV.
