POOL PUMP AND SAND FILTER SYSTEM
0.75 HP 110 V 16 INCH 7-WAY ABOVE-GROUND
ITEM: 75131
INSTALLATION AND USER'S GUIDE
75131
DANGER
Read all safety warnings and instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Advertisement
Table of Contents
Related Manuals for XtremepowerUS 75131
Summary of Contents for XtremepowerUS 75131
- Page 1 POOL PUMP AND SAND FILTER SYSTEM 0.75 HP 110 V 16 INCH 7-WAY ABOVE-GROUND ITEM: 75131 INSTALLATION AND USER’S GUIDE 75131 DANGER Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols GENERAL SAFETY OVERVIEW (PRODUCT INFORMATION) PACKAGE CONTENTS PUMP AND SAND FILTER SYSTEM PRODUCT DIMENSIONS SPECIFICATIONS INSTALLATION PUMP LOCATION ELECTRICAL INSTALLATION INSTRUCTIONS STEP 1: PUMP BASE ASSEMBLY STEP 2: SAND FILTER DRAIN INSTALLATION STEP 3: MEDIA ASSEMBLY INSTALLATION STEP 4: ADDING FILTER MEDIA STEP 5: PRESSURE GAUGE INSTALLATION... - Page 3 TABLE OF CONTENTS MAINTENANCE Pump Maintenance Water Chemistry REPLACEMENT PARTS Parts Diagram DISCLAIMER Disclaimer Customer Service...
-
Page 4: Important Safety Instructions
NOTE related to hazards. USE OF NON-XTREMEPOWERUS REPLACEMENT PARTS VOIDS WARRANTY ATTENTION INSTALLER: This manual contains vital information regarding the installation, operation, and safe use of this product. It is essential to provide this manual to the end user of the product. Failure to read and follow all instructions could lead to severe injuries. - Page 5 IMPORTANT SAFETY INSTRUCTIONS DANGER Risk of electrical shock. Connect this product solely to a branch circuit that is safeguarded by a ground-fault circuit interrupter (GFCI). If you are unable to confirm the presence of a GFCI protection on the circuit, please seek assistance from a qualified electrician. WARNING Please note that this unit must only be connected to a supply circuit protected by a ground-fault circuit-interrupter (GFCI).
-
Page 6: General Safety
IMPORTANT SAFETY INSTRUCTIONS GENERAL SAFETY WARNING • The pump and sand filter system is not designed to be submersible. • Do not attempt to open the inside of the drive or motor enclosure, as there is a capacitor bank that can retain a potentially dangerous electrical charge, even when the unit is not powered. •... - Page 7 IMPORTANT SAFETY INSTRUCTIONS DANGER DANGER DANGER DANGER DANGER SUCTION ENTRAPMENT HAZARD WARNING To minimize the risk of injury caused by suction entrapment hazards, please follow these safety guidelines: • Use only properly installed and secured ANSI/ASME A112.19.8 approved anti-entrapment suction covers for each drain.
-
Page 8: Overview (Product Information)
OVERVIEW (PRODUCT INFORMATION) OVERVIEW (PRODUCT INFORMATION) PACKAGE CONTENTS PARTS # & PARTS # PARTS # PARTS # PARTS # MEDIA ASSEMBLY PUMP WITH STRAINER 7-WAY VALVE FILTER TANK MEDIA ASSEMBLY 1 PC(S) 1 PC(S) 1 PC(S) W/ AIR RELEASE LATERAL 1 SET(S) 8 PC(S) 1.5 FT... -
Page 9: Pump And Sand Filter System
OVERVIEW (PRODUCT INFORMATION) PUMP AND SAND FILTER SYSTEM 7-WAY VALVE PRESSURE GAGE KL1.6 PIPE FILTER TANK PUMP PUMP BASE FILTER RINSE RECIRCULATE WASTE WINTER BACKWASH CLOSED... -
Page 10: Product Dimensions
OVERVIEW (PRODUCT INFORMATION) PRODUCT DIMENSIONS 24.4” 30.2” 25.4” 22” 9.1” 18.2”... -
Page 11: Specifications
OVERVIEW (PRODUCT INFORMATION) SPECIFICATIONS 110 V INPUT VOLTAGE 60 HZ FREQUENCY SINGLE SPEED SPEED 3450 RPM 0.75 HP HORSEPOWER PLUG WIRE 530 W MAXIMUM CONTINUOUS LOAD -40°F TO 140°F (-40°C TO 60°C) AMBIENT CONDITIONS 32°F TO 122°F (0°C TO 50°C) STORAGE RELATIVE 0 TO 95 % NON-CONDENSING OPERATING HUMIDITY... -
Page 12: Installation
INSTALLATION INSTALLATION INSTALLATION INSTALLATION PUMP LOCATION NOTE • This pump should not be installed within an outer enclosure or beneath the skirt of a hot tub or spa, unless there are specific markings indicating its suitability for such installation. • It is essential to mechanically secure the pump and sand filter system to the pump base during installation. -
Page 13: Electrical
INSTALLATION ELECTRICAL RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. DANGER It's crucial to follow the National Electrical Code and all relevant local codes and ordinances. Going against these rules can result in a high risk of electrical shock, potentially leading to severe injury, death, or property damage for individuals involved. -
Page 14: Installation Instructions
INSTALLATION INSTALLATION INSTRUCTIONS For detailed guidance on safe installation, please refer to the IMPORTANT SAFETY INSTRUC- TIONS. These instructions are vital to ensure the pump is set up correctly, maintaining safety and optimal performance. STEP 1: PUMP BASE ASSEMBLY Figure A PARTS # PARTS # Figure B... -
Page 15: Step 2: Sand Filter Drain Installation
INSTALLATION STEP 2: SAND FILTER DRAIN INSTALLATION Figure C PARTS # Figure D NOTE Do not overtighten the components of Part #9. PARTS #... -
Page 16: Step 3: Media Assembly Installation
INSTALLATION STEP 3: MEDIA ASSEMBLY INSTALLATION Figure E PARTS # PARTS # PARTS # & REMOVE IT BEFORE INSTALL VALVE Figure F PARTS #... -
Page 17: Step 4: Adding Filter Media
INSTALLATION INSTALLATION STEP 4: ADDING FILTER MEDIA Pool Filter Media Balls Figure G (filter balls not included) PARTS # Pool Filter Media Sand REMOVE IT BEFORE Figure H (filter sand not included) INSTALL VALVE WARNING Use only POOL FILTER SAND for this step. Sand Selection and Loading Requirements: Commonly used sand: #20 (0.71MM quartz sand) Sand density: 0.1 LB / FT³... -
Page 18: Step 5: Pressure Gauge Installation
INSTALLATION STEP 5: PRESSURE GAUGE INSTALLATION Figure I Figure J PARTS # PRESSURE GAUGE PORT PARTS # PRESSURE GAUGE PORT PLUG PARTS # Figure K Figure L PRESSURE GAUGE PORT TEFLON TAPE KL1.6 PARTS # PARTS # TEFLON TAPE PARTS #... -
Page 19: Step 6: Flange Clamp Installation
INSTALLATION STEP 6: FLANGE CLAMP INSTALLATION Figure M PARTS # PARTS #... -
Page 20: Step 7: Tank Attachment
INSTALLATION STEP 7: TANK ATTACHMENT Figure N PARTS # PARTS # PUMP INLET PARTS # PARTS #... -
Page 21: Step 8: Hose Accessories Attachment
INSTALLATION STEP 8: HOSE ACCESSORIES ATTACHMENT Figure O PARTS # PARTS # PARTS # PARTS # PUMP INLET PARTS # PARTS # POOL OUTLET PARTS # PARTS # WASTE OUTLET POOL INLET PARTS # PUMP OUTLET... -
Page 22: Step 9: Hose Attachment
INSTALLATION STEP 9: HOSE ATTACHMENT Figure P PARTS # PARTS # WASTE OUTLET PUMP INLET POOL INLET POOL OUTLET PUMP OUTLET PARTS #... -
Page 23: Step 10: Power Connection
INSTALLATION STEP 10: POWER CONNECTION A. Refer to the details below for the minimum distance in inches between the ground fault protection socket and the pump and sand filter system. (Figure R) B. Use an 18 AWG extension cord capable of handling the electrical load of the filter pump. Figure Q Pump Running Time Suggestion Chart Pool Capacity (Gallons) Duration of Each Run (Hours) Operating Frequency (Hours/Run) -
Page 24: Operation
• Before conducting the test, ensure all XtremepowerUS pump and system components are removed from the plumbing system. This ensures that the test is performed independently of the pump and its components. -
Page 25: Priming The Pump
OPERATION PRIMING THE PUMP • To begin, fill the strainer housing with water up to the level of the suction pipe. If any water leakage is observed from the pump or filter, DO NOT start the pump. In such cases, it is essential to address the leakage issue before proceeding. -
Page 26: After Priming The Pump
OPERATION Priming Instructions: (Continued) • Open all pool suction and WASTE lines for free water flow to the WASTE line. Press down and turn the top mount valve handle to the “BACKWASH” position. • Inspect the valve clamp for proper tightness. •... -
Page 27: Valve Functions
OPERATION VALVE FUNCTIONS CAUTION Never operate the pump without water. BACKWASH (Initial Run) Use this setting to clean the filter. When the filter pressure gauge rises 5-10 PSI (0.0.34-0.69 BAR, this reading may vary depending on the pool's pump and general piping system) above the start-up clean pressure. -
Page 28: Rinse (Initial Run)
OPERATION RINSE (Initial Run) This ensures that all the dirty water from backwashing is rinsed out of the filter and goes to waste, preventing possible return to the pool. • After backwashing, keep the pump off and set the valve to "RINSE" position and start the pump for about 0.5 to 1 minute. -
Page 29: Filter (Normal Operation)
OPERATION FILTER (Regular Operation) For normal filtering and regular vacuuming. • Turn off the pump. Set the valve to the "FILTRATION" position for regular pool filtration. Then, start the pump. • Occasionally check the pressure gauge to ensure pressure remains within the normal range 5-10 PSI (0.0.34-0.69 BAR), this reading may vary depending on the pool's pump and general piping system. -
Page 30: Recirculate (Move The Water Around Without Filtering)
OPERATION RECIRCULATE (Move The Water Around Without Filtering) Only use the it for a short period of time when the filter is malfunctioning, there is a severe algal bloom in the water, chemicals are being added to the pool, or after the filter has been backwashed. •... -
Page 31: Waste (Bypass Filter Media For Direct Water Exit)
OPERATION WASTE (Bypass Filter Media For Direct Water Exit) It enables water to access the filter but avoids passing through the filter media, instead directing it to exit the filtration system entirely. It aids in extracting leaves, dirt, and additional debris. •... -
Page 32: Closed (Shut Off The Flow To The Filter And Pool)
OPERATION CLOSED (Shut Off The Flow To The Filter and Pool) WARNING Avoid activating the pool pump when the 7-way valve is set to CLOSED, as this could result in damaging the filter, the pump, or both. This function involves shutting the valve to prevent water from entering, offering utility in clearing the lines during the pool's opening process and during winterization to expel air through the suction lines, redirecting airflow into the pool. -
Page 33: Winter (For Winterizing)
OPERATION WINTER (For Winterizing) Separate bonding surfaces to prevent freezing damage. NOTE Clearing out all residual water will reduce the risk of freeze damage. • Setting the Valve for Winterization With the pump remaining off, set the valve to the "WINTER" position to open all ports to prevent ◦... - Page 34 OPERATION WINTER (For Winterizing) (Continued) DANGER Before attempting any corrective actions, ensure that the pump is in the OFF position. To avoid any potential electrical hazards, wait until the remaining power in the capacitor is fully discharged before proceeding with any work on the pump. •...
-
Page 35: Control Panel
OPERATION CONTROL PANEL TIMER SETUP • Unscrew the 4 screws securing the terminal box lid and remove the lid. • Take out the battery. • Carefully remove the protective film from the battery's surface. • Replace the battery and reapply the rubber film. •... -
Page 36: Regular Inspection And Maintenance
MAINTENANCE REGULAR INSPECTION AND MAINTENANCE • Check Screws Ensure all screws in the baseboard are securely tightened. Tighten any loose screws. ▪ • Inspect Power Cords and Insulation Check for any damage to power cords or insulation parts. If damaged, have a qualified ▪... -
Page 37: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING DANGER Turn the pump OFF and disconnect the power source before any corrective work. Wait for the pump's capacitor to discharge completely to prevent electrical hazards. ISSUE CAUSE CORRECTIVE ACTION Improper or loose wiring connections; open Check all connections switches or relays Tripped circuit breakers Reset tripped breakers... - Page 38 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Incorrect Voltage Check input voltage and wiring connection Incorrect Wiring Check wiring connections Manually check rotation of motor shaft for free Mechanical binding movement with no obstruction Pump Hums but Ensure that the pump is properly primed before its will Not Start first use.
- Page 39 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Contact a qualified repair professional. Block off the bottom port of the skimmer to determine if pump will develop a vacuum. You should have 5”- 6” of vacuum at the strainer cover (Only your Pool dealer can confirm this with a vacuum gauge).You may be able to check by removing the skimmer basket and holding your hand over the bottom port...
- Page 40 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Air leak in suction Re-tighten using Teflon tape. (bubbles issuing from return fittings). Low Flow (Cont) Plugged, restricted, or Contact a qualified repair professional. damaged impeller. Clear blockage and replace the impeller seal. Air leak in suction piping, cavitation caused by Correct suction condition or throttle return lines, if restricted or undersized...
- Page 41 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Water Leakage The damaged o-ring installed. Adjust or replace the o-ring. (Inlet, Outlet, and Drainage Port) The locking ring is not properly Tighten the screws of the locking ring to ensure installed. proper installation. Water Discharging (From The Drain- The sealing ring of the Replace with a new valve.
-
Page 42: Maintenance
MAINTENANCE MAINTENANCE PUMP MAINTENANCE DANGER Always ensure the power to the pump is disconnected before starting any work. • Motors are designed to be self-lubricating, eliminating the need for additional lubrication. • Check the motor for any blockage of air vents on the motor shell. If any debris is found, remove it after turning off the power source. -
Page 43: Water Chemistry
MAINTENANCE WATER CHEMISTRY Maintaining proper water chemistry is essential for clean, sanitary water and to control algae growth in the pool or spa. Chlorine Use dry or liquid chlorine (calcium or sodium hypochlorite) daily to ensure clean and sanitary water. Chlorine dissipates due to dirt, germs, sunlight, and wind exposure. -
Page 44: Replacement Parts
REPLACEMENT PARTS REPLACEMENT PARTS PARTS DIAGRAM ITEM PARTS NO. DESCRIPTION ITEM PARTS NO. DESCRIPTION 647303971000 7-WAY VALVE 647304073000 DRAIN PLUG 1 1/2" HOSE 1.5’ 647229002001 647304017080 LATERALS 65432055080 GASKET Φ56*Φ47*14 647304571000 CENTRAL PIPE 1 1/2" HOSE 5.4’ 647279510 647229003001 CONNECTOR 5431021080 647303901 16"... -
Page 45: Disclaimer
DISCLAIMER DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor expressly state that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer.
