2HP 230V 2 SPEED INGROUND POOL PUMP
INSTALLATION AND
USER'S GUIDE
Full Installation and
User Guide and Instruction Video
ITEM: 75035
Read all safety warnings and instructions.
Failure to follow the warnings and
instructions may result in electric shock,
fire and/or serious injury. Save all warnings
and instructions for future reference.
DANGER
Advertisement
Table of Contents
Related Manuals for XtremepowerUS 75035
Summary of Contents for XtremepowerUS 75035
- Page 1 2HP 230V 2 SPEED INGROUND POOL PUMP ITEM: 75035 INSTALLATION AND USER’S GUIDE Full Installation and User Guide and Instruction Video DANGER Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
- Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS CUSTOMER SERVICE Customer Service and Technical Support IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols GENERAL SAFETY OVERVIEW (PRODUCT INFORMATION) TWO-SPEED PUMPS PRODUCT DIMENSIONS SPECIFICATIONS INSTALLATION PUMP LOCATION PIPING PIPE SIZING CHART FITTINGS AND VALVES ELECTRICAL INSTALLATION WIRING BONDING Electrical Chart... -
Page 4: Important Safety Instructions
NOTE hazards. USE OF NON-XTREMEPOWERUS REPLACEMENT PARTS VOIDS WARRANTY ATTENTION INSTALLER: This manual contains vital information regarding the installation, operation, and safe use of this variable speed pump. It is essential to provide this manual to the end user of the product. - Page 5 Please ensure that this pump is only used with permanent swimming pools and hot tubs or spas if appropriately indicated. Avoid using it with storable pools to prevent potential hazards and ensure optimal performance. XtremepowerUS ® Installation and User’s Guide...
-
Page 6: General Safety
It is essential to strictly adhere to the correct sizing, installation, and designated usage to mitigate these potential dangers and ensure the safety of all users and the surrounding environment. use only XtremepowerUS ® replacement parts... - Page 7 It is crucial to ensure that all users are familiar with the switch's location and understand how to use it effectively in case of an emergency. This measure ensures swift and safe response to any critical situations that may arise during the pump's operation. XtremepowerUS ® Installation and User’s Guide...
-
Page 8: Overview (Product Information)
The picture below illustrates how to switch between high speed and low speed. When using the timer, the pump speed switch must be set to either high speed or low speed to turn on. High Speed Low Speed use only XtremepowerUS ® replacement parts... -
Page 9: Product Dimensions
-40°F to +140°F (-40ºC to +60ºC) Storage Operating +32°F to +122°F (0ºC to +50ºC) Relative 0 to 95 % non-condensing Humidity Certification UL Listed CSA Certificated ETL Listed Features Thermal Protected Heavy-Duty Long-Lasting Case XtremepowerUS ® Installation and User’s Guide... -
Page 10: Installation
Select a well-drained location that will not flood during rainy periods. Never install the pump and filter in a damp or poorly ventilated area. Keeping the motor clean is crucial, as pump motors require unrestricted air circulation to aid in cooling. use only XtremepowerUS ® replacement parts... -
Page 11: Piping
When plumbing the pump in parallel with another pump, be sure to install check valves. This precautionary measure helps prevent the reverse rotation of the impeller and motor, ensuring smooth and efficient operation of both pumps. XtremepowerUS ® Installation and User’s Guide... -
Page 12: Electrical Installation
Always reinstall the drive lid after completing the electrical installation or before leaving the pump unsupervised during servicing. This step prevents rainwater, dust, or other foreign matter from accumulating in the drive and protects the components. use only XtremepowerUS ® replacement parts... - Page 13 Ensure that wires are not pinched between the drive body and the lid to prevent damage or safety issues. These precautions are vital to ensure the safe and proper functioning of the motor and to avoid potential hazards during installation and servicing. GREEN (GROUND) L1, L2 (HOT) XtremepowerUS ® Installation and User’s Guide...
-
Page 14: Bonding
(KW) rating and the distance from the power source. Please note that all electrical wiring must be carried out by a licensed electrician and must comply with local codes and NEC regulations. Use only copper conductors for the wiring. use only XtremepowerUS ® replacement parts... -
Page 15: Operation
Engage the services of a professional to perform the water pressure test. Their expertise will ensure accurate and safe testing of the plumbing system. Before conducting the test, ensure all XtremepowerUS pump and system components are removed from the plumbing system. This ensures that the test is performed independently of the pump and its components. - Page 16 Possible indicators that the pump is NOT primed include the absence of water flow, unusual noises, or insufficient pressure readings. Ensure all suction and discharge valves are open when the pump is running. For troubleshooting guidance, refer to the Troubleshooting Guide. use only XtremepowerUS ® replacement parts...
-
Page 17: Troubleshooting
Manually check rotation of motor shaft for free Mechanical binding movement with no obstruction. Electrical overload Ensure proper grounding and wiring voltage. XtremepowerUS ® Installation and User’s Guide... - Page 18 Leaking O-ring or packing Tighten, repair, or replace valves. glands on valves. Strainer basket or Remove strainer housing cover or skimmer cover, skimmer basket loaded clean basket, and refill strainer housing with water. with debris. Tighten cover. use only XtremepowerUS ® replacement parts...
- Page 19 Plugged or restricted Sand filters – backwash as per manufacturer’s discharge line of filter, instructions; D.E. filters – backwash as per valve partially closed manufacturer’s instructions; Cartridge filters – clean (high gauge reading). or replace cartridge. XtremepowerUS ® Installation and User’s Guide...
- Page 20 Check for leaks in the seals time that may allow water, including chemicals, to work into the bearing ring and wipe out the grease. Any leaking seals should be replaced at once. use only XtremepowerUS ® replacement parts...
-
Page 21: Maintenance
Fill the pump pot and volute up to the inlet port with water. Thoroughly clean the cover, cover O-ring, and sealing surface. Apply grease to the O-ring using a silicone-based lubricant. XtremepowerUS ® Installation and User’s Guide... - Page 22 Turn the power "ON" at the house circuit breaker and reset the pool time clock to the correct time. Start the pump, and ensure you are standing clear of the filter. Observe for a steady stream of water comes out. O-RING BASKET VOLUTE VOLUTE use only XtremepowerUS ® replacement parts...
-
Page 23: Winterization
NOTE When replacing the motor, ensure that the motor support is correctly positioned to adequately support the size of the motor being installed. XtremepowerUS ® Installation and User’s Guide... -
Page 24: Servicing
Diffuser (Item #8) and take off the diffuser from the motor housing. Insert a flathead screwdriver into the groove at the end of the shaft to securely fasten the motor shaft. use only XtremepowerUS ® replacement parts... - Page 25 XtremepowerUS ® Installation and User’s Guide...
- Page 26 Reconnect the pump to the pipeline. Open all motor (Item# 14) together using screws (Item # valves and ensure that the pump body is filled 16). Alternate and tighten the screws evenly. with water before restarting the pump. use only XtremepowerUS ® replacement parts...
-
Page 27: Replacement Parts
Strainer Basket 49130101001 5431032080 O-ring 5232001106 5212025000 Screw 48860105080 Drain Plug 47254703080 Diffuser 5432002080 Gasket Screw 5231002106 5221008000 647274871000 Impeller 5224003000 Screw 5028014000 Seal Assembly 47254704080 Mounting Foot 5431168080 O-ring 47254705080 Insert, Motor Foot XtremepowerUS ® Installation and User’s Guide... -
Page 28: Disclaimer
It is essential to follow all safety guidelines and recommendations provided in this manual and to seek professional assistance if unsure about the installation or operation procedures. use only XtremepowerUS ® replacement parts... -
Page 29: Warranty
We hope this rearrangement and numbering provide a clearer understanding of the warranty coverage and its terms. If you have any questions or need to initiate a warranty claim, please contact our customer service team. Thank you for choosing XtremepowerUS for your pool products, and we wish you an enjoyable experience with our products.
