M2 operator's Manual

Call us for more information: 1-888-484-9376

MS-03-E

Table of Contents

Need help?

Do you have a question about the M2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hydro Mobile M2 Series

Page 1 M2 operator’s Manual Call us for more information: 1-888-484-9376 MS-03-E...
Page 2: General Information
Hydro Mobile inc. Weight p7, misspelling p29, grease type p65 Sept 2004 v3.1 This Hydro Mobile Inc. product is covered and protected by patents un NOTE Canada, United States of America and Europe United States: 4809814...
Page 3 Dear owner or user: Thank you for investing in a Hydro Mobile M2 Series mast climbing work platform system. The design of this new motorized unit reﬂ ects a decade of contin- ued ﬁ eld operation, testing and research work and comes as a solution to our company’s deepest concern, your safety and well being on the job.
Page 4 Hydro Mobile shall pay, to the extent established by its applicable service policy in effect at the time of delivery, the cost to install any repaired or replacement part provided under this warranty. The cost of any such work will only be paid by Hydro Mobile if a written authorization has been granted prior to its begin- ning.
Page 5: Table Of Contents
Index Table of contents Contents Contents Introduction Weather protection Warranty Monorail Index Forward extension 24’ (7,3m) MU overview Hoist system 14’ (4,3m) MU overview Plank safety & cross-boxes Safety & Performance Transportation Position motorized unit Trailer Access Maintenance Rest platform Job equipment check list Engine Layout check list...
Page 6: 24' (7,3M) Mu Overview
24’ (7,3m) MU overview Sliding door (2) Climbable tower (2) Control post End guard rail (2) Engine access with intergrated tool box, refer to page 8 Door guard rail (2) Platform Top outriggers (7) Fork lift pocket (2) Movable guard rail (2) Bottom outriggers (9) Hydraulic power pack Access platform...
Page 7 24’ (7,3m) MU overview Simple hydraulic dual Sliding door system for Integrated bridge coupling Independent or linked base Open deck design to pass pump system w / reliable effortless and safe access system for fast set-up on uneven wall ties. New climbable Honda 9.0 HP to material (automatic terrain.
Page 8 24’ (7,3m) MU overview Cantilever bridge outrigger Removable guard rail Doors (2), door guard rails Mud sill storage (4) support (2) storage (2) (2) & end rails (2) Mason guard Tool box Cylinder & secondary hook rail storage (2) storage for transportation Locking bar storage (2)
Page 9: 14' (4,3M) Mu Overview
14’ (4,3m) MU overview Sliding door (2) Climbable tower (2) Control post End guard rail (2) Engine access with intergrated tool box, refer to page 11 Door guard rail (2) Platform Movable guard rail (2) Fork lift pocket (2) Hydraulic power pack Bottom outriggers (5) Access platform with intergrated ladder...
Page 10 14’ (4,3m) MU overview Simple hydraulic dual Sliding door system for Integrated bridge coupling Independent or linked base Open deck design to pass pump system w / reliable effortless and safe access system for fast set-up on uneven wall ties. New climbable Honda 9.0 HP to material (automatic terrain.
Page 11 14’ (4,3m) MU overview Cantilever bridge outrigger Mason guard rail (2) Doors (2), door guard rails (2), end Mud sill storage (4) support (2) rails (2) & removable guard rails (2) Tool box Cylinder & secondary hook storage for transportation Locking bar storage (2)
Page 12: Safety & Performance
Safety & Performance SAFETY comes ﬁ rst. For your personal safety, always have a competent person and back up competent person assemble, operate, disassemble and move this mast climber system. The deﬁ nition of competent person is deﬁ ned as one having the; 1 - Capability of identifying existing and predictable hazard, 2 - Authority to take prompt corrective action, 3 - Training &...
Page 13 Il est de votre responsabilité d’utiliser le de una manera apropriada. with the hoist is mandatory. manuel de façon appropriée. 12- Always wear an approved hard hat and safety boots when working on the Hydro Mobile system. S-V78M2...
Page 14: Position Motorized Unit
Position motorized unit Installation should be done under the supervision of a competent person, respecting all federal, state, and local regulations. In reference to the plan/layout drawing or having otherwise established position of motorised unit, determine where mud sills need to be positioned. On free standing installations, open base outriggers as far as possible.
Page 15 S-V62M2 adjust base level slightly to suit (not more than 5 revolutions per jack). Should tower(s) remain out of plumb after slight base adjustment, contact your distributor or Hydro Mobile for base/tower re-shimming WARNING / AVERTISSEMENT / AVISO instructions.
Page 16 Position motorized unit Reaction MINIMUM BEARING CAPACITY TABLE 12 544 lb (5 690 kg) Two motorized unit Height (pressure per mud sill) (ft) Reaction (psi) (kpa) 10 192 lb Free 10,7 Mud sill standing (4 623 kg) Jack 11 760 lb 15,2 (5 334 kg) 12 544 lb...
Page 17 Position motorized unit Position the motorized unit using a lift truck, 8 000 lb (3 630 kg) capac- ity minimum, optional wheel set or crane. Before lowering unit to the ground open adjustable jacks by 4” to 5” to facilitate levelling. WARNING / AVERTISSEMENT / AVISO Check base Vérifiez le niveau de la...
Page 18 Position motorized unit Base separation instructions Separating the base for uneven ground or for bypassing obstacles can be done following these steps. With the platform sitting on its base, remove locking bars and/or transportation hooks. Tie cylinder and secondary hooks away from tower using wire or rubber straps. Slide a piece of 2x4” x 6’ (38x89mm x 1,8m) long through access platform guard rail system to keep it closed for next step.
Page 19 Position motorized unit Base separation instructions, continued 10- The base can also be separated and installed with its long side parallel to the wall when space is limited near the ground. Follow same base separation steps but install ﬁ rst tower rotated 90 degrees. The base tower anti-error installation stubs will need to be removed to set the next tower section.
Page 20: Access
Access To reach work area when motorized unit is To reach work area when motorized unit is above 10’ (3,05m) we reccommend you use between 0 and 10’ (3,05m) high, climb up tower a staircase and opening on the building. If unavailable, climb tower rungs up to the access rungs on wall side of machine making sure wall platform, them climb the access platform ladder up onto the work area.
Page 21 Access The use of fall protection equipment is mandatory when climbing or descending the tower if exposed to height over 10’ (3,05m). Ex: Use full body harness and self-retracting lifeline. Attach rope to self-retracting lifeline hook for easy access from ground. Use of fall protection equipment is also mandatory when modifying planking (add shock absorbing lanyard).
Page 22: Rest Platform
Rest platform NOTICE The use of a retractable rest platform is recommended to access jobs 40’ to 69’ (12,2m to 21,0m). We do not recom- mend using the climbable tower on jobs over 69’ (21,0m) Folder part because of time and effort required to reach the work area. Installation procedure For safety reasons, we recommend that the rest platfrom be installed from the motorized unit deck or from a man basket underneath the motorized unit.
Page 23 Rest platform USE OF REST PLATFORM Climb the tower until one step above the rest platform. Raise the handle to retract the rest platform from the tower. Step on the rest platform as handle reaches vertical position. Once you are on the rest platform release the handle. When you will start climbing again the rest platform will retract into the tower automatically.
Page 24: Engine
Engine Start up preparation instructions Starting procedure Open engine control lever door. Open motor access doors. Pull out choke handle (blue control rod) Pull control post from its storage area by releasing the locking pin. Use Release pump pressure by moving both levers up and down before 15/16”...
Page 25: Tower Installation
Towers Tower installation Tower removal & transport To connect one tower section to another, insert top tower onto the bottom tower section, making sure To remove one tower section from an the towers line up square and that rungs for the hooks are on the same side. other loosen the toggle bolt assembly Slide the 5/8 x 6 1/2”...
Page 26: Hooks Installation
Hooks installation Remove transportation hook from hydraulic cylinder assembly and store under hook storage door (you may need to lower platform to remove hook). Install a set of towers (see tower section) Open hook storage door, remove hitch pin clips and release cylinder hook and secondary hook.
Page 27: Raise / Lowering Platform
Raising / Lowering platform OPERATING INSTRUCTIONS S-V49M2v2 INSTRUCTIONS D’OPÉRATION Locking device INSTRUCCIONES DE OPERACION Lowering cam Remove locking bars (2x). Retirer les barres de blocage (2x). Quitar las barras de bloqueo (2x) Keep platform level. Garder la plate-forme de niveau. Guardar la plataforma de nivel.
Page 28 Raising / Lowering Raising platform Lowering 2 rungs Lock both cylinder and secondary hook lowering cams using Unlock both cylinder and secondary hook lowering cams locking device. using the locking device. With engine running at full RPM, push both control levers With the engine running at full RPM and with both away from you using one hand.
Page 29: Wall Ties
Wall ties WALL TIE SCHEDULE Set up with Standard Platform hoist, weather set up height protection, forward extension (2 or 4 planks) or 5 to 8 planks 0 - 35' Free standing No free standing (0-10,6m) 0 - 250' Every Every (21,1m - 76,2m) 20 ft...
Page 30 Wall ties Loosen bolts on the wall tie tower bracket. Slide wall tie tower bracket assembly into the tower diagonally, making sure to install the tower bracket as close as possible to the upper rung to avoid interference with feet for climbing. Tighten the bolts on the wall tie tower bracket until the bracket holds the tower ﬁ...
Page 31 Wall ties Wall tie parts required Parts required 3 X 1/2" Adapter Wall tie Diagram Male part Female part (76,2 X 12,7mm) (plank(s)) pin ass'y extension bolt ass'y 15" (38cm) 18" (46cm) 21" (53cm) 24" (61cm) 33" (84cm) 34" (86cm) 37"...
Page 32 Wall ties Diagram A Diagram B Diagram C Diagram D Diagram E...
Page 33 Wall ties Angle brackets may be required for installing wall mounts WARNING / AVERTISSEMENT / AVISO throught window openings. Floor or wall type anchors will need to be used for this type of application. Also note that the maximum allowable angle between the ﬂ oor and tower rungs is 30 degrees.
Page 34 Wall ties Before attaching towers to the building using the tie system, it will be necessary to install anchors to a solid building structure. Concrete slabs, columns, steel beams, relief angles and other structural members can be used provided that a 3 000 lb (1 360 kg ) tension / compression and 1 000 lb (454 kg ) shear force can be applied.
Page 35: Anchor Installation
Wall ties Anchor installation While work is in progress and platform is rising, install wall anchors as per wall tie schedule. Measure distance from edge of slab to face of brick. Select the correct size anchor to suit. Removal After adjustable wall mounts have been removed, cut off ﬁ xed anchor at mortar joint using a grinder.
Page 36: Bridges
Bridges CANTILEVER BRIDGES BEARING BRIDGES A cantilever bridge system is the assembly of one (6, 10, 14 and A bearing bridge is an assembly of two (6, 10, 14 and 18 ft.) (1,8m, 18 ft maximum.) (1,8m, 3,1m, 4,3m and 5,5m) half-bridge on 3,1m, 4,3m and 5,5m) half-bridge sections.
Page 37 Bridges (0,6 m) Bridge specifications Bridge specifications Bridge specifications (1,8 m) (3,0 m) Size 26 1/2" x 91" x 39 1/2" (0,7m x 2,3m x 1,0m) Size 71 7/8" x 91" x 39 1/2" (1,8m x 2,3m x 1,0m) Size 120 7/8"...
Page 38 Bridges Bridge specifications Bridge specifications Bridge specifications (4,3 m) (5,5 m) (3,1 m) Size 168 3/4" x 91" x 39 1/2" (4,3m x 2,3m x 1,0m) Size 216 3/4" x 91" x 39 1/2" (5,5m x 2,3m x 1,0m) Size 123 1/4"...
Page 39 Bridges Cantilever installation procedure Position motorized unit to allow easy access. Raise to top of second tower. Use lift truck to position the half bridge or suspend it using slings. Connect upper half bridge to motorized unit using bolt assemblies (6). Guard rail storage DO NOT TIGHTEN YET.
Page 40 Bridges Bearing installation procedure WARNING 6'' (150mm) Minimum AVERTISSEMENT Position, install and level motorized units in AVISO accordance to example on next page. Minimum overlap: Set half-bridge sections on a level surface, 6” (150 mm) using wood cribbing or towers so that link Chevauchement minimal: 6”(150 mm) plates are free from ground.
Page 41 Bridges 6” (152mm) maximum offset each side 2’ (0,6m) insert must be installed 5 000 lb (2 268 kg) maximum capacity on bearing bridge B, 12” (305mm) maximum offset, must be evenly distributed forward or backward A = B - 1’6” (46cm) Note;...
Page 42 Bridges For 24' (7,3m) motorized unit only For 14' (7,3m) motorized unit only Counterweight required on cantilever bridge (A) (lb) Counterweight required on cantilever bridge (A) (lb) Bearing bridge size Cantilever bridge size Bearing bridge size Cantilever bridge size B (ft) A (ft) B (ft) A (ft)
Page 43: Capacities
Capacities Warning To keep workers using the mast climber safe at all times, it will be necessary to make sure the bridges are not loaded beyond their maximum rated weight capaci- ties. Also, to prevent your mast climbing system from stalling because of overload you will have to respect the Maximum weight capacities single unit maximum rated weight capacity of the motorized unit(s).
Page 44 Capacities Maximum weight capacities (12' (3,7m) ) bearing bridge Total length Total length with with 5 000 lb MU 24' (7,3m) MU 14' (4,3m) (2 268 kg) max. for corner setup 12 700 lb 12 400 lb 12 700 lb not used not used (5 760 kg)
Page 45 Capacities Maximum weight capacities (20' (6,1m) ) bearing bridge Total length Total length with with MU 24' (7,3m) MU 14' (4,3m) 5 000 lb (2 268 kg) max. for corner setup 12 575 lb 11 650 lb 12 575 lb not used not used (5 705 kg)
Page 46 Capacities Maximum weight capacities (28' (8,5m) ) bearing bridge Total length Total length with with MU 24' (7,3m) MU 14' (4,3m) 5 000 lb (2 268 kg) max. for corner setup 12 450 lb 12 450 lb Not used for corner setup Not used (5 650 kg) (5 650 kg)
Page 47 Capacities Maximum weight capacities (36' (11,0m) ) bearing bridge Total length Total length with with MU 24' (7,3m) MU 14' (4,3m) 5 000 lb (2 268 kg) max. for corner setup 12 350 lb 10 100 lb 12 350 lb Not used Not used (5 600 kg)
Page 48 Capacities Maximum weight capacities (48' (14,6m) ) bearing bridge Total length Total length with with MU 24' (7,3m) MU 14' (4,3m) 5 000 lb (2 268 kg) max. for corner setup 12 200 lb 8 500 lb 12 200 lb Not used Not used (5 535 kg)
Page 49 Capacities Maximum weight capacities (56' (17,1m) ) bearing bridge Total length Total length with with MU 24' (7,3m) MU 14' (4,3m) 5 000 lb (2 268 kg) max. for corner setup 12 100 lb 7 700 lb 12 100 lb 104' Not used Not used...
Page 50: Guard Rail & Outriggers
Guard rail & Outriggers Guard rail Outriggers There are three types of guard rails: 5 ft , 7 ft (1,5m Two levels of outriggers are provided; for men (lower level) and materials (top level). Top outriggers and 2,1m) and an ajustable. To install guard rails can be extended out 3’...
Page 51: Outriggers & Mason Guard Rail
Outriggers & Mason Top outriggers can be inserted from the front Mason guard rail guard rail only. Once planks are in place, push outrigger back in, until welded plank stop rests snugly A mason guard rail enables the closing of open ended planks. If against plank.
Page 52: Sliding Doors
Sliding doors Sliding doors Two sliding doors allow for safe loading of materials onto motorized units. All Top wheel references are made with the observer standing behind unit and facing the work. To install the guard rails and doors follow these steps; Use a fork lift to put the doors and door guard rails on the platform.
Page 53: Sliding Doors & Face Guard Rail
Sliding doors & Face Install the door on the door guard rail, with top wheel on the top Face guard rail guard rail midrail tube. Adjust the height of the door using the “eye bolt”, the door Face guard rail brackets must be used when the space between the mason should be approx.
Page 54: Wheel Set
Wheel set Sling Lower/raise the cantilever set-up to top of second tower. Move wheel set under bridge using handle bars. Install wheel set under a vertical truss support using 4 locking pins Slowly lower set-up onto wheel set. Sling Install the locking bars (2x). Raise up base until the locking bars lock under tower rungs.
Page 55: Weather Protection
Weather protection Positioning bottom support Setting up roof structure with roof tube kit (outriggers) Slide the bottom support under the unit or bridge. Insert the back vertical post into the bottom support pocket. The Hook it temporarily usingt suport collar. head of the vertical post must face the wall.
Page 56 Weather protection Setting up roof structure with wood Front bracing Front bracing can be installed by using 2 x 4” (38 x 89mm) in top angle brackets located on the back of the front vertical posts. 1 1/2” (12.7mm) nails are recom- Insert the back vertical post into the bottom support full mended.
Page 57 Weather protection Note: Installing tarp over a roof tubes kit A diagonal brace is required every two bays. Also, a bay can be left opened as long as diagonal bracing is set on both sides Install 2 x 4” (38 x 89mm) at the end of the 48” (1,22m) of the opening.
Page 58: Monorail
Monorail Monorail Install the weather protection M2 bottom support. Install the weather protection M2 back post on the bottom support pocket. Slide 10’ (3,05m) outrigger into top of back post head. Install the weather protection M2 front post on the bottom support pocket. Slide the outrigger into front post at the proper distance (longer outrigger required for setup with more than 3 planks).
Page 59 Monorail Monorail capacities as per installation distance Distance "A" Distance 20" 30" 40" 50" (50,8cm) (76,2cm) (101,6cm) (127cm) Capacity (lb) 1000 Monorail Capacity (kg) capacities Monorail capacities as per installation distance (each monorail) Capacity (lb) 1000 Distance"A" Distance Capacity (kg) 20"...
Page 60: Forward Extension
Forward extension (3,1m) A,E (4,9m) A,B,D,E (6,7m) A,B,C,D,E Required parts Weight Required parts Weight Required parts Weight Extension 29" x 14' 716 lb Extension 29" x 14' 716 lb Extension 29" x 14' 716 lb (74 cm x 4,3m) (325 kg) (74 cm x 4,3m) (325 kg) (74 cm x 4,3m)
Page 61: Hoist System
Hoist system Hoist specifications Winch "Pull master" Barrel diameter = 7" (178mm) Flange diameter = 13 1/2" (343mm) Barrel length = 8" (203mm) Cable 3/8" (9.5mm) dia. x 250' (76m) @ 4 000 lb (1 815 kg) 3/8" (9.5mm) dia. x 350' (107m) @ 3 600 lb (1 633 kg) Power pack system Door Movable guard rail...
Page 62: Plank Safety & Cross-Boxes
Plank safety & cross-boxes Plank safety prevents planks from tipping, lift- Cross-boxes provide a means of installing auxiliary outriggers. ing and slipping. Remove lock pin and plank stop pin from two outriggers. Remove plank stop pin. Slip cross box on back and front of outrigger. Repeat for next outrigger. Slip plank safety over outrigger Slide cross-members to mid position position between two planks.
Page 63: Transportation
Transportation NOTE: Weight limitations may vary from state to state.
Page 64: Trailer
Trailer Attachment Guiding support The 15’ (4,6m) trailer can be used for accessories transportation or bracket (4) bracket the 14’ (4,3m) motorized unit. For motorized unit loading follow the next steps. Remove the attachment bracket (4) provide for attaching the motorized unit base.
Page 65: Maintenance
Maintenance DAILY WEEKLY Observe cylinders and all other hydraulic components, checking for leaks and wear of Check level of base and tower. hydraulic hoses. Verify hydraulic oil level. Tank should be between 3/4 and 7/8 full with cylinders Check gasoline level. in closed position.
Page 66 Clean up and grease hooks at pivots. have it repaired by authorized distributor. NOTE: In case of doubt, consult Hydro Mobile Inc. or refer to a certified welder. Clean jack screws and lubricate. Check for paint damages, touch-up or repaint unit Clean outriggers.
Page 67 Maintenance Relief valve adjustment To provide optimal system performance (speed), the hydraulic system must be set to run at 2 800 psi (19 305 Kpa). UP hose Identify valve corresponding to cylinder(s) that is not operating at normal speed. Dismantle the adjusment screw. Clean all components with a solvant.
Page 68 Maintenance Control lever adjustment To provide optimal system performance (speed), control must be set in a neutral position (vertical) so that hydraulic valves open fully. Allen key bolt (2) Stop the engine. Untighten the Allen key bolts (2) at valve connection. Untighten the lock nuts.
Page 69: Job Equipment Check List
Job equipment check list Miscellaneous 5' (1,5m) top outrigger 7' (2,1m) bottom outrigger Wall Tie Accessories 10' (3,05m) long outrigger Adjustable anchor male Beam clamp anchor Cross box Adjustable anchor female Tower bracket Plank safety support Reusable anchor Standard wall mount Plank end guard rail Welded anchor Wall mount extension...
Page 70: Layout Check List
Layout check list Distributor Contact Project name Project description Blue print Floor plans Elevations Details if required Structure plan if required Roof plan if required Have you filled the project request form ?
Page 71: Tools & Suggested Spare Parts
Tools & suggested spare parts Suggested spare parts Bolt 5/8" x 1 1/2" nc GR5 Bridge link plate (15,8 mm x 38,1 mm) Bridge link plate pin ass'y Nut 5/8" nc GR5 (15,8 mm) Adapted pin Tower junction set M2 ass'y Clevis pin 3/8"...
Page 72: Equipment Training Check List
Equipment training check list Personal training record - Hydro Mobile equipment Precedural check list ( by instructor / installer) Date of training Lifting / handling and placing of units(s) Base installation procedure Loacation of training Bridge assembly, placement and installation...
Page 73: User Training Record Check List
User training record check list User training record - Hydro Mobile equipment Procedural checklist Date of training Hazard recognition & dealing with them Electrical exposures and considerations Location of training Falls and falling objects Proper usage of scaffold Duration of training...
Page 74: Hydraulic Schematic
Hydraulic schematic...
