Teletek electronics Natron Test Kit Manual

NOTE: Read carefully this Installation Instructions before starting operation with the test
kit! This manual is subject to change without notice!
ATTENTION!
Natron Test Kit is designed and operates according the international standards required
to meet the mandatory requirements of Radio Equipment Directive (RED).
IMPORTANT NOTES BEFORE STARTING THE TEST
• Natron Test Device (the probe) is enrolled to the test panel Natron-T by the
manufacturer during the final assembly of the test kit.
• The default set radio frequency channel for test is "Channel 0". There are 6 pairs of
available frequency channels for performing test. If a several Natron systems are
expected to operate at a single site it is obligatory to set their operation at different
frequency channels.
• Make complete site survey for presence of other wireless systems/devices emitting
radio signals at 868MHz operating frequency! If there are other systems/devices
operating on 868MHz they can disturb the proper operation of the whole Natron
system.
• Perform the preliminary test using Natron Test Kit while all present wireless
systems/devices on the site are turn on and emit signals according their operation
functionality. During the test all doors and windows at the site must be closed.
• Check the local regulations, standards, and work practices for installation of wireless
systems/devices – they may vary from country to country and you must consider them
before starting the installation of Natron wireless system.
1. General Description
Natron Test Kit is a survey test equipment for providing preliminary radio frequency test at the
protection site, where Natron Wireless Fire System is planned to be installed. The kit is delivered
in a portable plastic suitcase with comfortable handle and option for locking the both double throw
latches. The testing equipment is well protected in a customized foam inserts into the suitcase.
Natron-T is a test panel. It is mounted in a compact plastic enclosure box. The information for the
radio test and determined quality of the radio signal is presented on an LCD text display. A dipole
SMA type antenna is supplied with the equipment to ensure wide covering range of the test panel
and stable communication with the Natron testing device during the test procedure. During the
test the Natron-T must be placed at the chosen place for the Natron WE-x wireless expander or
Natron WR wireless repeater.
The testing device (probe) is equipped with a special conduit-box joint for connection to the
provided extension tubes. The purpose of the probe is to imitate operation of the wireless Natron
device at the chosen place for mounting, and thus to test the quality of the radio signal between
the device and the test panel.
Natron Test Kit complies to EN 54-25.
Natron Test Kit
Wireless survey kit for
preliminary testing of the
radio range and the signal
quality of Natron wireless
system
