- Page 1 CENMATE HDMI Over Ethernet Extender Over Cat5/6/7 HD50POC-4K60 User manual Video bandwidth 18Gbps Size of products 61x88x18mm Video resolution 4K@60Hz 4:4:4 Product weight TX:160g / RX:155g Power consumption 3.84W...
-
Page 2: Precautions Before Using The Product
Precautions before using the product While using this product, there may be problems with misuse, modification, wrong installation, and use of the product, and the headquarters is not responsible for compensation for this. The headquarters will not be responsible for the failure of HDMI supporting devices (HDMI players,display devices) due to the product. -
Page 3: Product Name
Features of the product Bandwidth supports HDCP(High-bandwidth Digital Content Protection) to enable stable Play of Digital Content with video copyright Protection technology. 4K resolution supports up to 50M/1080p resolution up to 50M. It provides IR infrared transmitter and receiver, and can remote-control the display device located in the remote area by remote control. -
Page 4: Components Of Product
Receiver Name Functional description Connect with HDMI port on TV or monitor or beam projector. Connect the LAN line connected to the transmitter. The LED lights up under normal power supply. Transmitter, receiver, normal flicker. LED in signal transmission Firmware update port Connect the IR RECEIVER cable. -
Page 5: Product Specifications
Product specifications... -
Page 6: Product Diagram
Product diagram... -
Page 7: Using The Product
Using the product Connect the Direct UTP cable (Cat5e/6/7) to the RJ45 port of the PRODUCT's HDMI RX(receiver),TX(transmitter). Connect HDMI source instrument such as PC, set-top box,etc.to HDMI TX(transmitter) body with HDMI cable within 5M length. Connect display devices such as HDMI monitor,TV, projector to HDMI RX(receiver) body.
