- Page 1 HDMI 1080P Extender 50M Over CAT 5/5e/6 with EDlD +IR Remote control+POC 60HDC User Manual HDMI version: 1080P Data transfer rate: Max 10Gbps Product size: 82.4x45.5x22mm Product weight: TX:120g / RX:120g...
- Page 2 Reminder when using the product 1. Cenmate-60HDC product and expose it to rain or excessive humidity, it may result in malfunction or breakdown of the product, and may result in fire and electric shock councilors due to electrical shorting.
- Page 3 The CENMATE-60HDC applies IR infrared sensor, enabling Remote Control of display units located in Remote areas. The CENMATE-60HDC HDMI Extender, which employs IR infrared sensors, allows you to use high-quality digital image/acoustic signal HDMI Extender products with UTP cables that are commonly used in business, home, and factory facilities.
- Page 4 Product specifications Name CENMATE-60HDC Interface 1080p/1080i/720p/576p/480p/480i HDMI resolution Supported video color bit Deep Color 24bit/36bit LPCM/Dolby -AC3/DTS7.1/DSD Supported audio format Extended UTP cable distance Within 10M (as per AWG24 specification) Output HDMI distance Within 10M (as per AWG24 specification) Input HDMI distance 6.75Gbps~10.2Gbps...
- Page 5 HDMI RX(receiver) of CENMATE-60HDC product,RJ-45 port of TX(transmitter). 2. Connect HDMI instrument to HDMI TX(transmitter) body with HDMI cable within 15M length. 3. Connect display devices such as HDMI monitor,TV,projector to HDMI RX(receiver) body. 4. For CENMATE-60HDC,connect the DC 5V adapter built-in to the product body.
- Page 6 Product diagram Mount product wall It can be fixed on the wall or desk etc by using the holes of the two lecrails of the product. (No screws are available.) (Product images may vary.)
