DAIKIN ROOM AIR CONDITIONER
OPERATION MANUAL
MODELS
FTXC20EV1B
FTXC25EV1B
FTXC35EV1B
FTXC50EV1B
FTXC60EV1B
FTXC71EV1B
Note:
Illustrations in this manual are for explanation to user only and may differ from the actual machine.
These are subject to change without prior notice for the development of future product.
R32 SPLIT SERIES
Operation Manual
Handset Wireless
3P621306-4 D
English
Advertisement
Related Manuals for Daikin FTXC20EV1B
Summary of Contents for Daikin FTXC20EV1B
- Page 1 3P621306-4 D DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL R32 SPLIT SERIES MODELS Operation Manual English Handset Wireless FTXC20EV1B FTXC25EV1B FTXC35EV1B FTXC50EV1B FTXC60EV1B FTXC71EV1B Note: Illustrations in this manual are for explanation to user only and may differ from the actual machine.
- Page 2 ENGLISH Safety precautions Read the precautions in this manual This appliance is filled with R32. carefully before operating the unit. • After reading, keep this manual in a convenient place so that you can refer to it whenever necessary. If the equipment is transferred to a new user, be sure also to hand over the manual.
- Page 3 ENGLISH CAUTION • Be aware that prolonged, direct exposure to cool or warm air from the air conditioner, or to air that is too cool or too warm can be harmful to your physical condition and health. • Do not use the air conditioner for purposes other than those for which it is intended. Do not use the air conditioner for cooling precision instruments, food, plants, animals or works of art as this may adversely affect the performance, quality and/or longevity of the object concerned.
- Page 4 Electrical work. For power supply, be sure to use a separate power circuit dedicated to the air conditioner. • System relocation. Consult your Daikin dealer about remodelling and relocation. • Precautions when using the wireless LAN. Do NOT use near: •...
- Page 5 ENGLISH REMOTE CONTROLLER OVERVIEW IR Signal Transmitter • To transmit signal, aim the Display (LCD) transmitter to the indoor unit. • Display the current settings. Note that in the condition (This illustration shows where there is an obstacle the full display of the LCD that blocks between the panel, including functions for transmitter and the indoor...
- Page 6 ENGLISH Preparation Before Operation Accessories To set the batteries The following accessories are included. 1. Remove the back cover by sliding downwards. 2. Insert two dry batteries (LR03:AAA). Drywall Remote Battery 3. Replace the back cover. screw Controller Holder Position correctly! Disposal Requirements The batteries supplied with the controller are marked with this symbol.
- Page 7 ENGLISH Preparation Before Operation To set the clock 1. Press button. • blinks on the LCD. 2. Press to set the clock to present time. • Holding down button rapidly increases or decreases the displayed time. 3. Press button. • Point the remote controller at the indoor unit when pressing the buttons. •...
- Page 8 ENGLISH Note Operating Mode Description COOL The air conditioner cools down the room by releasing the heat to outdoor unit. The air conditioner indoor unit will run in fan only. The air conditioner operates to control the room humidity by regulating the indoor unit fan speed.
- Page 9 ENGLISH Adjusting the Airfl ow Direction To change the air fl ow direction 1. Press button. • is displayed on the LCD. To set the fl ap at the desired position 1. Press button when the flap reached the desired position. ...
- Page 10 ENGLISH SLEEP Operation To start SLEEP operation 1. Press button. • is displayed on the LCD. • LED Indication lights of unit will be dimmed down. To cancel SLEEP operation 2. Press button. • will disappear from the LCD. Notes on SLEEP operation Set Temperature •...
- Page 11 ENGLISH TIMER Operation To use OFF TIMER operation • Ensure the clock setting is set to present time (refer to method to set the clock under preparation before operation). 1. Press button. • will be displayed on the LCD and blinks.
- Page 12 ENGLISH Wireless LAN Connection For more information and FAQ refer to: app.daikineurope.com • Customer is responsible for providing: To install the ONECTA app • Smartphone or tablet with minimum supported 1. Open: version of Android or iOS, specified on Google Play for appliances us ing Android. •...
- Page 13 ENGLISH 3. Check the ON/OFF and timer LEDs on the indoor unit display. If ON/OFF LED... …and timer LED… …then wireless LAN is… blinks blinks not connected ON/OFF LED is off blinks in 0.5 second running and ready to connect TIMER LED to the home network via WPS interval...
- Page 14 ENGLISH 3. Press to confirm the selection. • Result: is blinking. The timer LED and ON/OFF LED are blinking simultaneously. 4. Open the ONECTA application on your smart device and follow the steps on the screen. • Result: If the connection to your smart device is successful, the timer LED is blinking in 1.0 second interval and the ON/OFF LED is off.
- Page 15 ENGLISH Fault Diagnosis To perform error code diagnosis 1. Press and hold button for 5 seconds. • blinks. 2. Press to check on the error code. • Keep pressing on the button until a long “beep” acknowledgement heard from the indoor unit. To exit from error code diagnosis 3.
- Page 16 ENGLISH Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fi ns of the indoor unit. If you touch those parts, this may cause an injury. •...
- Page 17 ENGLISH Titanium apatite deodorizing fi lter The titanium apatite deodorizing filter can be renewed by washing it with water once every 6 months. We recommend replacing it once every 3 years. Filter frame 1. Take off the titanium apatite deodorizing filter Air fi...
- Page 18 Head offi ce: Zandvoordestraat 300, B-8400 Oostende, Osaka Umeda Twin Towers South, 1-13-1, Umeda, Belgium Kita-ku, Osaka, 530-0001, Japan http://www.daikin.com P.O.Box 18674, Jebel Ali Free Zone, Dubai-UAE Email: info@daikinmea.com Web: www.daikinmea.com Lot 60334, Persiaran Bukit Rahman Putra 3, Taman Perindustrian Bukit Rahman Putra,...
