HYDRAULIC operation
Insert the protections (02) onto the 4 brackets (01). Secure to the radiator the two upper brackets (01) using screws 04, all the way
Fig. 1.1
Soho
01
x1
x4
02
Installation kit
the package includes:
1
Bracket
2
Bracket protection
3
Wall-mounted support
4
TE M8 screw
5
Cover
6
Décor covering (upon
request)
Phase 1
Once you have identified the place of installation of the radiator,
04
mark the fixing holes for the supports (03), considering the
dimension specified in fig.1.2, and placing them at distance A
depending on the number of elements
(see Tab. 1). Maximum height B measured on the radiator see fig.
1.3.
01
02
Tab. 1
No. of
3
4
el.
A
0
68
136
Measurements are expressed in mm
Version: VERTICAL WALL MODEL
03
x4
x4
Screw in without locking the other 2 lower
brackets as shown in fig. 1.1.
Fig. 1.3
B
122
5
6
7
8
204
272
340
04
05
x4
x4
to the mechanical stop.
A
03
9
10
11
408
476
544
02
06
x1
12
612
