Summary of Contents for Knuth KB 32 SFV PRO
- Page 1 SAVE THIS MANUAL FOR FUTURE REFERENCE ATTENTION:READ THIS MANUAL CAREFULLYE BEFORE MACHINING HIGH EFFICIENCY INTELLIGENT HEAVY DUTY DRILLING MACHINE MODEL : KB 32 SFV PRO OPERATION MANUAL MAX.DRILLING DIAMETER31.75mm MAX.TAPPING DIAMETER Art. Nr.: 170464...
- Page 2 20、Before further use of tool, a guard or other part that is damaged should be carefully checked, so that it should be properly repaired or placed. 21、When cutting large diameter holes, keep speed slower. OPERATION MANUAL KB 32 SFV PRO Page 1 of 15...
-
Page 3: Table Of Contents
CONTENT 1. Summary…………………………………………...……………….………2 2. Technical parameters…………………………………………………..……2 3. Points for attention……………………………………………….………..2 4. Driving system………………………………………………………………3 5. Electric system…………………………………………………...………… 4 6. Install and adjust………………………………….………………..………..7 7. Lubrication…………………………………………………..………………8 8. Trouble shooting……………………………………………………………9 Head pares diagram………………………………………………………...10 …………………………………Certificate of Inspection ………………………………………………Packing List Forgive that there are no changes in the operation manual when the machine will be a little variation in the future. -
Page 4: Summary
Thank you for purchasing the bench strong drilling machine model: KB 32 SFV PRO。 In order to keep the machine in good working condition,please operate and maintain the machine correctly.Before operating the machine,please read his manual carefully. 1、SUMMARY The drilling machine of this model is designed for drilling, reaming and boring on ferrous and boring on ferrous and non ferrous metals of holes belowφ31.75mm in diameter. -
Page 5: Driving System
When making adjustment of the working table. Downwards or upwards first it loosen the adjustable tightening handle (Fig, I) of the bracket, then have the table raisedor lowered on the desired position with the lifting hand lever and re clamp the bracket. 3.4 After a hole has been drilled to the required depth, release the hand lever to have the spindle sleeve, under the action of a coil spring, returned to its original position. -
Page 6: Electric System
5、ELECTRIC SYSTEM (Fig, Ⅲ) The electrical system is consisted of a motor, a on-and-off switch and power cord wire. It is controlled to start or stop by switch. Loading is only one motor. The power supply must be in keeping with the motor as appeared on the packing carton, circuit control is Fig Ⅲ. - Page 7 OPERATION MANUAL KB 32 SFV PRO Page5 of 15 U1 Touch screen SB5+HL3 Reset Rotary HL2 Power indicator light SB4 Reversal point move Mains SB2 The spindle start SB1 E-stop SQ4 Spindle eye guard safety SB3 The spindle stop SQ2 Upper spindle...
- Page 8 Electric seri Rules can be paginati locati symbols type specification brand briefly numb Schneide V02C 12A Mains switch Main power Schneide GV2-ME14C/6-10A protection GV2-ME02C/0.16- Cooling pump Schneide 0.25A protection Transformer Schneide iC65N 1P D 1A protection Spindle motor Schneide iC65N 1P D 1A cooling fan protection CANNY...
- Page 9 Belt cover safety QKS8 OUKCH protection drive SYDL 380-50A SINYO Touch screen SYSG-T35-LP SINYO XN-V1.0 The spindle speed Emergency stop B/C/4/ CS AR-01V024 Pizzato relay 130SFM-H10030F 3KW Spindle motor SINYO 6A 3000RPM DB12TH 0.04KW 0.23A Nan Tong Cooling pump 2800r/min Nan Wei Main motor radiator 0.022KW 0.1A...
-
Page 10: Install And Adjust
OPERATION MANUAL KB 32 SFV PRO Page 7 of 15 6、INSTALL AND ADJUST The machine had been ass cabled before left factory Users could fix the machine on the base or not do so. If you want to fix the machine,you can drill holes in the base according to the size of base table.Then tighten the drill press on the base by bolt. -
Page 11: Lubrication
OPERATION MANUAL KB 32 SFV PRO Page8 of 15 7、 LUBRICATION (Fig, Ⅳ) renewals 7.1The bearing should be greased regularly and annually. 7.2 Lubrication friction parts are available in other oil spindle pulley spline housing injection. 7.3 After the end of the day, all should wipe the table, column surface, and then the oil. -
Page 12: Trouble Shooting
OPERATION MANUAL KB 32 SFV PRO Page 9 of 15 8、TROUBLE SHOOTING TROUBLE PROBABLE CAUSE REMEDY 1、In correction belt tension 1、Adjust belt tension Noisy 2、Loose spline pulley 2、Tighten spline nut Operation 3、Loose motor pulley 3、Tighten setscrew in pulley 1、Incorrect speed 1、Change speed... -
Page 13: Head Pares Diagram
KB 32 SFV OPERATION MANUAL Page 10 of 15 9、Head pares diagram HEAD PARTS DIAGRAM... - Page 14 KB 32 SFV OPERATION MANUAL Page11 of 15 Name Number Name Number HEAD PARTS LIST： Spindle Cover Bearing Washer Bearing Bvel lock Screw Sleeve Lock Bearing Washer stroke dog Ring Nameplate Screw Screw Pinion shaft Screw Screw Sleeve Screw Spring Washer Cover Screw...
- Page 15 KB 32 SFV OPERATION MANUAL Page12 of 15 Name Number Name Number Mounting plate Spring Screw Ring Bearing shaft Retaining ring pulley Friction plate pulley Bearing Spring Sent belt Pulley Cover belt guard knob Bearing Washer Retaining ring Retaining ring Bearing spacer Bearing...
- Page 16 OPERATION MANUAL KB 32 SFV PRO Page13 of 15 BASE＆COLUMN PARTS DIAGRAM...
- Page 17 OPERATION MANUAL KB 32 SFV PRO Page14 of 15 BASE＆COLUMN PARTS LIST： Name Name Numb Base Column Washe Ring Bearing Safety loop Rack Secure ring Washer Screw Screw Collar stop Screw Gear Gear table support Screw Worm Circle Bearing Ring...
-
Page 18: Certificate Of Inspection
Certificate of Inspection KB 32 SFV PRO Page1of4 HIGH EFFICIENCY INTELLIGENT HEAVY DUTY DRILLING MACHINE MODEL：KB 32 SFV PRO Certificate of Inspection MAX.DRILLINGDIAMETER： 31.75mm MAX.TAPPING DIAMETER： SERIAL NO: Certificate of Inspection KB 32 SFV PRO Page2of4... - Page 19 The machine had been tested according to the specified standard JB/T5245.2-2006 and technical requirements ， and found satisfactory for dispatch。 Director： Chief of Inspection Department： Date： Attached ：Test Chart Certificate of Inspection KB 32 SFV PRO Page3of 4...
- Page 20 300measuring Plane degree of table unite：0.05 working face plane or concave Outside the spindle Ⅰ: 0.015 taper hole axis Ⅱ: a)0.020 b)0.035 a dial runout Certificate of Inspection KB 32 SFV PRO Page4of 4...
- Page 21 (α≤90°) perpendicularity b)0.10/300 a)0.10/300 verticality of the (α≤90°) working b)0.10/300 table spindle axis Spindlesleeve a)0.07/100 moving on base b)0.07/100 surface vertical Spindle sleeve moves a)0.07/100 vertical work b)0.07/100 surface Packing List KB 32 SFV PRO Page2of 1...
-
Page 22: Packing List
HIGH EFFICIENCY INTELLIGENT HEAVY DUTY DRILLING MACHINE MODEL：KB 32 SFV PRO Packing List MAX.DRILLINGDIAMETER： 31.75mm MAX.TAPPING DIAMETER： Serial No : Packing List KB 32 SFV PRO Page2of 2... - Page 23 Serial No： 1040mm×640mm×2050mm Packing dimension：（L×W×H） 350kg G.W.： 310kg N.W.： Name Model Quantity Remark Machine KB 32 SFV PRO Belt in the machine B-1118Li Crank SB6532-05 Drill chuck 5-20mm/JT3 Arbor MT3/JT3 Taper sleeve MT3/MT2 Drift Z4120-F03 Operation manual / Certificate of Inspection /Packing list...
