Man & Machine CoolMIR v2 Quick Start Manual

CoolMIR v2 BlackBerry
Congratulations on your purchase of the CoolMIR keyboard for the RIM BlackBerry. This sophisticated
keyboard is the culmination of 2 years of research and development. Each team member at Man &
Machine proudly stands behind our company's coolest innovation. Don't be surprised when all your
friends and colleagues say to you "That's cool" and you can reply, "No, it's the CoolMIR". Be sure to
check out all the cool keyboards and mice at www.man-machine.com.
IF YOUR BLACKBERRY IS CONNECTED TO A BLACKBERRY ENTERPRISE
•
SERVER (BES), PERMISSION MUST BE OBTAINED FROM THE BES
ADMINISTRATOR TO RUN THE COOLMIR SOFTWARE.
or higher. For instructions on how to allow the CoolMIR driver on the BES please refer
to the "BES Setup Instructions
BlackBerry visit
04219").
PLEASE CHARGE THE COOLMIR KEYBOARD BATTERY FOR AT LEAST
•
TWO HOURS BEFORE USE.
battery, plug the USB cable B-mini connector to the Mini USB Input Port on the CoolMIR and the A connector of
the USB cable to your PC or AC adaptor. The CoolMIR will have 15 hours continuous usable battery life when it
is fully charged.
You will need to have your BlackBerry software and the BlackBerry Desktop
•
Manager loaded on your PC. You will need to download software to your
BlackBerry using the RIM Desktop Manager in order to enable the CoolMIR
Keyboard.
Quick Installation Guide
1. Go to www.man-machine.com/coolmir.htm
it on your computer. Refer to the "Installation Guide" in the manual for step-by-step instruction on how to install the software or
follow the steps below.
2. Save any important information from the handheld to the PC using the Backup and Restore tool before installing the software on
your handheld. (Open the Desktop Manager. Connect your handheld to your PC. Double-click "Backup and Restore" in the
Desktop Manager. To backup everything on your handheld, click the "Backup" button. In the "Select File for Full Backup"
window, select the name and location of the file as desired and click "Save".)
3. In the Desktop Manager, double-click "Application Loader". The "Welcome to Application Wizard" window appears. The
handheld must be connected before you can load new software.
4. Click "Next" to start the process of loading new software onto your handheld. A "Retrieving Handheld Configuration" window
appears on your PC to indicate that the Application Loader is connecting to your handheld and is reading your handheld's
configuration. Wait until initialization is complete and the dialog box disappears. The "Handheld Application Selection" window
appears, displaying the applications that you can choose to download to your handheld.
5. Click on the "ADD" button. Drop down the "LOOK IN BOX" and select the folder where the CoolMIR program is located and
Double-click on the file "CoolMIR.ALX".
6. Select the check boxes next to the names of the applications you want to load and click "Next". Any applications that do not have
a checkmark beside them will be erased from the handheld (even if you have them currently loaded).
7. The "Completing The Application Loader Wizard" window appears, displaying the application that will be downloaded to your
handheld. Verify that the information is correct and click "Finish".
8. The "Load Progress" dialog box appears and the new files are added to your handheld. When loading is complete, the "Loading
Operation Was Successful" box will indicate whether loading was successful. Click "Close" to return to the Desktop Manager. If
Quick Start Guide
" (pages 11-15)
www.blackberry.com/knowledgecenterpublic
CoolMIR uses the same charger cable as the BlackBerry. To charge the
and download the latest CoolMIR driver and the user manual. Unzip the file and save
TM
Keyboard
The BES must be 4.0
. For instructions provided by RIM
(Search for "KB-
