iXT™ Iris Recognition System

User Manual (v.1.4.5)

Applies to firmware versions d20201*

October 2020

EyeLock, LLC.

321 West 44th Street, Suite 702

New York, NY 10036

USA

Phone: (855) EYELOCK / +1 855-393-5625

sales@eyelock.com

herein, or discontinue the product described at any time without notice or obligation.

Intuitive video preview for face positioning

Internal automatic motorized tilt cameras

LAN / Wi-Fi / USB / RS485 / RS232

Dual iris capture and recognition

or support@eyelock.com.

Table of Contents

Need help?

Do you have a question about the iXT and is the answer not in the manual?

Questions and answers

Summary of Contents for eyeLock iXT

Page 1 Phone: (855) EYELOCK / +1 855-393-5625 Contact us: sales@eyelock.com or support@eyelock.com. Copyright 2020. EyeLock LLC reserves the right to make changes to the documentation, specifications and features shown herein, or discontinue the product described at any time without notice or obligation.
Page 2 The iXT captures high quality iris images in compliance with ISO 19794-6 2011 and ISO 29794-6 standards. The front facing 5” LCD touchscreen serves to display the video of the user’s face image for fast, easy and highly natural positioning for proper iris image capture.
Page 3: Key Features
2. Key Features • Fully integrated with EyeLock Identity Suite (EIS) server application for device management, firmware updates and database synchronization. • Supports EIS Network Matcher functionality. • Intuitive LCD face display positioning for fast, simple, and natural iris user experience •...
Page 4 The factory shipment box of iXT contains the following: 1) iXT device 2) iXT back mounting plate with M3 screw (not security type) 3) Power adaptor (IEC C13 female) with NEMA 5-15 (USA) power cord (IEC C14 male) 4) Access control cables for Wiegand (2), RS 485, RS 232, TTL (2) and dry contact relay with push-in connectors for device and pig tails for external connections 5) Diode.
Page 5 EIS is a licensed software application. It will operate unlicensed for up to 60 days. 4) On the iXT LCD screen, click on Settings → Network and set the device to a Static IP address on the same network as EIS. For example, if the EIS computer is 192.168.4.15 with subnet mask 255.255.255.0, then configure iXT with IP 192.168.4.100 with subnet...
Page 6: Mounting Instructions
The recommended mounting height for the iXT is approximately 60” (150 cm) from floor to the center of iXT. The device can be installed at a slightly different height optimized for the height of the average user of the facility. The recommended placement is at, or at slightly below the eye level of an average user.
Page 7 6. Basic Iris Recognition Operation iXT captures and recognizes the user’s iris and face images automatically. 1) Position yourself facing straight at the device. When the device detects your movement within 1 meter range, it initiates the image capture sequence. A...
Page 8: Technical Specifications
7. Technical Specifications Embedded CPU Cortex A9 quad core ARM Iris on-board algorithm EyeLock iris template extraction and matching algorithm for encoding and matching Face on-board Contact Eyelock for more information. algorithm for face encoding and matching Party integration API RESTful type API for 3 party integration.
Page 9 Alternative 12VDC +/- 5%, 42W power adapters may be used. Average power consumption is about 14 Watts. External POE+ splitter adapter may be used – contact EyeLock for the recommended part number. www.eyelock.com iXT User Manual, v.1.4.5...
Page 10 8. iXT Exterior Views and Electrical Connections iXT Front View Iris camera Face camera NIR illuminators NIR illuminators LCD display Microphone Speaker Smart card reader iXT Bottom View Micro-USB (for connection to PC host) Kensington lock Reset Lock Screw www.eyelock.com iXT User Manual, v.1.4.5...
Page 11: Rear View
Rear View Rear View Gang Mounting Screw Hole Wall Mounting Screw Hole Tamper Switch Tripod Socket (1/4-20) iXT Rear Connections Block View RS-485 Termination Resistor Switch Power Input (+12VDC) LAN/RS45 www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved...
Page 12 Rear Connections Block Diagram iXT Wiegand Input Wiring Diagram Use the diagram below to connect external Wiegand input card readers and controllers. Note: iXT ships with one set of Molex-type pigtail connectors for access control equipment. Contact support@eyelock.com for the exact type if wishing to purchase additional connectors.
Page 13 Wiegand Output Wiring Diagram Use the diagram below to connect iXT Wiegand output to access control panels. iXT Dimensions, in mm www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 13 of 86...
Page 14: Manual Firmware Upgrade
Unzip the file and copy both files (*.bin, *.info) to root folder of the USB stick. • Insert the USB stick to the bottom of iXT USB Type A socket while iXT is powered on. • On the LCD screen, select Setting → Network → USB Memory and tap USB enable.
Page 15 • If files are accepted, click OK, and iXT will upgrade the firmware and reboot automatically. Note: this type of upgrade via device menu can ONLY be performed to a NEWER version than what is installed in the device. Upgrade via EIS allows installing any version, newer, older or the same.
Page 16 10. Configuration Settings Accessible via LCD Display Note: the iXT is normally configured via EIS server. The settings entered via the LCD display will be overwritten by the settings provided by EIS, with exception of several settings such as Static IP address.
Page 17 6.1 Log Info 3.4.1 Use screensaver 6.2 Log List 3.4.2 Time display position 6.3 Log Search 3.4.3 Wait time 6.4 Delete all logs 3.5 Pop-Up Timeout www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 17 of 86...
Page 18 ② Notice Icon of Face mode is ⑥ Clock display operating ③ ⑦ Notice Icon when iXT is busy with EIS Settings Button for system configuration commands ④ Notice Icon of IP network is connected www.eyelock.com iXT User Manual, v.1.4.5...
Page 19 Configuration for screen display Authentication Configuration for authentication method and T&A Mode Configuration for recognition operations Information of saved log and log search viewer www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 19 of 86...
Page 20 Set motion detection delay time from last recognition operation Motion detection Select motion detection enable/disable and detection type for starting recognition Debug Select Debug mode enable/disable (captures image stream for off-line analysis) www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 20 of 86...
Page 21 Box + Large notices Select tracking box + large guidance text type UI display 11.1.2. Configuration → Enroll notices timeout Default timeout is set to 3 sec. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 21 of 86...
Page 22 Video Analytics Select video analytics for motion detection to detect user presence in front of the device (default) Select TOF sensor for motion detection www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 22 of 86...
Page 23 11.1.6. Bio → Security Level Iris only Only Iris only recognition mode is supported with this version of the firmware. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 23 of 86...
Page 24 Enroll: either eye Select enable/disable for either eye enrollment mode (default: ON) Min distance Set min distance for Iris recognition, in cm (default: 35) www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 24 of 86...
Page 25 11.1.9. Bio → Iris → Recognition false accept rate (FAR) Default set at 10 . Note: decreasing Recognition FAR may increase false reject rate (FRR). www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 25 of 86...
Page 26 Enable/Disable fake face detection (e.g. anti-spoofing) Note: With Fake face enabled, it may take a little more time to recognize face than if disabled. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 26 of 86...
Page 27 11.1.12. Bio → Cover glass IR transmission (%) 11.1.13. Sound Speaker volume Set speaker volume for instruction sound and interphone voice MIC volume Set microphone volume for interphone voice www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 27 of 86...
Page 28 11.1.14. Sound → Speaker Volume 11.1.15. Sound → MIC Volume Identical to settings for speaker volume www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 28 of 86...
Page 29 Note: the time of the device is synched by the EIS server as soon as the device is connected to the EIS server. 11.1.17. Date & Time → Manual Setup www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 29 of 86...
Page 31 Recognition start sensor monitors an input port and causes device to start recognition procedure on an event (e.g. pressing button) basis. • LED feedback sensor activates ACU authentication feedback wait function. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 31 of 86...
Page 32 EFIO Relay 1 Select to use EFIO Relay 1. EFIO is an optional expansion accessory. EFIO Relay 2 Select to use EFIO Relay 2 www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 32 of 86...
Page 33 Authentication + T&A Event Select door open for authentication plus T&A event Disabled Select door open disable 11.2.3. Door → Duration (sec) Setting the Duration time of door open function www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 33 of 86...
Page 34 EFIO GPI2 Select to use EFIO GPI2 as RTE (Exit button) 11.2.5. Door → RTE Type Select type of door sensor Normally Open Normally Closed www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 34 of 86...
Page 35 Select to use EFIO GPI1 as RTE (Exit button). EFIO is an optional expansion accessory. EFIO GPI2 Select to use EFIO GPI2 as RTE (Exit button) www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 35 of 86...
Page 36 Select type of door sensor (normally open or normally closed). 11.2.8. Door → Hold open period (sec) Setting the hold open period (sec) for alarm if the door is not closed. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 36 of 86...
Page 37 EFIO GPI2 Select to use EFIO GPI2 as RTE (Exit button) 11.2.10. Door → Alarm Sensor type Select type of Alarm sensor www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 37 of 86...
Page 38 When physical tampering is attempted, all the data and settings are deleted 11.2.12. Door → Interlock Sensor Not used Select not to use Interlock sensor GPI1 Select to use GPI1 as Interlock sensor www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 38 of 86...
Page 39 11.2.13. Door → Interlock Sensor type Select type of Interlock sensor Normally Open Normally Closed 11.2.14. Door → Prohibition Sensor Not used Select not to use Prohibition sensor www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 39 of 86...
Page 40 Select type of Prohibition sensor Normally Open Normally Closed 11.2.16. Door → Recognition start sensor Not used Select not to use Recognition start sensor www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 40 of 86...
Page 41 11.2.18. Door → LED feedback Sensor Not used Select not to use LED feedback Sensor GPI1 Select to use GPI1 as LED feedback Sensor www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 41 of 86...
Page 42 Select to use EFIO GPI2 as RTE (Exit button) 11.2.19. Door → LED feedback Sensor type Select type of LED feedback Sensor. Normally Open Normally Closed iTEMP Thermal Sensor www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 42 of 86...
Page 43 Select enable/disable to detect whether the user wears a mask Display Thermal body temp Select to display body temperature to users during their authentication. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 43 of 86...
Page 44 Select if Celsius or Fahrenheit scale is used. Thermal Sensor → Alarm temperature 11.3.2. Select the desired temperature threshold for alarm action. 11.3.3. Thermal Sensor → Alarm action www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 44 of 86...
Page 45 LED Signal cause the EF-IO relays to work upon authentication to turn on LED light connected to the relays. NOTE: LED signal activation requires having an optional EFIO unit connected to iXT via RS- 485 port. Recognition success (Green LED)
Page 46 Select relay to use Duration(sec) Set the time how long the LED signal lasts 11.4.2. LED Signal → Recognition success (Green LED) → Relay www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 46 of 86...
Page 47 Select relay to use Duration (sec) Set the time how long the LED signal lasts 11.4.4. LED Signal → Recognition failed (Red LED) → Relay www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 47 of 86...
Page 49 Face algorithm version Revision number of Face algorithm Interphone Interphone Select enable/disable for interphone use IP Address IP address of PC which interphone software is installed www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 49 of 86...
Page 51: Storage Info
Select power line frequency that is supplying to device to reduce interference with ambient light sources. Enter 60 Hz for the USA/ Mexico and 50 Hz for Europe. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 51 of 86...
Page 52 Factory Default Resets all configuration settings and/or deletes all user data Check DB consistency Checks and updates old DB for compatibility with new firmware manually www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 52 of 86...
Page 53 Delete all data Delete all user data Delete all data and reset all configuration settings Resets all configuration settings and deletes all user data www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 53 of 86...
Page 54 2) Press the button more than 2 secs, which will delete all the data and reset all the settings. 3) The device will reboot automatically. 11.9.4. Reset → Factory Default → Delete All Data www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 54 of 86...
Page 55 11.9.5. Reset → Factory Default → Delete All Data and Reset All Settings 11.9.6. Reset → Check DB consistency The device will check and reload the internal database. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 55 of 86...
Page 56 NOTE: When you use Static mode, you should enter all necessary information: IP Address, Subnet, Gateway. IP Address Set static IP address Subnet Set static subnet mask Gateway Set static gateway IP address www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 56 of 86...
Page 58 Requires reboot of the system. Note: only certain Wi-Fi dongles are compatible, such as TP-LINK TL-WN823N V2 300Mbps Mini Wireless N USB WiFi. 12.2.1. Wi-Fi → WiFi Scanning www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 58 of 86...
Page 59 Enter the selected Wi-Fi password to connect. Note: the data input may not support non- ASCII characters, and thus the Wi-Fi router password may need to be changed. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020...
Page 60 12.2.3. Wi-Fi → Wi-Fi Selected Wi-Fi → Selected Information Displays connection information for selected Wi-Fi. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 60 of 86...
Page 61 Use secure communication Enable or disable secure communication with Network Matcher. Normally enabled. Only allow TLS 1.2 SSL Enable or disable TLS-encrypted communication with Network Matcher. Normally enabled. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 61 of 86...
Page 62 Select an operating mode for RS232 (optional) If you want to use these functions, please contact support@eyeLock.com. 12.5.1. Serial → RS232 Select Baud rate if you want to use RS232. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 62 of 86...
Page 63 12.5.2. Serial → RS232-NET Select a device type connected to RS232-NET, an RS232 application for predefined custom protocols. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 63 of 86...
Page 64: Usb Memory
If the FW file (new firmware / operating libraries) does not exist in USB memory drive, or FW file is same or older version than what is on system, a message will appear as shown below. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020...
Page 65 12.6.2. USB Memory → Import User data Restore user enroll data from USB memory Log data Restore log data from USB memory www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 65 of 86...
Page 66 Backup log data and copies debug files to USB memory Backup for debug Backup debug files to USB memory Backup for CMID Not used www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 66 of 86...
Page 67: Voice Instructions
Except for recognition Select to disable voice position guide for recognition only position guide Except for recognition Select to disable recognition result voice only result www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 67 of 86...
Page 68: Menu Timeout
Select to enable Central Timer as 24-hour clock format Menu Timeout Menu Timeout Set timeout for auto exit from menu display after leaving it untouched www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 68 of 86...
Page 69: Screen Saver
13.4.1. Screensaver → Time display position The screensaver will be displayed either below (default) or above the Time/ Date display line. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 69 of 86...
Page 70 13.4.2. Screensaver → Wait time Pop-Up Timeout Pop-Up Timeout Set pop-up message window (recognition complete etc.) display duration www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 70 of 86...
Page 71: Backlight Timeout
Set timeout for auto off LCD backlight after leaving unused Date Display YYYY/MM/DD Select year/month/day display mode DD/MM/YYYY Select day/month/year display mode MM/DD/YYYY Select month/day/year display mode www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 71 of 86...
Page 72 Language Language Select a language to use (English, Korean, Chinese(S), Chinese(T), Japanese, Russian, Turkish, Spanish, Italian, Arabic, French, Portuguese (Brazil)) www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 72 of 86...
Page 73 Configure settings for authentication method and Time & Attendance (T&A) mode. Mode Start mode Select the initial (basic) recognition method Combination mode Select a combination (dual) recognition method if necessary www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 73 of 86...
Page 74 Mode → Combination Mode (Step 1) Select a combination (additional) recognition method. T&A www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 74 of 86...
Page 75 (Enabled on “Manual (by key input)” T&A mode) Select when to do T&A check T&A key map Select a T&A value for each Function key www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 75 of 86...
Page 76 [Manual Fix] works like [Manual]. However, in [Manual Fix] mode, once a T&A event is selected, the event is kept until another T&A event is selected. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 76 of 86...
Page 77 T&A mode. 14.3.3. T&A → T&A order The T&A order menu appears when you select “Manual (by key input)” as a T&A mode. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 77 of 86...
Page 78: Admin Password
Password Set admin password NOTE: always use device password to prevent unauthorized access to the system settings. The password can be set via EIS. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 78 of 86...
Page 80: Operation
Continuous recognition Enable/Disable continuous recognition mode (When enabled, the system does not return to the home screen after each recognition). www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 80 of 86...
Page 82 Enable to use TOC (Template-on-card) Note: Only Mifare® DESfire® EV1 cards are supported currently by the built-in reader. Other card types are supported via external Wiegand card readers. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 82 of 86...
Page 83 15.3.1. Card → CSN order Select to read CSN’s most significant bit first (Reverse) Select to read CSN’s least significant bit first (Forward) www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 83 of 86...
Page 85 If you select an item on the log list, you can find information as displayed above. Face image will be shown if Face image log is enabled (Settings → Mode → Face image log). www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020...
Page 86: Delete All Logs
Log Search Delete all logs If you want to delete all the logs then select Delete all tab. www.eyelock.com iXT User Manual, v.1.4.5 Copyright 2020, all rights reserved October 2020 Page 86 of 86...
