eyeLock NanoFace-2 System User's Manual

Face recognition system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Face Recognition System
Next Generation Embedded Face Recognition Terminal
Covers both NanoFace-2 and NanoFace-2N Models
System User Guide (v1.0.4)
December 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NanoFace-2 and is the answer not in the manual?

Questions and answers

Related Manuals for eyeLock NanoFace-2

Summary of Contents for eyeLock NanoFace-2

  • Page 1 Face Recognition System Next Generation Embedded Face Recognition Terminal Covers both NanoFace-2 and NanoFace-2N Models System User Guide (v1.0.4) December 2023...

  • Page 2: About This Manual

    This manual contains the descriptions and operational instructions for NanoFace-2 device. It is intended and written for system administrators who are in charge of overall operation including installation and management. We recommend you familiarize yourself with this manual in order to make use of the product correctly and effectively.

  • Page 3: Conventions In This Manual

    Provides optional information to help users be Provides optional information to help users be more more successful in their tasks successful in their tasks. www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 3 of 37...

  • Page 4: Table Of Contents

    Dimensions (unit: mm) ...................26 4.2. Key Technical Specifications ..................27 4.3. Cables and Connectors ....................28 4.4. Environmental Specifications ...................30 Appendix A: OSD Menu List ......................31 www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 4 of 37...

  • Page 5: Introduction Nanoface-2

    1. Introduction to NanoFace-2 NanoFace-2 is a face recognition terminal that provides face recognition in an embedded system with real-time subject finding and local authentication for high throughput access control and time & attendance applications. 1.1. Features The key features NanoFace-2 are shown in the following table:...

  • Page 6: Components

    Before you begin, make sure that all the following items are included with your device. If you find anything is missing, contact your dealer. www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 6 of 37...
  • Page 7 Table 1. NanoFace-2 component table Name Quantity Description Note NanoFace-2 Main system / face recognition terminal Mounting Plate Installs the unit on a wall or on an outlet Diode Prevents currents in unintended directions (See Relay Connection for an example of its use)

  • Page 8: Parts And Controls

    Speaker Delivers sound from device Mounting plate socket Attaches the unit with the mounting plate USB port Connects a USB flash drive www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 8 of 37...
  • Page 9 Connect the relay cable Debug Reserved for debugging purposes only NOTE: Optional configuration available for POE+ power input (not shown above) as special order www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 9 of 37...

  • Page 10: Touch Screen

    Goes to the home screen Back button Goes back to the previous menu screen Shows settings menu – User, Device, Settings Communication, Display, Authentication, www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 10 of 37...

  • Page 11: Accessories

    1.5. Accessories Name Description Mounting bracket Secure I/O RF card writer Duali RF card reader/writer www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 11 of 37...

  • Page 12: Installing Nanoface-2

    Before installation, make sure that the following requirements are met. 2.1.1. Environmental Requirements The NanoFace-2 is designed and intended for indoor use only. The device is not weatherproof and must not be exposed to water, ice, extreme temperatures or other adverse weather conditions. If it is required to use the device in outdoor or service@eyelock.com...

  • Page 13: Electrical Requirements

    Note: usage of 12V DC is possible if there is no voltage drop due to either cable loss or fluctuations in mains (AC) power. Please contact EyeLock for more information. ☑ It is preferrable that the power cable is as short as possible. Ensure that wire gauge is correct in accordance with Table 2.

  • Page 14: Tool Requirements

    For measuring the installation height General Cutting plier Electric drill With a drill bit and anchor bolts Concrete wall mount Marker Hammer www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 14 of 37...

  • Page 15: Installation Procedure

    You can install the device onto a wall directly by using the mounting plate. Remove the screw that attaches NanoFace-2 to the mounting plate and disassemble the plate. Keep the screw because it will be used to attach them again.
  • Page 16 Removable tabs 5. Put the device onto the installed plate, slide it downward, and attach them with the screw (M3 x 6) www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 16 of 37...

  • Page 17: Mounting Device (Gang Box Mount)

    You can also install the device on a gang box (outlet box) by using the mounting plate. 1. Remove the screw that attaches NanoFace-2 to the mounting plate and disassemble them. Keep the screw because it will be used to attach them again.

  • Page 18: Connecting Cables

    RJ-45 connector for 10/100/1000Base-T Ethernet communication, minimum CAT5 cable. NOTE: Optional configuration available for POE+ power input (not shown above) as special order www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 18 of 37...
  • Page 19 There are two types of dead-bolt door lock connections and configuration supported – fail- safe and fail-secure. • Use different power supplies for the NanoFace-2 and the door lock. • Install the diode at both ends of the circuit as shown in the figure below close to the door lock to protect the relay contact from the reverse current that occurs when the door lock works.
  • Page 20 Fail-Secure Configuration Relay Connection – Automatic Door www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 20 of 37...
  • Page 21 Relay Connection – Alarm Light Internal relay interface with nominal switching capacity of 1 A, 30 VDC or 0.3 A, 120 VAC, resistive load. GPI Connection www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 21 of 37...
  • Page 22 Wiegand IN Connection Wiegand OUT Connection www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 22 of 37...

  • Page 23: Using Nanoface-2

    Optionally, select Bypass card to allow the user to get access permission by using a registered card alone regardless of authentication mode Press OK to complete the enrollment. www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 23 of 37...

  • Page 24: Authentication

    3.2. Authentication NanoFace-2 detects and displays the subject’s face over 2.0 meters from the system on the high-resolution color display. The subject will simple and naturally walk toward the face capture range of 0.4 to 2.0 meters. Once the system recognizes the subject, the result will be displayed immediately with indication line over the subject’s face image.
  • Page 25 Authentication result is displayed on the top of the screen depending on whether your face is recognized successfully. www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 25 of 37...

  • Page 26: Product Specifications

    4. Product Specifications 4.1. Mechanical Specifications 4.1.1. Dimensions (unit: mm) www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 26 of 37...

  • Page 27: Key Technical Specifications

    ISO/IEC 14443 reader for MiFare, DesFire and FeliCa cards (standard) Connections RJ45 for LAN, Wiegand IN/OUT, GPIO (3), RS485, dry contact relay, optional POE+ (special order) Service mode only www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 27 of 37...

  • Page 28: Cables And Connectors

    Normal Close (NC) Gray 300 mm Name Color Wire Gauge GPI 0 24 AWG GPI 1 Green GPI 2 Yellow Ground (GND) Black www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 28 of 37...
  • Page 29 OUT DATA 0 Blue 24 AWG OUT DATA 1 Gray Ground (GND) Black Power 200 mm 10 mm Ø5.5mm (-) 18 AWG www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 29 of 37...

  • Page 30: Environmental Specifications

    Non-operating -20°C to 60°C (-4°F to 140°F) Humidity Operating 8% to 85% relative humidity, non-condensing Non-operating 8% to 90% relative humidity, non-condensing www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 30 of 37...

  • Page 31: Appendix A: Osd Menu List

    Appendix A: OSD Menu List This appendix gives the details about advanced setting menus of the NanoFace-2 system’s On Screen Display that appears when you press the Gear button ( ) on the home page of the main screen. A.1. User...
  • Page 32 APP version Shows the application version Shows the MAC address Shows the serial number IOMicom version Shows the IO Micom revision number www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 32 of 37...
  • Page 33 Resets all configuration settings and deletes all user data Reset all config Sets all configuration settings to default Reset all users Deletes all user data www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 33 of 37...
  • Page 34 Shows the gateway address DNS 1 Shows the DNS #1 DNS 2 Shows the DNS #2 Server User server Selects whether to use server www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 34 of 37...
  • Page 35 FAR (false acceptance rate). Recog distance Selects the distance from where face detection starts Use T&A Selects whether to use T&A functions www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 35 of 37...
  • Page 36 Shows the used space for logs in percent Total count Show the total count of logs Log delete Delete log Deletes all logs www.eyelock.com NanoFace-2 / 2N User Guide, Copyright 2023, all rights reserved v1.0.4 December 2023 Page 36 of 37...
  • Page 37 Contact Information Please contact EyeLock or your representative for more information about the NanoFace-2 / 2N product, NanoFace Software Development Kits (SDK) and other supporting software. Eyelock, LLC 180 Marcus Blvd Hauppauge, NY 11788 Tel: +1.855.393.5625 Contact: sales@eyelock.com or service@eyelock.com www.eyelock.com...
