- Page 1 Dishwasher NEPTUNE SX1 Read Instr uctions before switching on the Dishwasher. Observe the safety guidelines for installation.
-
Page 3: Table Of Contents
CONTENTS Technical specifications …………………………………………………….. • Conformity with the standards and Test data …………………………….. • Safety information and Recommendations………………………………….. Recycling ..………………………............• Safety information …………………………………………………………… • Recommendations …...……………………………………………………… • Items not suitable for dishwashing ………………………………………… • Installing the machine ………………………………………………………….. Positioning the machine …………………………………………………….. •... - Page 4 Loading your dishwasher .……………………………………………………. Alternative basket loads …………………………………………………... • Important Note for Test Laboratories • ………………………………….. Programme descriptions .…………………………………………………….. Programme items ………………………………………………………….. • Getting familiar with your machine …………………………………………… 27 Switching on the machine and selecting a programme……………..Switching on the machine…………………………………………………. •...
- Page 5 Turbo Drying Unit: This system provides better drying performance for your dishes. Ceiling Spray Arm: It provides better washing for the dishes at upper basket. Control Panel Worktop Detergent and rinse-aid dispenser Upper basket with racks Upper spray arm Filters Lower basket Salt dispenser 15.Interior light : It provides you...
-
Page 6: Technical Specifications
Technical specifications Capacity 15 place settings Height 850 mm Height 820 mm (without worktop) Width 598 mm Depth 598 mm Net Weight 53 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W... - Page 7 For detailed information and disposal request Please visit our website https://www.ifbappliances.com/e-waste or Contact IFB Care at 080 458 45678 and provide your details to our representative to raise a request for product to be picked up for recycling and safe disposal.
-
Page 8: Safety Information And Recommendations
SAFETY INFORMATION AND RECOMMENDATIONS Recycling • Certain components and the packaging of your machine have been produced from recyclable materials. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling. -
Page 9: In Daily Use
• Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •... - Page 10 mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.
-
Page 11: Recommendations
For your children’s safety • After removing the machine’s packaging, make sure that the packaging material is out of reach of children. • Do not allow children to play with or start the machine. • Keep your children away from detergents and rinse aids. •... -
Page 12: Items Not Suitable For Dishwashing
Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers. -
Page 13: Water Connections
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning. -
Page 14: Water Inlet Hose
Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection. -
Page 15: Water Outlet Hose
Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. -
Page 16: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. -
Page 17: Fitting The Machine Undercounter
Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration. - Page 18 Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product Without Insulation With Insulation All Product For 2nd Basket For 3rd Basket Height 820 mm 830mm 835 mm Warning: After removal of worktop, the machine should be placed in such a closed place of which dimensions are shown at fig.
-
Page 19: Prior To Using The Machine
IF AVAILABLE Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •... -
Page 20: Testing Strip
Testing strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available). - Page 21 Adjust water hardness setting of your machine according to the level specified on the test track. Push the Programme selection button and hold down. In the meantime, energize the machine by pushing ON/OFF button. Hold down the programme selection button until “SL” on the screen goes off. After “SL”...
-
Page 22: Detergent Usage
Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children. - Page 23 They produce good results for certain types of usage only. If you are using this type of • detergents, you need to contact the manufacturers and find out about the suitable conditions of use. When the conditions of use of such products and the machine settings are appropriate, •...
-
Page 24: Loading Your Dishwasher
Level Brightener Dose Indicator Rinse-aid not dispensed r1 is shown on the display. 1 dose is dispensed r2 is shown on the display. 2 doses are dispensed r3 is shown on the display. 3 doses are dispensed r4 is shown on the display. 4 doses are dispensed r5 is shown on the display. - Page 25 Top basket height adjustment while it is full Basket height adjustment mechanism on the top basket of your machine is designed to let you adjust the height of your top basket upwards or downwards, without removing it from your machine when it is full, and create large spaces at the top or bottom area of your machine as needed.
- Page 26 Upper Cutlery Basket The upper cutlery basket is designed for you to place forks, spoons and knives, long dippers and small items. Warning: Knives and other sharp objects must be placed horizontally in the cutlery basket.
-
Page 27: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket... -
Page 28: Important Note For Test Laboratories
Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door. -
Page 29: Programme Descriptions
PROGRAM DESCRIPTIONS Reference P4 Program Quick 30 Mins. Super 50 Mins. Prewash * Jetwash 14 dk. Jetwash 14 dk. Eco 50°C Eco 50°C Auto Delicate Auto Delicate Auto Normal Auto Normal Auto Intense Name: 40 °C Washing 35°C 40°C 50°C 65°C 30-50°C 50-60°C... - Page 30 * * Jetwash 14 min. program can be used for the washing of fresh, low contamination dishes. It i suitable for washing dish of 4 people. ** Jetwash 14 mins. program should use only powder detergent. Warning: Jetwash 14 mins. ,quick 30 mins. and super 50mins. programs do not have drying step.
-
Page 31: Getting Familiar With Your Machine
GETTING FAMILIAR WITH YOUR MACHINE 15.b 15.c 15.d 15.a 13-Salt Level Warning Display 1-On/Off Button 14-Rinse Aid Level Warning Display 2-Door Handle 15-Program Phases Follow-up Display 3-Start/Standby button a-Washing Phase Symbol 4-Half Load Button b-Rinse Phase Symbol 5-Program Button c-Drying Phase Symbol 6-Tablet Detergent Button d-Completion Symbol 7-Extra Rinse Button... - Page 32 Power On/Off Button When you press the on/off button, the machine is energized. Door Handle Please use the door handle to open-close the door of your machine. Start/Standby Button When you press the start/standby button, the program selected with the program button will start and the display will show the washing image “...
- Page 33 Delay Button 8 Before the program starts, you may adjust the delay time by pressing the Delay button. When you press the delay button, indicator no. 17 will be illuminated on the display. Extra Hygiene Button 9 By pressing this button in order to obtain extra hygiene and a cleaner washing process by altering the water temperature and washing time of the program you have selected.
- Page 34 SELECTING A PROGRAMME AND STARTING THE MACHINE Starting the Machine 11.Press Power On/Off switch. 1 2.Select the appropriate program for your dishes using the Program Button. 4 6 7 9 3.If you prefer, you can select additional functions. Start the programme by pressing the Start/Standby button. Program Follow-up You can follow the progress by the help of the program follow-up symbols on the display.
-
Page 35: Switching On The Machine
Program Change If you want to change the program while another one is proceeding; . Press on Start/Standby button. 3 . Select the new program using Program button.5 . The newly selected program continues from where the previous one was left. . -
Page 36: Inner Light Option
Inner Light Option Machine mustbe ON position during activation and deactivation of inner light modes. Note: Open or close position of the door is not important. How to change from “ECO MODE” to “NORMAL MODE”: First energize the machine via main switch (if it is in OFF position). Press ‘’Delay’’and ‘’Extra Hygiene’’buttons simultaneously for 3 seconds. -
Page 37: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 38: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. - Page 40 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on.
-
Page 41: Practical And Useful Information
If the dishes won't dry up A programme without a dry operation selected. • Rinse aid dosage set too low • Dishes unloaded too fast. • If there are rust stains on the dishes Stainless-steel quality of the dishes washed is insufficient. •... - Page 42 THE PRODUCT FICHE (Spect) Supplier's trade mark Supplier's model NEPTUNE SX1 Capacity of dishwasher 15 The energy efficiency class A++ Annual energy consumption in kWh per year (AE ) ( 280 Cycle ) * Energy consumption (E ) (kWh per cycle) 0,93 0,5 0 Offmode power consumption (W) (P ) 1,00 Lefton mode power consumption (W) (P ) 2520 Annual water consumption in litres per year (AW ) ( 280 Cycle ) ** Drying efficiency class *** A Eco Standard programme name **** Programme time for standard cycle ( min) Noise dB(A) * Energy consumption 267 kwh per year, based on 280 standard cleaning cycles using cold water fill and the consumption of low power modes. Actual energy consumption will depend on how the appliance is used. ** Water consumption 2520 liters per year based on 280 standard cleaning cycles. Actual water consumption will depend on how appliance is used. ***Drying efficiency class A on a scale from G(least efficient) to A (most efficient). **** The “Eco 50 ˚C” is the standard cleaning cycle to which the information in the label and the fiche relates. This programme is suitable to clean normally soiled tableware and it is the most efficient programme in terms of combined energy and water consumption. ...
-
Page 43: Customer Copy
Products Owned by the customer:(Please tick in the appropriate box.) Washing Machine Refrigerator Color TV 100% Clothes Dryer Dishwasher Music System Oven Toaster Grill 2 Wheeler Air Conditioner IFB Industries Limited Regd. Off : 14 Taratolla Road, Kolkata - 700088... - Page 47 Chimney I Built in Hah Top load Front load 100% Clothes Dryer Air Conditioner Sho p 24x7 @ www.ifbappliances.com I Email customerservice@ifb g lobal.com I Cali 1860 2085678 or 1860 4255678 ) 080458 45678 Our lines remain open 24/7 www.insta g ram.com/ifbappliances/ www.facebook.com/lFBappliances twitter.com/lFBAppliances www.
