Maintenance
Guide
Store this guide next to the machine for future reference.
CONTENTS
Manuals for the Machine .................................. 1
Contents ........................................................... 2
Preface ............................................................. 4
1 Routine Maintenance .................................... 5
2 Reducing the Frequency of Paper Jams ....... 7
3 Screens Indicating the Locations of Paper
Jams .............................................................. 8
4 Symbol Indication ....................................... 11
5 Labels for Clearing Paper Jams .................. 13
6 Clearing Paper Jams ................................... 22
7 Clearing Staple Jams .................................. 94
8 List of Error Messages .............................. 101
9 If Memory Becomes Full during Scanning ....112
10 Ser vice Call Message ...............................114
11 Main Power and Control Panel Power ......118
12 When the Power Does Not Turn ON ......... 127
