Summary of Contents for Copeland KHZ506
- Page 1 USER MANUAL 2018 ZSI scroll condensing units...
-
Page 2: Table Of Contents
Location and fxing Installation clearance Refrigeration piping installation Brazing guideline Wiring diagram Start up and operation Leak test System evacuation Refrigerant charging & charge limit Maintenance & application tips System troubleshooting System start - up and operation check sheet About Copeland... -
Page 3: Disclaimer
Disclaimer Icon explanation Thank you for purchasing the Copeland ZSI low WARNING temperature condensing units. We trust that you will see This icon indicates instructions to avoid personal injury this product meeting your refrigeration needs effciently and material damage. and effcaciously. -
Page 4: Safety Instructions
Safety instruction: • Company shall not be responsible for any kind of accidents occur at sites due lack of sense of responsibility, mishandling, wrong practice of The equipment has been designed and manufactured installation and not following the instructions as to meet international safety standards but, like any mentioned above. -
Page 5: Nomenclature
Nomenclature Voltage range Capacity Code Description Code Description First two digits in CDU with cooling capacity serviceable 400V(380-420), Scope CDU family at 60Hz (Btu/hr) chassis 50Hz, 3Ph of supply K H X X X X X X X X X X X X X Capacity Application Motor circuit... -
Page 6: Features & Benefts
Features & benefts: Copeland is pleased to introduce the Copeland scroll KHZXXXLRL condensing units for low temp applications. These condensing units are built with the ZSI scroll compressors with liquid injection and premium on-board CoreSense electronics features for diagnostics plus protection and come with a service door for ease of access and serviceability. -
Page 7: Function Descriptions
CoreSense electronics module: The KHZXXXLRL use the proven ZSI compressor range which features liquid injection technology controlled by an intelligent electronics platform—the CoreSense control board. CoreSense regulates liquid injection by sensing the Discharge Line Temperature (DLT) to widen the operating envelope and enhance the product reliability. - Page 8 Board Operation - EXV Testing LED Display Description LED Blinking Pattern Indicates DLT sensor status (Yellow Green) LED2 and LED3 combination and blinking patterns indicate EXV opening or closing (Yellow Green) LED2 and LED3 blink once when entering or exiting EXV manual operation (Yellow Green) LED4 turns on as an alarm when triggered by any of the following: 1.
-
Page 9: Standard Scope Of Supply
Standard scope of supply: The following components are included in the KHZXXXLRL - E5EC6C condensing unit scope of supply: Table 1: scope of supply details of KHZXXXLRL CDU models Model KHZ506 KHZ508 KHZ509 KHZ511 KHZ514 KHZ515 KHZ518 KHZ521 ✓ ✓... -
Page 10: Technical Specifcation
Technical specifications: Refer to table 2 below for the dimension, weight & other mechanical details of the product. Table 2: mechanical details of KHZXXXLRL CDU models Mounting Fan W/V/P Receiver Dimensions Suction line Liquid line Sound dimensions weight No of CDU model * fans W X D X H... - Page 11 Refer to table 3 for the electrical details of the KHZXXXLRL CDU models as under Table 3: electrical data for the KHZXXXLRL CDUs Contactor Model Compressor Rated voltage CDU MCC (A) Cu. cable size rating KHZ506LRL-E5EC6C ZSI06KQE-TFM 380-420V/50 Hz/3Ph 2.5 Sq. mm KHZ508LRL-E5EC6C ZSI08KQE-TFM 380-420V/50 Hz/3Ph...
-
Page 12: Installation
Oil & refrigerant: suitable and provide adequate support for the weight of the units. Qualifed refrigerant R404A During installation and Copeland brand subsequent maintenance products Emkarate RL 32 3MAF standard oils • Installation and maintenance are to be performed only by... -
Page 13: Location And Fxing
Location and fxing • The unit should always be installed in a location that ensures clean air fow. Both service access and airfow have been considered in making these recommendations. • Where multiple units are to be installed in the same location, the contractor needs to consider each individual case carefully. -
Page 14: Refrigeration Piping Installation
Refrigeration piping installation Brazing recommendations All interconnecting pipes should be of refrigeration grade, Maintain a fow of oxygen-free nitrogen through the system clean, dehydrated and must remain capped at both ends at a very low-pressure during brazing. Nitrogen displaces until installation. Even during installation, if the system is the air and prevents the formation of copper oxides in the left for any reasonable period (say two hours), pipes should system. -
Page 15: Wiring Diagram
Wiring diagram 2 Fans Unit 8504574 (2018) ZSI scroll condensing units... - Page 16 Wiring diagram Single Fan Unit 8504574 (2018) ZSI scroll condensing units...
-
Page 17: Start Up And Operation
Failure to carry vacuum pump and never operate the compressor while out leak test can result to undesirable system performance. the system is in vacuum. Copeland recommends triple evacuation process (best practice) to be implemented on Step-by-step: all our installations. -
Page 18: Refrigerant Charging & Charge Limit
Refrigerant charging 7. The compressor can then be started, and the unit continued to be charged (with liquid refrigerant through the suction service valve). After ensuring the system is vacuumed properly and all valves are opened, only then start the refrigerant charging The quantity of charge should always be measured. - Page 19 Refrigerant charge Refer to the table below for the approximate refrigerant holding capacity of condensing unit : Refrigerant charge Model (R404a) kg KHZ506LRL-EX 4.10 KHZ508LRL-EX 4.10 KHZ509LRL-EX 4.10 KHZ511LRL-EX 4.10 KHZ514LRL-EX 4.10 KHZ515LRL-EX 4.10 KHZ518LRL-EX 4.54 KHZ521LRL-EX 4.54 8504574 (2018) ZSI scroll condensing units...
-
Page 20: Condenser Fins
Condenser fan(s) and motor(s) Maintenance An annual inspection of these items is recommended. Condenser fins Fastenings may loosen, bearings may wear, and fans may require cleaning of solid deposits which can cause • Condenser fns become dirty over time as ambient imbalance. -
Page 21: Electrical Tips
• Don't allow air, moisture, contaminants to enter • Check to ensure the electrical connections are properly compressor. attached, secured and properly tightened. • Don't charge refrigerant looking at compressor amperes • Make sure all panels are secure and panel screws are properly tightened. -
Page 22: Pressure -Temperature Chart
Maximum compressor cycle & minimum run time Copeland cannot be held responsible for any damage caused by using these substances. KHZ or ZSI scroll CDU units- maximum permitted starts per hour is 10. -
Page 23: System Troubleshooting
System troubleshooting guide: Symptom Possible cause Correction • Check voltage at contactor in condensing unit • Power disconnected or loose connection • Replace fuses / reset breaker • Blown fuse / breaker tripped • Reset Unit is not starting • Thermostat out of calibration – set too high •... - Page 24 System troubleshooting guide: Symptom Possible cause Correction • Compressor may loss pumping • Replace Suction & discharge • If cooling achieved, gauges may be faulty • Gauges replace pressure balanced • Compressor may trip on IPRV • Check for high side restriction in the system •...
-
Page 25: System Start - Up And Operation Check Sheet
System start-up and operational check sheet: Client details Facility/customer name : Address : Contact details : Installer : Installation date : Condensing unit info CDU model : Serial number : CDU location : Indoor unit make/model : System details System Operation Room/case ID: COMP voltage: Pipe Length (approx.):... -
Page 26: About Copeland
About Copeland Copeland is a global leader in sustainable heating, cooling, refrigeration and industrial solutions. We help commercial, industrial, refrigeration and residential customers reduce their carbon emissions and improve energy effciency. We address issues like climate change, growing populations, electricity demands and complex global supply chains with innovations that advance the energy transition, accelerate the adoption of climate friendly low GWP (Global Warming Potential) and natural refrigerants, and safeguard the world’s most critical goods through an...
