- Page 1 All manuals and user guides at all-guides.com INSTRUCTION MANUAL IN DASH COLOR TT-LCD MONITOR PLVS420 4 INCH SUN VISOR TFT-LCD MONITOR...
- Page 2 All manuals and user guides at all-guides.com Thanks for purchasing PYLE Sun visor TFT-LCD Monitor. Please read this menu carefully before the installation.
-
Page 3: Operation
All manuals and user guides at all-guides.com OPERATION 1.Connect the monitor power input plug to a DC po wer source (Red plug +12 VDC, Black plug(-) to ground). 2.Connect the external video source output signal (from VCD, DVD, TV etc.) To the VIDEO in jac k. 3.Press power button to turn the monitor on and off. -
Page 4: Installation
All manuals and user guides at all-guides.com INSTALLATION Installation will vary from vehicle to vehicle, as headrests in vehicles are not standard. - Page 5 All manuals and user guides at all-guides.com PRECAUTION T o p r e v e n t s h o r t - c i r c u i t i n g o f t h e e l e c t r i c a l s y s t e m a n d c a u s e s e r i o u s d a m a g e t o t h e u n i t o r t h e v e h i c l e , y o u a r e a d v i s e d t o f o l l o w t h e i n s t r u c t i o n s c a r e f u l l y.
-
Page 6: Front Panel
All manuals and user guides at all-guides.com FRONT PANEL 1.power indicator 2.power On/Off 3.menu 4.positive adjustment 5.negative adjustment 6.menu select up 7.menu select down 8.IR 9.video input REMOTE CONTROL 1.menu 2.power on/off 3.game - 4.game + MENU ON/OFF 5.volume - GAME 6.volume + 7.sleep... - Page 7 All manuals and user guides at all-guides.com Technical Specification Screen size: 4 inch(Diagonal length) System: PAL & NTSC Display Method: TFT active matrix system Resolution: 390x282 dots Power supply: DC 12V Power consumption: 8W Dimension: 210 X 129 X 30 mm WIRING Black:power input Yellow:video 1 input...
- Page 8 All manuals and user guides at all-guides.com...
