Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 5 to 11 and Installation Instructions are on pages 12 to 26. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the appliance.
Table of Contents Before You Begin ............................. 2 Table of Contents ............................ 4 Important Safety Information ........................5 Installation ............................. 12 Included Parts ..........................11 Tools and Additional Parts Needed ....................13 Dimensions ............................14 Gas Range Specifications ....................... 15 Step 1 - Read the Safety Precautions .....................
Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using your oven to prevent the risk of fire, electric shock, personal injury, or damage when using the appliance. This guide does not cover all possible conditions that may occur. Always contact your service technician or manufacturer about problems that you do not understand.
Important Safety Information WARNINGS • Ensure that the room is well ventilated by keeping the air • Do not store or use gasoline, liquid propane cylinder or intakes open and in good working order or by installing other flammable vapors and liquids in the vicinity of this an extractor hood with discharge pipe. If the appliance or any other appliance. is used intensively for a long time the effectiveness of •...
Important Safety Information DANGER • Clean the appliance regularly to keep all parts free of • Do not store items of interest to children in the cabinets grease that could catch fire. Exhaust fan ventilation above the appliance or on the back splash of appliance. hoods and grease filters should be kept clean. Do not Children should not be left alone or unattended in the allow grease to accumulate on hood or filter.
Page 8
Important Safety Information DANGER • Do not use stove top grills on your gas appliance. If • Use the proper pot/pan sizes. This appliance is equipped you use a stove top grill on a sealed gas burner, it will with surface units of different sizes. Select pots/pans cause incomplete combustion and can result in exposure having flat bottoms large enough to cover the surface to carbon monoxide levels above allowable current unit.
Page 9
Important Safety Information VENTILATION WARNINGS • The appliance should have proper ventilation in order to • If a range hood is installed above the appliance, maintain keep the unit operating properly and maintain the a 30” minimum clearance between cooking surface and bottom of range hood. The range hood must be temperature of immediate surroundings within safe limits.
Important Safety Information INSTALLATION WARNINGS 501A, ANSI A119.2.2–1982, or with local codes. To avoid damage to your cabinets, check with your In Canada, the installation of this range must conform builder or cabinet supplier to make sure that the with the current standards CAN/CSA-A240-latest materials used will not discolor, delaminate or sustain edition, CAN/CGA Z240.4.2, or with local codes.
Important Safety Information GAS CONNECTIONS GAS LINE SHUT-OFF VALVE • To reduce the possibility of gas leaks, apply Teflon tape Important: Do not apply pressure directly to the appliance or a thread compound approved for use with LP or manifold pipe when tightening supply connections. The manifold pipe should be held securely at the pressure Natural gases to all threaded connections.
Installation Included Parts Griddle (48” models only) Adjustable Feet LP conversion kit Gas pipe adapter with washer T H E L E G A C Y C O M P A N I E S W E S T O N , U S A 3 3 3 3 1 W W W .
Installation WARNING: HAVE THIS RANGE INSTALLED BY A QUALIFIED INSTALLER. Improper installation, adjustment, alteration or maintenance can cause injury or property damage. Consult a qualified installer or service agency. IMPORTANT – SAVE FOR THE LOCAL ELECTRICAL INSPECTOR’S USE. BEFORE USING YOUR DUAL FUEL RANGE •...
Page 15
Installation ELECTRICAL CONNECTION WARNING: Improper grounding can result in the risk of electrical shock. • The appliance must be properly installed and grounded by a qualified technician in accordance with the National Electrical Code ANSI/NFPA No. 70 (Latest Edition) and local electrical code requirements. Installation should be made by a licensed electrician.
Installation 3-Wire Power Cord Installation • Remove the Terminal Block Access Plate on the back of range by removing the 1 fixing screws. • Assemble the strain relief in the hole on bracket. • Insert the power cord through the strain relief and tighten. •...
Installation GAS RANGE SPECIFICATIONS • Before installing the range, you must locate and secure the included anti-tip bracket to the wall for your range. • The range may be installed flush to the rear wall. You may install a non-combustible material on the rear wall above the range and up to the vent hood.
INSTALLATION INSTRUCTIONS Dimensions and Clearances The range may be installed flush to the rear wall. You may install a non combustible material on the rear wall above the range and up to the vent hood. It is not necessary to install non-combustible materials behind the range below the counter top height.
Page 19
Installation STEP 3 Dimensions and Clearances • Before installing the range, you must locate and secure the included anti-tip bracket to the wall for your range. 13” (33 cm) Max. • The range may be installed flush to the rear wall. You may install a non-combustible material on the rear wall above the range and up to the vent hood.
Installation Dimensions and Clearances Installation Diagram Installation Diagram T H E L E G A C Y C O M P A N I E S W E S T O N , U S A 3 3 3 3 1 W W W .
Installation STEP 4 Gas Connection For NG, input pressure is 7” W.C. and output pressure 5” W.C. For LP, input pressure is 11” W.C. and output pressure: 10” W.C. Appliance regulator is set at 5.0” W.C. outlet pressure. The gas supply pressure for checking the regulator setting is 5” (Natural Gas) and 10” (LP gas). Connect flexible gas line connector to the regulator on the range.
Page 22
Installation STEP 4 (Continued): Gas Connection WARNINGS: • Please make sure to read ALL safety precautions on pages 4 to 10. • Explosion Hazard. • Use a new CSA International approved gas supply line. • Install a shut-off valve. • Securely tighten all gas connections. • If connected to LP, have a qualified person make sure gas pressure does not exceed 12” (30 cm) water column. Examples of a qualified person include: licensed heating personnel, authorized gas company personnel, and authorized service personnel. • Failure to do so can result in death, explosion, or fire. Shut off the main gas supply valve before removing Use a flexible gas line to connect to the 1/2”...
Installation STEP 5 (Optional) Unscrew the regulator cap with a wrench (see Figure (Must be done before Step 6 if converting to Propane) Liquefied Petroleum (Propane) Remove retainer pin by pulling it out (see Figure 7). Gas Conversion This appliance can be used with Natural Gas or LP/Propane Gas.
Use proper support to prevent will damage the burner base and affect the flame). damage to components. Install the proper nozzles in the exact locations as noted in the illustrations below (see Figures 11). BR3001SSDF Burner 1.75 1.18 BR4801SSDF 1.33...
Installation STEP 6 Install Anti-Tip Bracket Make sure the anti-tip bracket is installed: To reduce the risk of tipping of the range, the range must be Slide range forward. secured to the floor with a properly installed Anti-Tip Bracket (included). All ranges can tip and cause injuries.
Installation STEP 8 Finish Installation When all connections have been made, check that all range controls are in the “off” position and turn on the main gas supply valve. T H E L E G A C Y C O M P A N I E S W E S T O N , U S A 3 3 3 3 1 W W W .
Safety Before Operating Safety Precautions • Allow the burner grates and other surfaces to cool before touching them. Before operating this appliance it is VERY important that • NEVER block the vents (air holes) of the appliance. They you read the safety precautions on pages 4 to 10 as well as provide the air inlet and outlet that are necessary for all safety precautions listed on this and the following pages the appliance to operate properly with correct with the header, “Safety Before Operating”.
Page 28
Safety Before Operating Surface Burner Safety • Use the least possible amount of fat for effective shallow or deep-fat frying. Filling the pan too full of fat can cause WARNINGS: spillovers when food is added. • If the top burner flame goes out, gas will continue to flow to the burner until the knob is turned to the •...
Operation Guidelines for Using Cooktop Burners • There are dual burners that have the same low turn-down • Make sure that all burner parts are properly in place. Incorrectly or incompletely assembled burners may setting (SIM) for gentle simmering (620 BTU/hr). Use the SIM setting for melting chocolate and butter, cooking rice produce dangerous flames. See ‘Replacing the burner and delicate sauces, simmering soups and stews, and parts’ in ‘Care and cleaning’.
Operation Simmer and Boil • A smaller flame will give the best simmer results. Small flames offer precise cooking performance for delicate foods, keeping food warm, melting chocolate or butter, and for slow-cooking over low heat. • The highest (larger) flame settings provide the maximum possible heat. This setting should be used for heavy cooking loads such as water boiling and pasta cooking.
Operation Oven Vent • Do not block the ducts at the rear of the range when cooking in the oven. It is important that the flow of hot air from the oven and fresh air into the oven burner never be interrupted. Avoid touching the vent opening or nearby surfaces during oven or broiler operation –...
Operation Broil The intense heat from the upper heating element is used to cook thin slices of meat, poultry and fish. The heating element coils turns red when the oven control knob is set to BROIL. Place food in the recommended rack position after the oven has completed the PREHEAT cycle. Refer to recipes or packaging for broiling instructions and cook times.
Operation Griddle Operation (BR3601SSDF & BR3601SSDF) Before Using the Griddle Use of the Griddle Clean the griddle thoroughly with warm, soapy water Push and turn the control knob counter-clockwise to to remove dust or any protective coating. the preferred cooking temperature. Rinse with clean water and wipe off to dry with soft, Preheat the griddle for 10-12 minutes.
Maintenance Removing the Oven Door and Kick Plate While holding the door on each side, close the door until it touches the levers. Continue closing the door WARNINGS: until it is about 4” (10 cm) from being completely • The removable oven door is heavy. You may need closed.
Care and Cleaning Burner Rings WARNINGS: Lift off when cool. Wash burner rings in hot, soapy water • Please make sure to read ALL safety precautions and rinse with clean water. To remove burned-on food on pages 4 to 10 and 21 to 22. particles, you may scour with a plastic scouring pad. •...
Care and Cleaning Control Panel, Door Handle, Control Housing Oven Frame • Clean the control panel, door handle and control • Clean with hot water, soap-filled steel-wool pads or housing with a solution of mild detergent and warm cleaners. Rinse well with clean water and dry. water.
Page 37
Troubleshooting Tips Symptom Possible Cause Solution Dead batteries or ignition module failed. Replace batteries and attempt ignition. If there is still no spark ignition, the appliance burners can still be CAUTION used. To light them: Holding a lit match to the flame spreader, No ignition spark.
For two years from the date of purchase by the original owner, BRAMA products will, at its option, repair or replace any part of the product which proves to be defective in material or workmanship under normal use.
