Thank you for purchasing our products.
The products are subject to change without prior notice.
The company is not responsible for any safety accidents caused by abnormal operation of the
product.
Please carefully read this User's Guide (in particular, precautions for safety) before using a
product and follow instructions to use a product exactly.
The Guide is for reference only. If there is inconsistency between the Guide and the actual
product, the actual product shall prevail.
GUARDEON SECURITY SYSTEM
Advertisement
Table of Contents
Related Manuals for GUARDEON GPV-IPMMF IP
Summary of Contents for GUARDEON GPV-IPMMF IP
- Page 1 GPV-IPMMF IP multibruger manual Thank you for purchasing our products. The products are subject to change without prior notice. The company is not responsible for any safety accidents caused by abnormal operation of the product. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
-
Page 2: Table Of Contents
11. Door setting ..........................8,9 12. Card management ......................9,10 13. Unlock operation ......................11-12 13.1 Unlock from indoor monitor .....................10 13.2 Password unlock ......................11 13.3 RFID unlock ........................12 13.4 APP unlock ........................12 14. System information ......................12,13 15. Specifications ........................14 GUARDEON SECURITY SYSTEM... -
Page 3: Product Component Description
GUARDEON SECURITY SYSTEM 72170028 1. Product component description FRONT REAR Night vision Display Anti-tamper button Camera Card read area Terminal 10 12 Indicator light Speaker Microphone Reset button Step 1 Step 2 Long press the RESET Reset button for 5 seconds, the... -
Page 4: Product Wiring Diagram
GUARDEON SECURITY SYSTEM 72170028 3. Product wiring diagram LOCK NO LOCK NC GATE NO GATE NC POWER Gate 15 VDC Door Contact INPUT 1 INPUT 2 Exit Button LOCK NO LOCK NC Gate GATE NO GATE NC 15 VDC... -
Page 5: System Wiring Diagram
GUARDEON SECURITY SYSTEM 72170028 4. System wiring diagram DOOR 1 DOOR 8 Internet (Address 1) (Address 8) Family 100 Switch uplink Internet Family 10 Switch Internet Family 1 Router DOOR 1 DOOR 8 (Address 1) (Address 8) Family 100... -
Page 6: Installation Guide
GUARDEON SECURITY SYSTEM 72170028 5. Installation guide a. Please select the most suitable doorbell position, avoid direct sunshine to camera, dark surroundings, rain. b. Determine doorbell installation height: suggest to be 1.5~1.6meters. 120° c. Dig a hole at the suitable height on the wall. -
Page 7: Configuration Process
GUARDEON SECURITY SYSTEM 72170028 NOTE: If you forget the password, first remove the rubber plug at the reset button of the outdoor station, then use a screwdriver or other tools to long press the reset button inside for 5 seconds until the outdoor panel reboots, and the reset is complete. -
Page 8: Verifying Configuration
GUARDEON SECURITY SYSTEM 72170028 LANGUAGE ENGLISH 17:49 SCREEN LOCATION ROOM1 ROOM NO TIME UNTILL SCREEN STANDBY 1 MIN 16-05-2020 DO NOT DISTURB RECORD MODE DOORBELL PRESS TAKE PICTURE ASK FOR VOICEMAIL POSSIBLE TO LISTEN TO THIS SCREEN ADD NEW DEVICES... -
Page 9: Calling Monitor From Panel
GUARDEON SECURITY SYSTEM 72170028 18/08/2022 15:12 18/08/2022 15:12 18/08/2022 15:12 NEW CONTACT 搜索 NAME Shelly CONTACTS SETTINGS ROOM NO Mar y Dolly DOOR PASSWORD Nancy Jane Barbara CARD INFORMATION Tommy ?123 Picture 1 Picture 2 Picture 3 9. Calling monitor from panel 9. -
Page 10: Calling Master Monitor
GUARDEON SECURITY SYSTEM 72170028 9. 2 Calling master monitor On the outdoor panel touch for quick calling MASTER monitor. 10. Calling between indoor monitors You can make call between all the monitors. Click CALL of the indoor monitor, enter “ 1+room number ” then call user. -
Page 11: Card Management
GUARDEON SECURITY SYSTEM 72170028 Setting item Selection Note The unlocking time can be set to 1S to 20S. The default UNLOCK TIME 1S-20S unlocking time is 5S. The GATE unlocking time can be set to 0.2S to 5S. The GATE UNLOCK TIME 0.2S-5S... -
Page 12: Unlock Operation
GUARDEON SECURITY SYSTEM 72170028 Setting item Selection Note Input the user room number, swipe RFID card at reader area of panel. The card can be registered successfully REGISTER after a beep. The user cards can be added in sequence. -
Page 13: Password Unlock
GUARDEON SECURITY SYSTEM 72170028 13. 2 Password unlock A. Door Unlock: Default UNLOCK password: 123456. Click , Input password to unlock the door. 18/08/2022 15:12 18/08/2022 15:12 18/08/2022 15:12 18/08/2022 15:12 18/08/2022 15:12 Picture 1 Picture 2 Picture 3 B. -
Page 14: Rfid Unlock
GUARDEON SECURITY SYSTEM 72170028 13. 3 RFID unlock 1. Swipe RFID on the outdoor panel to open the lock. 2. Gate unlock: click and then put the card on the panel to open the gate. 13. 4 APP unlock During intercom interface of APP, click Lock 1, and the door will be opened. - Page 15 GUARDEON SECURITY SYSTEM 72170028 Setting item Selection Note LANGUAGE Choose the right language as you like. The address of the panel can be set to 1-8. If you use multiple panels, the ADDRESS address of the master panel should be “1”...
-
Page 16: Specifications
GUARDEON SECURITY SYSTEM 72170028 15. Specifications Operation system Embedded linux operation system Screen 7" IPS screen TFT resolution 1024*600 Camera 2MP CMOS HD camera Angle of view 120° Video compression standard H.265 (default), H.264 Resolution 1920x1080 Noise suppression and echo cancellation Audio quality Specification of speaker...
