- Page 1 S l ox Signage TV USER’S MANUAL Note: The product and illustrations in this user's manual is only for explanation purposes and may vary depending on model.
-
Page 2: General Information
General Information To avoid damaging the television set please observe the following safety instructions during setup and use. Cleaning the television set Before cleaning, disconnect the television set. Use only a soft damp cloth or a special cleaning product for flat-screens. LED Display Too much pressure on the screen can damage the television set. - Page 3 Do not flush the television to avoid damaging its waterproof design. Batteries (AAAx 2) Remote Control S l ox S l ox Screws BM8X14MM Screws BM8X28MM & Gasket (Matched with Sylvox Full Motion Cantilever Mount) (Matched with Fixed Wall Mount)
-
Page 4: Table Of Contents
TV Specification Content Screen size 43" Display Type TFT LED Resolution 3840 X 2160 TV Specification Aspect Ratio 16:9 Installation Alimentation AC 100-240V 50/60Hz Overview Audio Output L/R10WX2 Dimensions 38.61 x 22.40 x 3.41 inch SUPPORTINGSIGNALS Operating Temperature -22° to 140° F (-30° to 60°C) Remote-Control unit General Description USB Playback Settings... -
Page 5: Installation
Installation Installation Step1–Mounting Bracket to Wall Fixed Wall Mount Fix the horizontal bracket into wall with screws. Step2–Mountingbracket toTV Fix the vertical bracket on the back of TV with screws(M8). (Mounting Brackets are not supplied with TV) Please thoroughly read instructions before attempting installation The only suitable for the 43”–75”Outdoor TVs. We advise that 2 people install the screen due to the heavy load of the screens. -
Page 6: Vesa Standard
Overview Installation Step 3–Mounting TV to Bracket Attach TV with brackets on wall. SPEAKER Reminder of dust removal of trumpet waterproof film Don't use sharp objects to remove dust from the horn mouth, so as not to damage the waterproof membrane. Use a soft brush to remove dust. VESA Standard 43": 300 x 300 mm 55": 300 x 300 mm... -
Page 7: SupportingSignals
Supporting Signals Overview Connection Port PRESET MODE (HDMI) Please remove the waterproof panel on the back of the TV and you will see all the ports. Resolution V.Freq.(Hz) H.Freq.(KHz) 640x480 59.94 31.469 720x480 59.94 31.469 720x576p 31.25 800x600 37.9 1280x720p 1920x1080i 33.75 1920x1080p... -
Page 8: Remote-Control Unit
General Description Remote-Control unit Installing Batteries in the Remote Control 1. POWER: Short press to turn off Long press to turn Installing Batteries on or restart. 2. MUTE: Mute key Open the battery compartment cover on the back side. : Come back to Android System page. -
Page 9: Usb Playback Settings
4. Set up the Magic Player Device Ensure that no networks are connected, as an active network can interfere with USB playback. USB Playback Settings Enter “Network settings,” turn off the network, and then save the settings. (Changes will take effect after saving. If the network is disconnected by default, ignore this step.) 1. -
Page 10: Usb Playback Operation
Return to System Settings, enter “System mode.”Choose the “Stand-alone” mode, then save the settings. USB Playback Operation (Settings will take effect after saving.) 1. Full-screen playback in a single region Store videos/images in the root directory of the TF/USB drive; videos/images will automatically loop as shown in the picture. -
Page 11: Lan Publishing Settings
*Diagram of naming coordinates LAN Publishing Settings Download and install: LCD player NetAssist.exe USR-M0 V2.2.6.0.exe UartAssist.exe Note: USB drives and TF cards only support video and image playback. 1. Supported video formats (coding methods): H.264, VP8, MAV, WMV, AVS, H.263, 1. - Page 12 3. Enter the Magic Player System Settings. 5. Return to System Settings, enter “System Mode.” Press the key on the remote control to enter the System Settings; the interface is as follows: *System Settings interface as shown: 6. Choose “LAN mode” in System Mode, and then save the settings. (Please note that the settings will only take effect after saving.) 4.
-
Page 13: Publishing Content
7. Enter "About Us" in the System Settings to find and note down the device name. Publishing Content 1. Publishing Content 1. Connect LCDplayer with the Magic Player Device. 2. Ensure that the computer and Magic Player Device are on the same LAN. 3. - Page 14 3. Program Editor 6. Publishing progress can be monitored in the execution results. 1. Use the top navigation bar to select the desired material type. When execution reaches 100%, the published content will be displayed on the device screen. 2. Click the "+" in the Component Properties on the right side to upload the required materials and save.
-
Page 15: Cloud Platform Publishing Settings
2. Enter the Magic Player Settings Press the key on the remote control to enter the System Settings; the interface appears as Cloud Platform Publishing Settings follows: Cloud Server URL: https://iot.sylvoxtv.com 1. Open the Magic Player software. 3. Enter “Network settings” to connect to the network. Enter System Mode, set the system mode to “Networking,”... -
Page 16: Cloud Platform Publishing Content
3. Program Management 1. Click “Program,” select LCD, and enter the program list. Cloud Platform Publishing Content 2. Click “New program.” 3. In the new program dialog, define the program name, manually set the screen width and height. 4. Or select the corresponding device to automatically set the screen width and height. 5. - Page 17 7. In the publishing dialog, choose the device or device group to C. You can also display in any arbitrary section as shown in the picture. publish to, and then click the Send button. Note: 1. If you select Additional Update, it will clear all programs on the device and add latest programs;...
-
Page 18: Ip Control For Local Area Network Control
3. Open ‘NetAssist.exe’. 1. Protocol: TCP Client, Remote Host Addr: The device IP found in ‘USR-M0 V2.2.6.0.exe’, IP CONTROL for Local Area Network Control Remote Host Port: 20108. 2. Click on "Connect." If the connection is successful, it will display: "The server is connected from local X.X.X.X:X."... -
Page 19: Rs232 Control
4. Enter the corresponding commands in the data sending window, click "Send," and the TV will respond. RS232 Control 1. Connect the computer to the LAN IN port using an RS232 CABLE. The RS232 definition for the LAN IN interface is as follows: 5.GND 2.TX 1.RX... -
Page 20: Warning
Warranty WARNING Thank you for purchasing this Sylvox product. We are glad to offer 12 months free warranty for you. If you have any questions, please contact us via our after-sales email or website for assistance. Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death. - Page 21 Warranty Period: Sylvox repairs the TV free of charge under the condition of the normal use of the instruction manual within 12 months. Sylvox warrants that this product conforms to the manufacturer's specifications and will be free of defects in material and workmanship should any defect occur.
