Installation Manual
Manual de Instrucciones
Manuel D'Installation
Manual de Instalação
MS642
CST642
Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
(888) 295-8134 or (678) 466-1300 when calling from outside of U.S.A.
Advertisement
Table of Contents
Related Manuals for Toto MS642
Summary of Contents for Toto MS642
- Page 1 CST642 Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con- tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260...
-
Page 2: Table Of Contents
Rough-In Dimensions ......23 THANKS FOR CHOOSING TOTO! The mission of TOTO is to provide the world with healthy, hygienic and more comfortable lifestyles. We design every product with the balance of form and function as a guiding principle. Congratulations on your choice. -
Page 3: Included Parts
Mounting Screw with Washer (2 pieces) Template Anchor (2 pieces) Rough-In Instructions CARE AND CLEANING WARNING! DO NOT USE IN-TANK BOWLCLEANERS. The use of high concentration of chlorine or chlorine-related products can seriously TOTO ® by the use of in-tank bowl cleaners. -
Page 4: Installation Procedure
INSTALLATION PROCEDURE Ill. 1 Rough-In Installation instruction. 2. Place the template into position and follow its instructions to prepare for installing the toilet bowl. NOTICE Ill. 2 Rough-In on the Floor Flange after wax seal is set. If this notice is disregarded, discard the wax ring and replace with new wax ring. - Page 5 INSTALLATION PROCEDURE Ill. 4 4. Align the toilet perpendicular to the back wall and parallel to side walls; it should not sit crooked or diagonal (ill. 4). Ill. 5 5. Make sure it’s aligned before securing. 6. Install the side screws to the mounting blocks.
-
Page 6: Maintenance Instructions
MAINTENANCE INSTRUCTIONS Fill Valve Replacement Procedure Shut off the water supply to the toilet. Flush toilet and remove remaining water from tank with a sponge. position that does not interfere with the trip lever operation. NO TE: Do not overtighten. These are plastic parts. Never use pipe dope on any water supply connection. - Page 7 SERVICING THE FILL VALVE NOTE: Due to water conditions in your area, the strainer may require periodic clean- ing. An indication that the strainer 1. Snap off the top cover by pulling from under the tab (see ill. 1). 2. Pinch the tabs of the lever arm to allow its removal (see ill. 2). 3.
