Summary of Contents for Lynx LN24REFC
- Page 1 MAKE THE MOST OF YOUR L 24REFC OUTDOOR REFRIGERATOR / FREEZER CARE & USE/INSTALLATION...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions Contents Safety information ...............2 Warnings and safety instructions appearing in this guide Unpacking your appliance ..........3 are not meant to cover all possible conditions and situa- Installing your appliance ............4 tions that may occur. Common sense, caution, and care Optional ice-maker operation ..........7 must be exercised when installing, maintaining, or operat- Door Reversal ..............8... -
Page 3: Unpacking Your Appliance
UNPACKING YOUR APPLIANCE Warranty Registration WARNING It is important you send in your warranty registration card EXCESSIVE WEIGHT HAZARD immediately after taking delivery of your appliance or you can register online at: Use two or more people to move product. www.lynxgrills.com/support/registration Failure to do so can result in personal injury. -
Page 4: Installing Your Appliance
Do not obstruct the front grille. The openings within the energy usage and loss of cooling capacity. For this reason it is important this area not be obstructed and the grille openings kept clean. Lynx Grills does not recommend the (See Figure 2). CARE AND USE/INSTALLATION... -
Page 5: Electrical Shock Hazard
INSTALLING YOUR APPLIANCE WARNING Electrical Shock Hazard • Do not use an extension cord with this appliance. Do not remove They can be hazardous and can degrade product ground prong performance. • This appliance should not, under any circumstanc- es, be installed to an un-grounded electrical supply. •... -
Page 6: Water Supply
MODEL LM24RFEFC WITH OPTIONAL ICE-MAKER KIT NOTE An optional ice-maker kit (part number S42418151) is avail- able for model LN24REFC which includes all of the neces- sary parts for installation. The kit can be obtained from Lynx Grills customer service by calling (888)-289-5969. -
Page 7: Optional Ice-Maker Operation
OPTIONAL ICE-MAKER OPERATION CAUTION The water supply to the ice-maker must be turned on prior to turning the ice-maker on. Failure to do so will cause rapid dry cycling of the ice-maker mold heater resulting in temperature control issues in the freezer compartment. Ice-maker operation Figure 8 •... -
Page 8: Product Dimensions
PRODUCT DIMENSIONS Door Reversing Instructions Tools Needed: • 1/8” Hex Key • 5/32” Hex Key • Phillips Screwdriver Open door and remove Hinge Pin from the Upper Hinge using a 1/8” Hex Key tool making sure to steady the Using a Phillips Screwdriver, remove the 6 screws from both the Upper and Lower Hinges and save for later steps Once the Hinges are removed from the unit, using a Phillips Screwdriver, remove the Bushing Screw and Hinge Pin Screw and save for later steps On the Bottom Hinge, reattach the Bushing Screw and Hinge Pin Screw to the opposite side... - Page 9 6. Remove the door switch actuator tab from the door and attach it to the opposite side Door switch actuator tab 7. Reattach the Upper and Lower Hinges, and Hinge Brackets to opposite sides. Then install the door. CARE AND USE/INSTALLATION...
- Page 10 PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS MODEL "A" "B" "C" "D" "E" "F" "G" "H" "J" 24" **34" to 35" " " to 34 " " " " " L 24REFC (61 cm) (86.4 to 88.9 cm) (60.7 cm) (85.7 to 88.3 cm) (60.2 cm) (67.9 cm)
- Page 11 PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT MODEL REQUIREMENTS # WEIGHT 140 lbs L 24REFC 115V/60Hz/15A (63.6 kg) "J" "H" "D" "G" "E" Figure 11 " " (54.6cm) (1.6 cm) "F" * Depth dimension of rough-in opening may vary depending on each individual installation. To recess entire door "F" di- mension plus 1"...
-
Page 12: Using Your Electronic Control
Close door to reset towards the selected temperature. Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. Lynx Grills recommends allowing the unit to reach set High/Low Temp. Notifications points before loading. -
Page 13: Shelving Configurations
SHELVING CONFIGURATIONS Refrigerator / Freezer 24" (61 cm) wide see Figure 13: Refrigerator: (2) Half width cantilever adjustable shelf. see Figure 14 (1) Roller glide clear crisper drawer Freezer: (1) Fixed position metal shelf, see Figure 15. Figure 14 Freezer compartment Figure 13 Figure 15... -
Page 14: Shelf Removal
SHELF REMOVAL To Add or Remove a Shelf Remove stored product from the shelf. Do not try to remove a loaded shelf from the appliance. Grasp the shelf front with both hands, rotate the front upward and lift out. (See Figure 17a). -
Page 15: Care And Cleaning
CARE AND CLEANING Front Grille Long Term Storage/Winterization (LN24REFC refrigerator freezer): ings in front of the cabinet. At least once or twice a year, 1. Time to Winterize, when the daily low ambient tempera- brush or vacuum lint and dirt from the front grille area (see ture is at or below 38°F (3.3°C). - Page 16 CARE AND CLEANING 17. Once the exterior has been thoroughly cleaned, you Start-Up After Long-Term Storage may want to apply a coating of car wax to help protect against spotting from moisture, dirt, and debris that 1. If stored outside, it is recommended that the unit again may accumulate on the surfaces during the Winteriza- be thoroughly inspected per the storage instructions tion period.
-
Page 17: Long Term Storage/Winterization
Long Term Storage/Winterization on the unit. 20. Wipe down all interior surfaces with anti-bacterial (LN24REFC, with optional ice maker): cleaner to be followed with clean rinse water to remove 1. Time to Winterize, when the daily low ambient tempera- any residual chemicals which could cause staining. Do ture is at or below 38°F (3.3°C). -
Page 18: Energy Saving Tips
CARE AND CLEANING AND ENERGY SAVING TIPS Start-Up After Long-Term Storage 1. If stored outside, it is recommended that the unit again be thoroughly inspected per the storage instructions above to address any dirt or debris from the weather and/or animals/insects. 2. -
Page 19: Stainless Steel Maintenance
• halide salts, (sodium chloride). please contact your dealer or call Lynx Grills Customer Service at 888.289.5969 for directions on how to obtain It is strongly recommended to periodically inspect and thor- warranty coverage in your area. -
Page 20: Troubleshooting
TROUBLESHOOTING Before You Call for Service NOTE If the appliance appears to be malfunctioning, read through shooting guide below. Locate the problem in the guide and Your product has an automatic defrost feature that utilizes refer to the cause and its remedy before calling for service. an electric heater element. -
Page 21: Troubleshooting Ice-Maker
TROUBLESHOOTING OPTIONAL ICE-MAKER Problem Possible Cause Remedy Unit operates but produces little or no • The unit has just been started and • Typical ice production is 6 to 7 ice. it has been less than 24 hours. pounds per day. Allow for the freezer section to reach tempera- ture and the ice-maker to cycle and accumulate ice. -
Page 22: Household Product Warranty
Undercounter refrigerators / Beverage Centers and all of their component parts, except as detailed below*†, are warranted to be free from defective materials or workmanship in normal residential use for a period of one (1) year from the date of original retail purchase. Lynx, warrantor, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period. - Page 24 The best outdoor kitchen products come from: Lynx Grills Service: (888)-289-5969 www.lynxgrills.com 41016166 Rev C the buyer to corresponding changes, improvements, additions, replacements or compensation for 11/12/24 previously purchased products.
