Sealey LED3601R Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
9
damaged DO NOT use.
Ensure the lamp is fully charged before initial use.
9
DO NOT charge in damp conditions.
8
DO NOT turn the lamp on when it is being charged.
8
DO NOT shine directly into your, another person's or an animal's eyes.
8
DO NOT allow children to use the lamp.
8
DO NOT handle or move the lamp whilst it is being charged.
8
DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
8
recharge the battery at least once every six months of non-use.
DO NOT attempt to open, disassemble, modify or service the battery pack.
8
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 60°C (140°F).
8
Replace only with the battery pack designated for this product.
9
Recycle or dispose of used battery as stipulated by local regulation.
9
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with
‰
cool water and seek immediate medical attention.
2. INTRODUCTION
Mini, lightweight light with exclusive patented design owned by and registered to Sealey. Unique and innovative 360° swivel and tilt
function enables the light source to be positioned in any direction. Featuring a super bright 3W COB LED light source, which gives
an even and constant spread of light. Produces up to 300 lumens with a CRI-80 rating. Recessed lens for added protection. 1W
SMD LED directional torch located on top of the light, produces up to 100 lumens. Rubber covered magnet in base and swivel hook
for hands-free operation. High quality rechargeable 3.7V 1.5Ah Lithium-Polymer battery for longer life. Supplied with Micro USB
cable.
3. SPECIFICATION
Model No:
Battery:
LED Type:
Lumen Output Side/Top:
CRI Rating: (Side):
Operating Time Side/Top:
Charging Time:
IP Rating:
Maximum Length:
Minimum Length:
The battery fitted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time. We will
provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear. If the
battery is not properly charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances we
will not replace the battery regardless of whether it is less than one year old.
NOTE: The lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without
another charge. (Not supplied with mains adaptor).
4. OPERATION
© Jack Sealey Limited
Original Language Version
360° 3W COB & 1W SMD LED RECHARGEABLE LITHIUM-
POLYMER INSPECTION LIGHT
MODEL NO: LED3601R.V3, LED3601G.V3, LED3601CF.V3, LED3601.V3
LED3601R, LED3601G, LED3601CF, LED3601
3.7V 1.5Ah Li-Poly
3W COB + 1W SMD
300/100lm
80
3/6hr
3hr
IP20
170mm
160mm
LED3601R.V3, LED3601G.V3, LED3601CF.V3, LED3601.V3. Issue:3 (H,3) 20/09/23
