Wood Chipper | GUO067
Operator's Manual
Warning: Please read and thoroughly understand all instructions before operating. Failure to follow
safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe and easily accessible place so that they can be referred to when needed. Retain
these instructions to assist in future servicing.
superhandyus.com
© SuperHandy All Rights Reserved | Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUO067 and is the answer not in the manual?

Questions and answers

Related Manuals for Landworks GUO067

Summary of Contents for Landworks GUO067

  • Page 1 Wood Chipper | GUO067 Operator’s Manual Warning: Please read and thoroughly understand all instructions before operating. Failure to follow safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe and easily accessible place so that they can be referred to when needed. Retain these instructions to assist in future servicing.
  • Page 2 1. WARNING AND SAFETY---------------------------------------------------------------------------------------------------------------- 1-4 2. TECHNICAL SPECIFICATIONS --------------------------------------------------------------------------------------------------------- 5 3. MAIN COMPONENTS --------------------------------------------------------------------------------------------------------------------- 6 4. ASSEMBLY ----------------------------------------------------------------------------------------------------------------------------- 7-10 5. OPERATION ---------------------------------------------------------------------------------------------------------------------------- 11-12 6. TRANSPORTING ------------------------------------------------------------------------------------------------------------------------- 12 7. MAINTENANCE AND STORAGE --------------------------------------------------------------------------------------------------- 12-14 8. WARRANTY ------------------------------------------------------------------------------------------------------------------------------- 15 9. TROUBLESHOOTING ------------------------------------------------------------------------------------------------------------------- 15 10.
  • Page 3 GENERAL OPERATING SAFETY 1. Read, understand, and follow all instructions in the manual and on the unit before starting. 2. Locate the Chipper/Shredder on a flat, level, sturdy surface capable of supporting the weight of the Chipper / Shredder and any additional tools and equipment. 3.
  • Page 4 9. Never continue to operate the machine if it starts making unusual noise or vibration. Shut the engine off immediately, allow the rotor to stop, disconnect the spark plug wire and secure the wire away from the spark plug.Inspect the unit for any signs of damage or foreign material in the chipping or shredding areas.
  • Page 5 Gasoline Fires and Handling Fuel Safety Use extra care in handling gasoline and other fuels. They are flammable and vapors are explosive. 1. When storing extra fuel be sure that it is in an appropriate container and away from any fire hazards. 2.

  • Page 6: Technical Specifications

    2. TECHNICAL SPECIFICATIONS SKU# GUO067 Chipping Capacity Max. 3" Chipping Knives Reduction Rate 15:1 Chipper Knife Material CR12MoV Hopper Dimensions 13.1"x10.8" Limb Chute Wheel Size 10"x3" Wheel Material Wheel Type SOLID Net Weight 96 Lb Gross Weight 109 Lb Assembled Dimension 53.5"x19.3"x33.5"...

  • Page 7: Main Components

    3. MAIN COMPONENTS Discharge Guide Plate Handle Discharge Chute Engine Recoil Starter Feed-in Chute Engine Support Wheel...

  • Page 8: Packing List

    4. ASSEMBLY Scan the QR code to watch the ASSEMBLY video. Packing List Equipment Body Engine Support Axle Feed-in Chute Discharge Chute Discharge Guide Plate Wheel Hardware M6x16 Bolt x2 M8x16 Bolt x4 M8x60 Bolt x4 M6 Nut x2 M8 Nut x4 Elastic Washer ø6 x1 Washer ø6 x1 Washer ø16 x2...

  • Page 9: Tools Required

    Tools Required Fig.01 Open-end wrench 10mm x2, 12mm x1, 13mm x1 (No included) Nipper x1 (No included) Step 1: Assemble the engine support and wheels (Fig.0.1) Parts: Wheel x2, Engine support, Axle INSIDE OUTSIDE Hardware: Cotter Pin ×2, ø16 Flat Washer ×2 Tools: Nipper (no included) 1) Recognize the wheel’s different sides.
  • Page 10 Step 3: Assemble the Feed-in Chute (Fig.03) Parts: Fed-in Bin Assembly Hardware: M8x16 Bolt x4 Tools: 12mm open-end wrench (no included) 1) Place the feed-in chute in the corresponding position of the equipment body. 2) Take the M8x16 bolt and fix the feed-in chute. 3) Use a 12mm open-end wrench to tighten 4 M8x16 bolts.
  • Page 11 Step 5: Assemble the Discharge Guide Fig.05 Plate (Fig.05) Parts: Discharge Guide Plate Hardware: M6x16 Bolt ×2, M6 Nut ×2, M6 Star head bolt ×1, ø6 Elastic Washer ×1, M6 Flat Washer ×1 Tools: 10mm open-end wrench ×2 (no included) 1) Fix the guide plate with 2 M6x16 Bolt and 2 M6 Nut, by two 10mm open-end wrench.

  • Page 12: Operation

    5. OPERATION DANGER 1. THE EXHAUST FROM THIS PRODUCT CONTAINS CARBON MONOXIDE GAS. CARBON MONOXIDE IS A COLOR- LESS, ORDERLESS AND TASTELESS GAS THAT CAN CAUSE DIZZINESS, NAUSEA, UNCONSCIOUSNESS OR EVEN BRAIN DAMAGE AND DEATH IF INHALED FOR PROLONGED PERIODS. 2.

  • Page 13: Maintenance And Storage

    Chipper Operation 1. Do not insert your hands into the feed-in chute while the equipment is running. 2. Wood chips are ejected at high speed during operation; do not allow the discharge direction to be aimed at operator. The discharge direction can be adjusted using the star head bolts. 3.
  • Page 14 Step 2: Loosen the another screw as red arrow, take off the Carburetor cap.(Fig.08) Fig.08 Fig.08 Step 3: Clean any debris inside Carburetor cap.(Fig.09) Fig.09 Fig.09 Step 4: 1) Unclog the fuel transfer hole as red arrow by air gun or thin needle.

  • Page 15: Recoil Starter

    CHIPPING KNIVES REPLACEMENT If the cutting performance of the equipment decreases, the feed-in chute can be disassembled to check if the blades are dull, worn, or broken, and then the blades should be replaced. Tools: 12mm open-end wrench，13mm Socket wrench. Note: When changing the blades, the engine must be turned off...

  • Page 16: Warranty

    8. WARRANTY Twelve (12) months for workmanship of the product, except for wearing parts. Warranty period starts from the product purchase date. Warranty covers material quality and workmanship only. Warranty does not cover product for issues caused by improper usage or any operation not in accordance with the specifications of this manual. Any modification or tampering with the product in any way voids the warranty.
  • Page 17 10. EXPLODED AND PARTS LIST Part No. Description Q’ty Part No. Description Q’ty Rubber Guard M8 nut Round pipe plug Washer-8 Feed-in chute Elastic Washer-8 M6x16 bolt M8x16 bolt M8x16 bolt Cover Assembly Engine Washer-10 Cushion blocks Elastic Washer-10 M8x20 bolt M0x25 bolt Cavity component Cotter pin 2.8x30...
  • Page 20 Great Circle USA Support Line: 1-866-493-0524 help@greatcircleus.com www.greatcircleus.com Size: 210x285mm 128克双铜 REV 10/24/24 3020407...
