GENERAL DESCRIPTION
The SGM8262-2 is a dual, low noise, high speed
operational amplifier with voltage feedback function.
The output swing is rail-to-rail with heavy loads. This
maximizes the dynamic range and offers high linearity.
The SGM8262-2 features 3.5nV/√Hz low voltage noise
at 100kHz with ultra-low distortion. It also has 22MHz
wide bandwidth at -3dB and 33V/μs high slew rate. The
device is unity-gain stable and has high output drive
capability.
The SGM8262-2 is available in Green SOIC-8 and
TDFN-3×3-8BL packages. It operates over an ambient
temperature range of -40℃ to +85℃.
SG Micro Corp
www.sg-micro.com
Rail-to-Rail Output, High Output Current Amplifier
High Speed, Ultra-Low Noise,
FEATURES
● Ultra-Low Noise:
Voltage Noise: 3.5nV/√Hz at 100kHz
Current Noise: 4pA/√Hz at 100kHz
● High Speed:
-3dB Bandwidth: 22MHz (G = +1)
Slew Rate: 33V/μs (R
● Unity-Gain Stable
● High Output Current with Excellent Linearity: 310mA
● High Open-Loop Gain: 110dB
● Rail-to-Rail Output
● Support Single or Dual Power Supplies:
4.5V to 36V or ±2.25V to ±18V
● -40℃ to +85℃ Operating Temperature Range
● Available in Green SOIC-8 and TDFN-3×3-8BL
Packages
APPLICATIONS
Audio Processing
General-Purpose AC Equipment
Twisted-Pair Wiring Drivers
SGM8262-2
= 32Ω)
LOAD
MARCH 2023 – REV. A. 1
