- Page 1 OWNER’S MANUAL ULTRAEDGE Propane Concrete Edger CLICK TO ORDER PARTS shop.monsterjanitorial.com...
-
Page 2: Important Safety Instructions
PG. 2 ULTRAEDGE IMPORTANT SAFETY INSTRUCTIONS places and away from any fire or flame producing device. READ and UNDERSTAND all instructions and Keep all objects clear of the exhaust system warnings before operating this machine! during and after operation. WARNING Do not leave this machine unattended while the engine is running. -
Page 3: Transporting The Machine
PG. 3 ULTRAEDGE DO NOT OPERATE THIS MACHINE IN AN All machines are equipped with a multi-function EXPLOSIVE ENVIRONMENT! maintenance meter. The functions include the following: hour meter, service alert and tachometer. THIS PROPANE MACHINE IS INTENDED FOR (See Engine Maintenance Meter instructions on pg. 7). -
Page 4: Operating Procedures
PG. 4 ULTRAEDGE A. Plate Assembly and Diamond Installation WARNING Resin Bond Metal Bond with 3 Screws NEVER CHANGE OR ALTER THE PROPANE CONTROL EQUIPMENT. SAFETY Provide and use ear protection during operation. Never let an untrained person operate or perform repairs on the machine. -
Page 5: Stopping The Engine
E. Installing the Fuel Cylinder switch to “Start”. Do not run starter for more than 20 seconds at a time. 1. Take UltraEdge to well ventilated area Allow 10-20 seconds between each 2. Check cylinder for overfill attempt to start the engine. -
Page 6: Maintenance
PG. 6 ULTRAEDGE MAINTENANCE E. Maintenance Schedule A. Gear Box Reducer Repairs and adjustments to the fuel system must be Lubrication and Maintenance. performed by an authorized, properly trained service Approved lubricant=Mobilgear 630 GL90 technician. To keep the machine in good working... - Page 7 PG. 7 ULTRAEDGE Servicing the UltraEdge Proper maintenance of the UltraEdge is the Remember that being safe is a full-time, every responsibility of the owner and/or the operator. day job. Follow all information posted on the Be sure to go through this checklist on a regular machine and the LPG tank.
- Page 8 PG. 8 ULTRAEDGE KAWASAKI 603cc ENGINE Oil Viscosity Tune-up Specifications Choose the viscosity according to the temperature as follows: ITEM SPECIFICATIONS Ignition Timing Unadjustable -20˚C -10˚C 0˚C 10˚C 20˚C 30˚C 40˚C Spark Plugs: NGK BPR4ES SAE40 0.75 mm (0.30 in)
- Page 9 PG. 9 ULTRAEDGE Supply engine oil as specified. Run the engine for about 3 minutes, stop engine, and check oil leakage around the filter. Add oil to compensate for oil level drop due to oil filter capacity (See “Preparation” for oil level check on pg.
-
Page 10: Engine Troubleshooting
PG. 10 ULTRAEDGE ENGINE TROUBLESHOOTING COMMON PROBLEMS & PROBABLE CAUSES SOLUTIONS Engine cranks but will not start Fuel cylinder is empty Refill cylinder Shutoff valve is closed Open valve Clogged, obstructed, kinked or cut fuel or vacuum line Remove obstruction or replace line... - Page 11 PG. 11 ULTRAEDGE BODY ASSEMBLY PARTS DESCRIPTION PART # BELT 113-BP72 1/2-13 LOCK NUT 164-22836 041-BA-02P FLAT IDLER PULLEY 1/2-13X3 BOLT 164-JOC300HCS5Z BELT TENSIONER 011-6-2795 PULLEY (GEAR BOX) 172-041 GEAR BOX 041-953 SPACER BLOCK 283-041-20 VACUUM CAP 040-3015 BELT COVER...
- Page 12 PG. 12 ULTRAEDGE HANDLE ASSEMBLY PARTS DESCRIPTION PART # HANDLE STRUT 283-040-600 WIRE HARNESS 011-762WHK STARTER SOLENOID 296-SS-581 BATTERY BOX BOTTOM 283-11-2127B BATTERY 12V 276-GTX14 BATTERY BOX TOP 283-11-2127T LOCK PIN 625-98404A385 KEY SWITCH 312-308-0385 LANYARD KILL SWITCH 153-73459 HANDLE GRIP...
- Page 13 PG. 13 ULTRAEDGE WHEEL AXLE ASSEMBLY PARTS DESCRIPTION PART # AXLE NUT 164-36869 1/2-13X2 HCS 164-110120382 1/2” FLAT WASHER 164-20159 ADJUSTMENT SIDE BAR 283-040-1000 3/8-16X1 HCS 164-10115 5/16” FLAT WASHER 164-20156 3/8-16 STOVER LOCK NUT 164-22834 1/2-13X5” BOLT 164-5OC500BTA5Z 1/2” FLAT WASHER...
- Page 14 PG. 14 ULTRAEDGE DIAMOND DRIVERS PARTS DESCRIPTION PART # 3/8-16X2¼ FSCS 164-37C225KSCST 3/8-16X2½ FSCS 164-37C25KSC DRIVE PLATE 283-040-2255 MOUNT SPACER 283-040-2220 3/8-16 STOVER LOK NUT 164-22834 HUB RING 283-040-2215 FLEX PLATE 040-2210 283-040-2230 3/8-16X1¼ HCS 164-10117-SS MOUNT RING 283-040-2245 3/8-16 HEX NUT...
- Page 15 PG. 15 ULTRAEDGE FUEL SYSTEM PARTS DESCRIPTION PART # QUICK CONNECT 152-700 LPG HOSE 20” 267-P5561-0410 FUEL LOCK OUT 12V 152-N3-0173-1 HOSE BARB FITTING 166-62039 LPG REGULATOR 152-500...
- Page 16 You have purchased a quality product. Each of its components has been tested and approved for use by Aztec Products, Inc. It is unlikely that you will ever have a warranty claim if you properly maintain our machine.
