EONE EXTREME Series Installation Instructions & Warranty Information
Hide thumbs
Also See for EXTREME Series:
Subscribe to Our Youtube Channel
Related Manuals for EONE EXTREME Series
Summary of Contents for EONE EXTREME Series
- Page 1 FIBERGLASS Typical Installation Instructions & Warranty Information Simplex, Duplex, Triplex, & Quadplex Grinder Pump Stations INSTALLATION...
-
Page 2: Safety Instructions
Safety Instructions Please read prior to the installation and operation of pump. The information provided is for SAFETY and to help PREVENT DO NOT pump hazardous To reduce risk of electrical shock, EQUIPMENT PROBLEMS. always disconnect the pump from materials (fl ammable, caustic, etc.) all power sources before handling To help you understand this DO NOT wear loose... - Page 3 Environment One Grinder Pump Feature Identification 1. Electrical Quick Disconnect (EQD) – Electrical lead from pump core terminates here (NEMA 6P). 2. Power and Alarm Lead – Circuits to be installed in accordance with local codes. 3. Alarm Panel – Rainproof (NEMA 4X) enclosure. Equipped with circuit breakers. Locate according to local codes.
- Page 4 1 - 4 in MAIN AC SOURCE FEED SEAL CONDUIT PER NEC SECTION 300.5 & 300.7 6-12 INCH SETTLING LOOP 5 x2 Figure 1 FAILURE TO COMPLY WITH INSTALLATION INSTRUCTIONS WILL VOID WARRANTY...
- Page 5 TYPICAL MULTI- PUMP STATIONS: DUPLEX, TRIPLEX & QUADPLEX Simplex 1 Simplex Panel Duplex 1 Duplex Panel Triplex 1 Simplex Panel, 1 Duplex Panel Quadplex 1 Quadplex Panel...
- Page 6 This is a sewage handling sewer line intersects the tank engineer’s recommendation. pump and must be vented in wall. The center of the inlet Place the ballasted tank in accordance with local plumbing pipe must be a minimum the excavated hole using the of 30 inches from bottom lifting hooks.
- Page 7 inlet pipe. The grommet is pipe and grommet are installed organic material may be used if self-sealing and does not properly. compacted in lifts not to exceed require the use of additional 5. Vent Installation: A one foot. It must be compacted sealant or adhesives.
- Page 8 RETAINING LOWER END CLIPS (4) OF PUMP SUCTION HOUSING INLET SHROUD STAND MOUNTING HOLES (4) BEND IN LEG FLUSH WITH STAND SURFACE HALVES Figure 4 Figure 3 Power at the station must not drop more than 10% below the nameplate voltage. Maximum Recommended Length: 120 Volt 60’...
- Page 9 1" NPT THREADS FOR SLIDE FACE REMOVAL TOOL MALE ADAPTER O-RING GREASE FACE OF SLIDE FACE AFTER O-RING IS INSTALLED 1 1/4" NPT FITTING TO ATTACH TO PUMP DISCHARGE Figure 7 Figure 8 Figure 9 protective conduit.) the grinder pump. The supply Failure to tighten the cord cable cord grip provides a leak Locate and mark the...
- Page 10 10. Stand Assembly: (Fig. 4) assembly to open. (Fig. 9) Power source to the panel Temporarily rest the grinder Hang power cable, breather must be 240 VAC (or 120 VAC pump on its side. Using a block tubing with Equalizer, and for a 120V model).
- Page 11 All of these tests must read including service manuals visit an open circuit. A short at any eone.com/technician. of these test points will cause Higher amperage readings premature pump failure if not equal a higher discharge corrected. pressure. If the amperage...
- Page 12 Grinder Pump Station Ballast Calculations Any buried vessel that is submerged, or partially submerged, in water will be acted on by an upward buoyant force that attempts to return the vessel to a non-submerged state. The magnitude of this buoyant force is equal to the volume of the vessel that is submerged multiplied by the density of water.
- Page 13 Chart 2 *Ballast is calculated with ground water at grade STATION CONCRETE WEIGHT STATION STATION DIAMETER CONCRETE CONCRETE STATION DIAMETER (pounds) VOLUME BUOYANT BALLAST MODEL MATERIAL HEIGHT (inches) VOLUME WEIGHT TYPE (inches) station, (cubic FORCE FORCE (inches) (ballast 10" (cubic feet) (pounds) cover, feet)
- Page 14 Scan code for service info at eone.com/technician A Precision Castparts Company Environment One Corporation 2773 Balltown Road · Niskayuna, New York 12309–1090 Tel: (01) 518.346.6161 · Fax: (01) 518.346.6188 eone.com Copyright © 2025 by Environment One Corporation ALL RIGHTS RESERVED. This book contains material protected under International and Federal Copyright Laws and Treaties.
- Page 15 User Instructions for the Environment One Grinder Pump General Information Care and Use of Your Grinder Pump Your home is served by a low pressure sewer The Environment One grinder pump is capable of system; the key element is an Environment One accepting and pumping a wide range of materials, and grinder pump.
-
Page 16: Limited Warranty
For More Information Scan QR Code or Visit: eone.com/sewer-systems/knowledge/warranty Notes 2773 Balltown Rd • Niskayuna NY USA 12309 (01) 518.346.6161 • www.eone.com...
