SERVICE MANUAL
The above models are classified as green products (*1), as indicated by the underlined serial numbers.
This Service Manual describes replacement parts for the green products. When repairing these green
product(s), use the part(s) described in this manual and lead-free solder (*2).
For (*1) and (*2), see the next page.
HD DVD PLAYER
HD-XE1KE
HD-XE1KY
FILE NO. 810-200695GR
Dec., 2006 GREEN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD-XE1KE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toshiba HD-XE1KE

Summary of Contents for Toshiba HD-XE1KE

  • Page 1 FILE NO. 810-200695GR SERVICE MANUAL HD DVD PLAYER HD-XE1KE HD-XE1KY The above models are classified as green products (*1), as indicated by the underlined serial numbers. This Service Manual describes replacement parts for the green products. When repairing these green product(s), use the part(s) described in this manual and lead-free solder (*2).
  • Page 2 Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any market- ing of new products containing the restricted substances. Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING: BEFORE SERVICING THIS CHASSIS, READ THE ＂SAFETY PRECAUTION＂ AND ＂PRODUCT SAFETY NOTICE＂INSTRUCTIONS BELOW. SAFETY PRECAUTION WARNING: SERVICE SHOULD NOT BE ATTEMPTED BY ANYONE UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER. THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED BEFORE SERVICING THIS CHASSIS.

  • Page 4: Touch Current Check

    Touch current check (After completing the work, measure touch current to prevent an electric shock.) ・Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.. ・Connect a measuring network for touch currents between each exposed metallic part on the set and a good earth ground such as a water pipe, as shown in Figure D.1 ・The potential at any point(TOUCH CURRENT) expressed as voltage U and U...

  • Page 5: Product Safety Notice

    PRODUCT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this manual and its supplements;...

  • Page 6: Laser Beam Caution Label

    LASER BEAM CAUTION LABEL When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of a laser may be received. PREPARATION OF SERVICING Pickup Head consists of a laser diode that is very susceptible to external static electricity. Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement, its life might be shortened.

  • Page 7: Table Of Contents

    CONTENTS SECTION 1 GENERAL DESCRIPTIONS 1. OPERATING INSTRUCTIONS 2. LOCATION OF MAIN PARTS 2-1. Location of Main Parts 2-2. Location of PC Boards SECTION 2 PART REPLACEMENT PROCEDURES 2. WIRING CONNECTION DIAGRAM 1. REPLACEMENT OF MECHANICAL PARTS 1-1. Front Panel, Front PC Boards 2-1.

  • Page 8: Section 1 General Descriptions

    SECTION 1 GENERAL DESCRIPTIONS 1. OPERATING INSTRUCTIONS Please refer to the owner's manual about the contents.

  • Page 9: Location Of Main Parts

    2. LOCATION OF MAIN PARTS 2-1. Location of Main Parts RAM1 DVD Drive FAN1 Fan Fig. 1-2-1 2-2. Location of PC Boards PWR1 Power PC board U003 ATAPI PC board FRS1 RS232C PC board U001 Main PC board PSW1 Power Switch PC board LED1 Front D-Light PC board FSW1 Front Switch/USB PC board U002 Front FIP PC board...

  • Page 10: Section 2 Part Replacement Procedures

    SECTION 2 PART REPLACEMENT PROCEDURES CAUTIONS BEFORE STARTING PART REPLACEMENT Electronic parts are susceptible to static electricity and may easily damaged, so do not forget to ground as required. Many screws are used inside the unit. To prevent the screws from missing or dropping, etc. always use a magnetized screwdriver in servicing.

  • Page 11: Main/Power Pc Boards

    1-2. Main/Power PC Boards Power PC Board Main PC Board RS232C PC Board Fig. 2-1-2...

  • Page 12: Dvd Drive

    1-3. DVD Drive ATAPI PC Board DVD Drive Fig. 2-1-3...

  • Page 13: Wiring Connection Diagram

    2. WIRING CONNECTION DIAGRAM 2-1. Wiring Connection Diagram After the servicing is complete, return the wiring to its original state by using the diagram below as a reference. RS232C PC board W104 W105 W102 Main PC board Power PC board ATAPI PC board W004 W103...
  • Page 14 2-2. Supplementary Instructions for Reassembling A-1. Fix the wire (W103) with two tapes (TAPE-PET-W10-L50). A-2. Fix the FFC (W104) with the tape (TAPE-PET-W10-L50). W103 W104 A-3. Fix the wire (W004) with the tape (TAPE-PET-W10-L50). (Fixed position : Between CN405 and C60D) W004 Fix (Between CN405 and C60D)
  • Page 15 B-1. Paste the gasket to 4 places of the upper surface of front panel. B-2. Paste gaskets to the following positions in the lower side of DVD drive. (Gasket : SSTG10-10 L25HC(GD9D00000080) Paste the gasket just behind folded FFC.
  • Page 16 B-3. Paste gaskets to the following positions in the upper side of DVD drive. (Gasket : SSTG10-10 L25HC(GD9D00000080) Paste gasket to the position where a semicircle part of the hole of molde this DVD drive correspond to the edge of Gasket. B-4.
  • Page 17 C-1.Attach ferrite core Z001F(PM0007982010:ZCAT2132-1130) to the power code. Roll the power code twice. (HD-XE1KE has two power codes. Attach ferrite core on each power code.) Fixed C-2.Attach ferrite cores(HF70SH22*0.8*7:PM0009691010) for FFC(W001,W002,W003) of between Front and Main. Fix three cores with the tape respectively (TAPE-PET-W10-L50).
  • Page 18 D-1.Paste the aluminum tapes to the position of A, B, and C. Position A : 25mm(Tape Width) X 30mm Position B : 25mm(Tape Width) X 50mm Position C : 25mm(Tape Width) X 7mm 30mm 30mm 50mm D-2.Twist W103. D-3.Fix the wire (W103) to the following position (A and B) with two aluminum tapes (GY4D00000030, Parts Name: AL-25T, Tape Width : 40mm).
  • Page 19 D-5.Press W005 to PCB side. W005 D-6.Twist W104. W104...

  • Page 20: Section 3 Servicing Diagrams

    SECTION 3 SERVICING DIAGRAMS 1. CIRCUIT SYMBOLS AND SUPPLEMENTARY EXPLANATION 1-1. Precautions for Part Replacement • In the schematic diagram, parts marked (ex. • Using the parts other than those specified shall violate the regulations, and may cause troubles such as F801) are critical part to meet the safety regulations, so operation failures, fire etc.

  • Page 21: Inductor Indication

    1-4. Inductor Indication Eg. 4 ... Η Unit None µ ... µH ... mH Tolerance None ... ±5% ... ±0.1% ... ±0.25% ... ±0.5% ... ±1% ... ±2% Type name ... ±10% ... ±20% Fig. 3-1-4 1-5. Waveform and Voltage Measurement Eg.

  • Page 22: Printed Wiring Board And Schematic Diagram

    2. PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM W106 WIRE memo FPS1 PSW1 U002 PSW1 W001 FFC 12 L110 FRONT_RS232C PWR_ Ritgh Angle CN106 CN107 SW_USB UNIT FRONT FIP UNIT W002 FFC 20 L110 CN101 SW UNIT E+5V W003 FFC 16 L110 Power_LED W004 FFC 40 L250...

  • Page 23: Block Diagrams

    3. BLOCK DIAGRAMS Front Unit USB*2 14.31318MHz X'tal 256MB Clock Gene. HD-DVD DDR SDRAM 3.3V<->5VTrans. ICS950812 512Mb*4 100MHz Thermal Sensor 48MHz33MHz ADM1032AR DDR333 100MHz Timer USB1.1 32.768KHz Buffer uCOM Driver uPD78F0534 UART1 232C(8pin) EMMA3 GB(S)-UEU-A EJTAG interface JTAG(10pin) RS232C 48MHz ICH4-M N-Wire interface *2 N-Wire(TP only)

  • Page 24: Circuit Diagrams

    4. CIRCUIT DIAGRAMS 4-1. Power Supply Circuit Diagram Fig. 3-4-1...

  • Page 25: Front Circuit Diagram

    4-2. Front Circuit Diagram 4-2-1. Front FIP Circuit Diagram Fig. 3-4-2...

  • Page 26: Power Switch Circuit Diagram

    4-2-2. Power Switch Circuit Diagram Not use Fig. 3-4-3...

  • Page 27: Front Switch/Usb Circuit Diagram

    4-2-3. Front Switch/USB Circuit Diagram Not use Fig. 3-4-4...
  • Page 28 4-2-4. Front D-Light Circuit Diagram Fig. 3-4-5...

  • Page 29: Rs232C Circuit Diagram

    4-3. RS232C Circuit Diagram Fig. 3-4-6...
  • Page 30 4-4. Main Circuit Diagram Note : The main circuit diagrams describe only part of information. 4-4-1. AV Output Circuit Diagram VCC+12V VEE-5V E+5V QA21 EA15 2SA1213 EA18 E+6V EA07 CA50 006 007 008 010 801 802 805 807 808 809 813 819 RA96 PWPON-M5P NOISE...
  • Page 31 4-4-2. Timer Circuit Diagram R781 R780 R782 R783 CPU+5V VOUT L704 CPU+5V E753 MMZ1608S601 C722 B0.01u C726 C724 E754 F0.1u 47uF16V X701 CN705 X702 AT-41-20M E+5V 52808-1671 SP-T2A R725 R778 C720 FL+5V B0.01u(1608) R776 R747 L707 R775 820k MMZ1608S601 R774 CN701 R732 P_CORE...
  • Page 32 4-4-3. Video Scaller Circuit Diagram SCALER-DDR_VREF VTT(REON) EP35 SCALER-VDD2.5V CP06 ICP03 B0.1u CP08 B0.01u VREF VDDQ MCLK CP07 B0.01u VDDQ MCLKN CP57 B0.01u SCALER-VDD2.5V VDDQ ICP01 MCLKE CP167 B0.01u EP17 VDDQ RP56 MDQS[4] MDQS[4] CP59 B0.01u PQ025EZ02ZPH DQS0 VDDQ CP101 RP57 MDQS[5] MDQS[5]...
  • Page 33 4-4-4. Video Output Circuit Diagram CX24 RX36 ICX09 VCC+5V VCC3.3V E+6V TPX01 RX35 CX73 MM1565AF B0.1u EX09 VCC+12V Mute1 COUT EX10 ICX03 RX49 4.7k CX25 PWPON-M5P MM1561J VSAG RX66 RX65 TPX02 CX11 005 006 007 008 801 802 805 807 808 809 813 819 YCMIX EX14 VOUT...

  • Page 34: Atapi Conversion Circuit Diagram

    4-5. ATAPI Conversion Circuit Diagram Fig. 3-4-11...

  • Page 35: Power Switch Pc Board

    5. PC BOARDS 5-1. Front FIP PC Board A100 Fig. 3-5-1 Front FIP PC Board (Top side) Fig. 3-5-2 Front FIP PC Board (Bottom side) 5-2. Power Switch PC Board CN101 Fig. 3-5-3 Power Switch PC Board (Top side) Q102 C118 Q101 Fig.
  • Page 36 5-3. Front Switch/USB PC Board 5-4. ATAPI PC Board IC102 W103 S108 J101 J102 S103 Fig. 3-5-5 Front Switch/USB PC Board (Top side) Fig. 3-5-7 ATAPI PC Board (Top side) Fig. 3-5-6 Front Switch/USB PC Board (Bottom side) Fig. 3-5-8 ATAPI PC Board (Bottom side)
  • Page 37 5-5. D-Light PC Board Fig. 3-5-9 D-Light PC Board (Top side) Fig. 3-5-10 D-Light PC Board (Bottom side) 5-6. RS232C PC Board CN108 Fig. 3-5-11 RS232C PC Board (Top side) C106 Fig. 3-5-12 RS232C PC Board (Bottom side)

  • Page 38: Section 4 Parts List

    SECTION 4 PARTS LIST SAFETY PRECAUTION The parts identified by ! ( ) mark are critical for safety. Replace only with part number specified. The mounting position of replacement is to be identical with originals. The substitute replacement parts which do not have the same safety characteristics as specified in the parts list may create shock, fire or other hazards.

  • Page 39: Exploded Views

    EXPLODED VIEWS 1-1. Packing Assembly Z012 Z011 Z010 Z006 Z001 (HD-XE1KE) Z002 Z001A (HD-XE1KE) Note: The shape of the packing material is sometimes different. Fig. 4-1-1...

  • Page 40: Chassis Assembly

    1-2. Chassis Assembly CAL1 PALL PALR B300 U003 W004 FRS1 W102 W105 RAM1 PWR1 FAN1 CND01 LED1 W101 PSW1 W106 W104 A001 W001 U001 W103 W003 FSW1 W002 U002 Fig. 4-1-2...

  • Page 41: Parts List

    W104 P000477560 WIRE CABLE PHR-4P-L260 MAIN-POWER W105 P000479150 WIRE CABLE PHR-4-AWG26-L190-ZHR-4 W106 P000479160 WIRE CABLE PHR-2-AWG26-L50-PHR-2 Z001 P000354930 CORD POWER, UK-SET HD-XE1KE Z001A P000477770 CORD POWER, TE-SET HD-XE1KE Z001 P000480900 CORD POWER, TY-SET HD-XE1KY Z002 P000479140 REMOTE CONTROL, SE-R0251 Z006...

  • Page 42: Supplement1. Firmware Version Update

    SUPPLEMENT SUPPLEMENT1. Firmware Version Update We plan to respond to these developments by providing the firmware update. The latest information will be informed Toshiba customer support on the WEB. 1) Main Firmware 2) HD DVD Drive Firmware 1. HD DVD Player FW Update To update the firmware, the following procedures are provided.
  • Page 43 4. Firmware Update Procedure (1) Main (or Drive) FW Update by CD-ROM disc 1) Insert Update disc into the unit. 2) Indicate the notice. -> Select YES & press “OK” button on the remote control. 3) Version update is started. Waiting a few minutes. 4) Tray will be opened and power off automatically.

  • Page 44: Supplement2. Error Code

    Playback is prohibited. The playback is stopped. AACS Error Error Code AACS Error Failed to verify the content. The playback is stopped. Error Code Management system error occurred. Please call Toshiba AACS Error Customer Support. Error Code AACS Error System error occurred.
  • Page 45 Playback is prohibited. The playback is stopped. AACS Error Error Code Failed to verify the content. The playback is stopped. AACS Error Error Code Management system error occurred. Please call Toshiba AACS Error Customer Support. Error Code AACS Error System error occurred.
  • Page 46 2. Update Error Error Code Remark Contents of Error Decryption Error Decryption Error Same Version file read error file read error Memory Error Memory Error File Error Network Error Wrong Network Setting Proxy Error Wrong Network Setting Proxy Error Wrong Network Setting Proxy Error LAN connection error connect error...
  • Page 47 Error Code Remark Contents of Error not valid time clock setting long path name verification error server error line busy server error line busy server error line busy SSL error data size error data size error Drive Error Drive manufacturer Error Drive Error Drive Error Drive Error...

  • Page 48: Supplement3. Troubleshooting

    SUPPLEMENT3. TROUBLESHOOTING 3-1. Standby LED (red) does not light. START (1) E+5V supplied to pin 16 of Power_LED on pin 2 of Replace PWR_SW unit. CN601 from power unit? CN702 is “L”? Replace power unit. Failure of main unit. 3-2. LED (green) does not light at power on.

  • Page 49: Cpu Fan Does Not Work

    3-3. CPU FAN does not work. START (3) Pin 1 of CN803 develope Replace FAN unit. 12V±5%? Power circuit troubleshooting 3-4. Indicator does not light. (“WELCOME” does not light at startup.) START (4) Pin 1~4 of IC705 VFD driver IF bus working at startup? PIN 20 of CN601 Replace front FIP...

  • Page 50: System Does Not Run. ("Welcome" Displayed And Key Operation Disabled)

    3-5. System does not run. (“WELCOME” displayed and key operation disabled) START (5) E602(VCC+3.3V) voltage TP414 is "H" (3.3V)? output correctly? Power circuit troubleshooting Failure of main unit Connector (CN403) of DVD drive and power connector connected correctly? Check CN403 connection and replace FFC cable.

  • Page 51: No Picture Appears

    3-6. No picture appears. • Before repair, confirm the connection with a TV set and the settings of DVD player. START (6) Check HDMI troubleshooting.(3-6-1) All analog (video, S-video, Check "MODE" switch in case of HD-XA2/XE1. component) and HDMI do Check and replace cable.

  • Page 52: No Audio Is Played Back

    3-7. No audio is played back. • Before repair, confirm the connection with a TV set and the settings of DVD player. START (7) Check and replace AV cable. All analog, digital, and Check and replace HDMI cable. HDMI audio are not Check and replace optical and coaxial cable.

  • Page 53: Extension Port Does Not Work

    3-9. Extension port does not work. START (9) Check and replace CN402 cable Neither right port nor (W101) or replace front SW_USB unit. left port works? Either one port does not work. Device to be connected is Check the device supported by this mode. supported? Failure of main unit...

  • Page 54: Front Panel Keys/Remote Control Are Disabled

    3-10. Front panel keys/remote control are disabled. START (10) Front Power LED lighting? Change power unit. Check and replace CN703 FFC (W001) cable. PJ7 connected correctly? Replace front SW_USB unit. Failure of main unit 3-11. Other Symptoms • Improper LAN connection LAN depends on the quality of the environment and lines to which LAN is connected.

  • Page 55: Power Circuit Troubleshooting

    3-12.Power Circuit Troubleshooting START (11) “H” Power unit ON/OFF control signal check PS_ON(Pin 1 of CN601). “L” Power system voltage Power Measuring points Output voltage VCC3.3V E602 +3.3 ±0.16V Failure of connector VCC+5V E603 +5.0 ±0.25V (CN601) and/or power unit E+6V E604 +5.8 ±0.3V...

  • Page 56: Specifications

    SPECIFICATIONS Power requirement 50.0W Power supply 220-240V AC 50/60Hz Mass 6.2kg External dimension Width 438 x Height 74.4 x Depth 344mm Signal system Standard PAL/NTSC colour TV system Laser Semiconductor laser, Wavelength: 405nm/650nm/780nm VIDEO output 1.0Vp-p (75Ω), Sync signal negative, Pin jack x 1 system S-VIDEO output (Y) 1.0Vp-p (75Ω), Sync signal negative, (C) 0.286Vp-p (75Ω), 1 at rear...
