Operator's Manual
LIGHT DUTY ELECTRIC
MATERIAL HOISTS
For EH-250 & SPH-250
Material Hoists
IMPORTANT:
Retain this manual for instruction on
assembly and operation of hoist.
READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING TO
ASSEMBLE OR OPERATE YOUR SAFETY HOIST. FAILURE TO
COMPLY WITH INSTRUCTIONS MAY CAUSE THE HOIST TO
MALFUNCTION AND MAY RESULT IN PERSONAL INJURY.
info@safetyhoistcompany.com • (610) 941-4333 • www.safetyhoistcompany.com
Version 0225
Advertisement
Table of Contents
Related Manuals for Safety Hoist EH-250
Summary of Contents for Safety Hoist EH-250
- Page 1 Retain this manual for instruction on assembly and operation of hoist. READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE YOUR SAFETY HOIST. FAILURE TO COMPLY WITH INSTRUCTIONS MAY CAUSE THE HOIST TO MALFUNCTION AND MAY RESULT IN PERSONAL INJURY.
-
Page 2: Table Of Contents
HOW TO OPERATE YOUR HOIST ....................... 9 INSTALLING THE SOLAR PANEL CRADLE (SPH-250) ................10 MOTOR RECOMMENDATIONS ........................ 11 DISASSEMBLING, STORAGE, & TRANSPORTATION ................12 SAFETY HOIST COMPANY - LIMITED WARRANTY ................13 IMPORTANT: Retain this manual for instruction on assembly and operation of hoist. -
Page 3: Hoist Components
Operator’s Manual EH-250/SPH-250 Platform Material Hoist HOIST COMPONENTS EH-250 1. ONE (1) - Power Unit (hoist bolted on base) (includes a storage compartment) 2. ONE (1) - Power cord with screw connection 3. ONE (1) - Pendant with screw connection 4. -
Page 4: Parts List
Extend brace to middle of hoist, or as far as can be reached. Bolt brace together. Attach support head of brace to track using clamps provided. EH-250 & SPH-250 MATERIAL HOIST AVAILABLE PARTS LIST Part Number Description... -
Page 5: Important Safety Notices
WET WEATHER CONDITIONS!!! A. PROPER INSTRUCTIONS DO NOT ALLOW ANYONE TO OPERATE THE HOIST WHO HAS NOT BEEN PROPERLY AND THOROUGHLY TRAINED IN ITS OPERATION AND USE. BEFORE OPERATING, YOU MUST WATCH THE EH-250/SPH-250 OPERATIONS TUTORIAL AT SAFETYHOISTCOMPANY.COM/PAGES/TUTORIALS-EH250. B. WARNING: ONLY USE THIS HOIST FOR LIFTING MATERIALS. -
Page 6: General Safety Recommendations
Operator’s Manual EH-250/SPH-250 Platform Material Hoist GENERAL SAFETY RECOMMENDATIONS The safety instructions and warnings in this section and throughout this manual must be read carefully before assembling or operating the hoist. These safety instructions and warnings are not substitutes for routine accident prevention measures, which must also be implemented to eliminate potential risks and hazards. -
Page 7: Hoist Setup Instructions
HOIST SETUP INSTRUCTIONS ***IMPORTANT*** EVERY TIME A SAFETY HOIST IS SET UP FOR OPERATION YOU MUST: Check the condition of the electric hoist before connecting the pendant and the power cords. Inspect winch drum and cable assembly for obvious damage or misalignment. Inspect winch drum to make sure that cable is wound smoothly with no crossovers. -
Page 8: How To Assemble Your Hoist
Operator’s Manual EH-250/SPH-250 Platform Material Hoist HOW TO ASSEMBLE YOUR HOIST Unpack ALL parts of the hoist and lay them flat on the ground. See page one for a list of included parts and materials. If any parts are missing, call (610) 941-4333. - Page 9 Operator’s Manual EH-250/SPH-250 Platform Material Hoist HOW TO ASSEMBLE YOUR HOIST Continued Slide the carriage along the track to the base section so that the bumpers rest on the carriage stops. Make sure the carriage slides smoothly on the track.
- Page 10 Operator’s Manual EH-250/SPH-250 Platform Material Hoist HOW TO ASSEMBLE YOUR HOIST Continued You are now ready to lift the hoist into place. Height to Max. Hoist Length “C” Bearing Horizontal WARNING: When setting up your hoist please Point “A” Distance “B”...
-
Page 11: How To Operate Your Hoist
Operator’s Manual EH-250/SPH-250 Platform Material Hoist HOW TO OPERATE YOUR HOIST THE OPERATOR OF THE HOIST MUST WEAR ALL THE NECESSARY PERSONAL PROTECTIVE EQUIP- MENT (PPE) WHICH SHOULD INCLUDE FOOT, HAND, EYE, AND HEAD PROTECTION. KEEP HANDS AWAY FROM ALL MOVING PARTS AT ALL TIMES. SEE PAGE 3 FOR IMPORTANT SAFETY NOTICES. -
Page 12: Installing The Solar Panel Cradle (Sph-250)
Operator’s Manual EH-250/SPH-250 Platform Material Hoist INSTALLING THE SOLAR PANEL CRADLE (SPH-250) Remove the flat panel cradle and hardware bag from the box. Lift the solar panel cradle into place on the carriage [make sure the straps are facing the track and the pitch is facing you]. You will know this is correct when the holes on the Flat Panel Cradle line up with the holes on the carriage. -
Page 13: Motor Recommendations
Operator’s Manual EH-250/SPH-250 Platform Material Hoist MOTOR RECOMMENDATIONS SEE SEPARATE OPERATION MANUAL - ELECTRIC WIRE ROPE HOIST - ACCOMPANYING THIS MANUAL. info@safetyhoistcompany.com • (610) 941-4333 • www.safetyhoistcompany.com... -
Page 14: Disassembling, Storage, & Transportation
Operator’s Manual EH-250/SPH-250 Platform Material Hoist DISASSEMBLY, STORAGE AND TRANSPORTING HOIST AFTER A JOB Unwind the cable with a gloved hand, providing enough slack to remove the power pack. Then place it on the ground. Move the hoist away from the building. Remember to look out for--and avoid--any overhead wires of any kind, especially power lines. -
Page 15: Safety Hoist Company - Limited Warranty
REPLACES ALL DATED OR UNDATED LIMITED WARRANTIES DATED BEFORE JUNE 25, 2017. Safety Hoist Company will, at its option, repair or replace any part or parts of the Safety Hoist material hoist that are defective in material or workmanship, with the exclusion of the motor/engine, which maintain a separate warranty provided by the manufacturer of the motor/engine. - Page 16 More From Gas Material Hoists Electric Material Hoists SteepSlope Scaffold Safety Hoist Company • 604 Jeffers Circle• Exton, Pennsylvania 19431 www.safetyhoistcompany.com • info@safetyhoistcompany.com...
