- Page 1 humiFog Multizone Touch Oil-free pumping station INSTALLATION MANUAL NO POWER & SIGNAL CABLES TOGETHER READ CAREFULLY IN THE TEXT! humiFog Multizone Touch Oil-free...
- Page 2 The technical speci- fications shown in the manual may be changed without prior warning. The liability of CAREL in relation to its products is specified in the CAREL general contract conditions, published on the website www.carel.com and/or by specific agreements with customers;...
- Page 3 Index 1. Purpose of the manual ..........7 2. How to read the manual .......... 7 3. General safety information and instructions ..8 3.1 Intended use ......................8 3.2 General safety instructions .................8 3.3 Personal protective equipment ...............9 4. Introduction ............. 10 4.1 Components .....................
-
Page 4: Purpose Of The Manual
Brugine - Padova (Italy) Tel. (+39) 049.9716611 - Fax (+39) 049.9716600 e-mail: carel@carel.com - www.carel.com 2. HOW TO READ THE MANUAL The manual is divided into chapters and paragraphs. Each paragraph is a sub-level of the corresponding chapter. References to headings or paragraphs are indicated by the abbreviation “Chap. -
Page 5: Intended Use
AHU (air handling unit), and for direct humidification or cooling in rooms. CAUTION: The product must only be used for its intended purpose, as envisaged by CAREL. CAREL declines all liability, both contractual and extra-contractual, for any damage to people, animals or things due to installation, control or maintenance errors or improper use. -
Page 6: Personal Protective Equipment
Personal protective equipment DANGER Strictly follow the instructions provided in the manual. Personal protective equipment (PPE) means any equipment intended to be worn and kept by workers in order to protect them- selves against one or more risks likely to threaten their health or safety during work, as well as any device or accessory intended for this purpose. -
Page 7: System Layouts
• to connect the pumping station to the blowers, use the water circuit assemblies and electrical panels supplied separately by Carel (see the list of accessories); • to facilitate commissioning, plates already equipped with electrical connectors are available for simply and quickly connecting the electrical panels to the solenoid valves on the distribution manifolds. - Page 8 Internal rack valves Fig. 4.a Ref. Description Pumping station Electrical cables Distribution manifolds Zone panel Droplet separator Drain trap Open funnel drain (after droplet separator) Open funnel drain (before droplet separator) High pressure water line Line drain valve Tab. 4.a humiFog Multizone Touch Oil-free +0300126EN rel.
- Page 9 Multizone Fig. 4.b Ref. Description Pumping station Ethernet cable Zone electrical panel Tab. 4.b Notice: for the Ethernet connection from the pumping station to the zone electrical panels, see “Installation notes”. humiFog Multizone Touch Oil-free +0300126EN rel. 1.2 - 05.11.2024 Introduction...
- Page 10 4.2.2 Room Notice: • do not install the blowers in niches, closed corridors or behind curtains, as this hinders uniform distribution of humidified air; • the air leaving the blowers is colder and more humid, and the noise levels of the nozzles and fans must be taken into consid- eration.
-
Page 11: Pumping Station
Power supply and approval Revision no. Customisation Pump type 250: 250 kg/h humiFog multi- 2: 230 Vac 50/60 Hz, 1~, UL 5: Fifth 0: Carel 4: Oil-free stainless humiFog zone Touch U: 208 Vac 50/60 Hz, 1~ UL revision steel 600: 600 kg/h... - Page 12 Qnom kW G20(nat.gas) G25(nat.gas) kg / h NOx cl Date CODE Serial No. Date Rev. Part No. MADE IN ... CAREL INDUSTRIES Via dell'Industria, 11, 35020 Brugine (Padova) Italy Fig. 4.i humiFog Multizone Touch Oil-free +0300126EN rel. 1.2 - 05.11.2024 Introduction...
- Page 13 CAUTION: tampering, removal or absence of the rating plate or anything else that does not allow certain identification of the product will make any installation or maintenance operations difficult and will void the manufacturer’s warranty. Structure 1 : 2 Fig. 4.j Ref.
-
Page 14: Blower Unit
4.9.2 In-room humidification directBOX hydraulic Water circuit assembly for interfacing the pumping station with the blowers for in-room humidification. It contains the solenoid valves for pressurising 1/2 water lines (zone/step). See technical leaflet +050001828. Fig. 4.l Ref. Description UAKDLASV10 directBOX hydraulic for managing 1 zone/step UAKDLASV20 directBOX hydraulic for managing 2 zones/steps Tab. -
Page 15: Droplet Separator
Manifolds with nozzles The distribution system is designed according to the specific application and comprising manifolds, solenoid valves, nozzles, pipes and fittings. Fig. 4.o 4.9.3 Ducted humidification Racks The distribution system is designed according to the specific application and comprising manifolds with nozzles and fixing frame in the duct, available in the fully- or partially-assembled versions. -
Page 16: Installation Notes
5. INSTALLATION NOTES Network connection See the technical data table for the specifications of the connection cables. 5.1.1 Zone panel connection The connection is made using an Ethernet cable from the pumping station to the zone panels, as shown in the figure. CAUTION: the maximum allowed length of an Ethernet connection between two devices is 100 m (for longer distanc- es, use switch P/N KITSE08000). -
Page 17: Distribution System
Distribution system 5.2.1 Drain valve management (NOL) The pumping station manages and controls the line drain valve (NOL, normally open). The zone panel can also manage a con- nected line drain valve. Notice: the line drain valve must be fitted at the lowest point in the water circuit and wired to the nearest electrical pan- el (pumping station or zone panel), so that when opened, the entire system is emptied. - Page 18 Functional diagrams - room CAUTION: the blower fill and drain valves are contained in the directbox hydraulic panel. The maximum allowable length for the water line leaving and re-entering the directbox or that, if no directbox is installed, connects the fill valve to the drain valve, is 1181 inches.
- Page 19 Case 3: 2 zones with 1 step Zone 1 Zone 2 Zona 1 Zona 2 Humidity Sensore Sensore Humidity sensor 1 di umidità 1 di umidità 2 sensor 2 Direct Box Direct Box Power supply Power supply Alimentazione Alimentazione Direct Box Direct Box Zone Zone...
-
Page 20: Water Connections
6. INSTALLATION Water connections 22.5 11.6 10.7 13.8 14.4 Fig. 6.a Model Water inlet (C) Water outlet (A) Drain (B) 3/4”G - F 1/2”G - F 1/4”G - F 3/4”G - F 1/2”G - F 1/4”G - F 3/4”G - F 1/2”G - F 1/4”G - F Tab. - Page 21 If, on the other hand, the humidifier is supplied with water from a Carel reverse osmosis system connected to the potable water supply network, the double check valve must be installed on the inlet to the reverse osmosis system.
-
Page 22: Electrical Connections
Electrical connections Before making the connections, make sure that the unit is disconnected from the power supply: turn the main system switch and pumping station switch to OFF. Install the cable glands on the left and right side of the electrical panel for the electrical cables to pass through. 6.3.1 Electrical panel Fig. -
Page 23: Control Connections
Control connections The type of control is selected on the user interface. See the humidification system commissioning manual. Notice: for all control connections: • cable sizes: 0.0005 to 0.0008 in² (AWG 22/20) up to 1181 inches • recommended cable size: 0.00124 to 0.002 in (AWG 18/16) >... -
Page 24: Alarm Output
6.6.2 Water leakage alarm input Water leakage alarm input, detected by the flood sensor. Connector Terminals Device WL - GOA Flood sensor (contact open/closed = alarm present/absent) Tab. 6.i Fig. 6.h 6.6.3 Alarm output The alarm output is activated when one or more alarms are detected. The contact/output can be relayed to a supervisory system. Relay electrical specifications Power 500 VA;... -
Page 25: Maintenance
For duct humidification, any biocides used for cleaning can only be added discontinuously. Based on its extensive experience in designing intrinsically-safe high-pressure systems that automatically prevent water stagnation, Carel strongly recommends against using biocides as a cleaning method for the humidifier components in contact with water, unless microbiological con- tamination has been proven. -
Page 26: Hygiene Measures
7.1.2 Hygiene measures Below is the list of preventive hygiene checks and their frequency, as required by the VDI 6022-1 guidelines and applicable to the humiFog system when used for duct humidification. Activity Action if necessary 1 month 3 months 6 months Check for damage due to contamination, microbial growth, or Clean and repair corrosion... -
Page 27: Pump Maintenance
CAREL in the manual supplied with the appliance. CAUTION: maintenance must be carried out on the pumping station at least once a year. - Page 28 Backup ring O-ring O-ring O-ring Shaft gasket Screw Seal ring O-ring Tab. 7.d Notice: For details on the disassembly and replacement operations, contact the service department at the reference Carel branch. humiFog Multizone Touch Oil-free +0300126EN rel. 1.2 - 05.11.2024 Maintenance...
- Page 29 Brief instructions for disassembling the pump: Fig. 7.k Fig. 7.m the spray bottle must be filled with water, preferably from reverse osmosis Fig. 7.l Fig. 7.n Fig. 7.o Fig. 7.q Fig. 7.p 7.4.2 Maintenance warning, reset hour counter When the pump has reached 8000h of operation, a warning is generated to notify that planned ordinary maintenance is re- quired, replacing the pump gaskets and pistons (as described in the previous paragraphs).
-
Page 30: Technical Data
8. TECHNICAL DATA Technical specifications UA2501250* - UA2501U50* UA6001250* - UA6001U50* UA1K31M50* ENVIRONMENTAL CONDITIONS Operating temperature (°F) 41 to 104°F Operating humidity (rH) 0 to 90% non-condensing Storage temperature (°F) 14 to 122°F Storage humidity (rH) 0 to 90% non-condensing Ingress protection IP20 WATER CIRCUIT DATA... - Page 31 9. CHECKLIST Final installation checklist 1. Installation site Temperature range 34 - 104 °F. Protected against rain and humidity. Protected against direct sunlight. 2. Water line All water connections fitted correctly. Materials compatible for use with water treated by reverse osmosis (stainless steel/plastic). Piping on pumping station feedwater line suitable for an operating pressure range of 2 to 5 bars.
- Page 32 10. ANNEXES Annex A: Wiring diagrams Single-phase power supply: UA250*-UA600* COND COND LEVEL +Vterm +5VREF +VDC ROEN PUMP IDC1 Fig. 10.a humiFog Multizone Touch Oil-free +0300126EN rel. 1.2 - 05.11.2024 ANNEXES...
- Page 33 Three-phase power supply: UA1K3* COND COND LEVEL Vterm +5VREF +VDC ROEN PUMP IDC1 Fig. 10.b humiFog Multizone Touch Oil-free +0300126EN rel. 1.2 - 05.11.2024 Checklist...
- Page 34 Annex B: Accessories and spare parts kits 1 Mechanical/electrical parts Fig. 10.c Description Ref. figure Qty. per humidifier UAKMWHP001 Pressure gauge, 0 to 100 bars UAKCV0HP01 Pressure control bypass valve, stainless steel UAKM220T60SP Electric motor for UA250*D5*4, 50-60 HZ UL UAKM300T63SP Electric motor for UA600*D5*4, 50-60 HZ UL UAKM400T63SP...
- Page 35 2 Water circuit parts Fig. 10.d Description Ref. figure Quantity per humidifier HSCONDUT00 Conductivity meter UAKHLP000SP Low-pressure fitting kit UA*****5*4/5 oil-free (contains charging solenoid valve kit code UGKEVOUT00SP) SPKT0011S0 Low pressure probe UAKSAFVAL0 Safety valve UAKCV0DR01SP Cabinet drain solenoid valve, stainless steel UAKTRAS05V 0-5 V high pressure probe UAKTS00000SP...
- Page 36 humiFog Multizone Touch Oil-free +0300126IT rel. 1.2 - 05.11.2024...
