Summary of Contents for Kemppi TTC 130

  • Page 1 130, 130F, 160, 160S, 200W, 220, 220S, 250W, 250WS Operating manual Käyttöohje Bruksanvisning Bruksanvisning Brugsanvisning Gebrauchsanweisung Gebruiksaanwijzing Manuel d’utilisation Инструкции по эксплуатации ttc_1927570_1736.indd 1 11.9.2017 13:54:49...
  • Page 2 ttc_1927570_1736.indd 2 11.9.2017 13:54:49...
  • Page 3 OPERATING MANUAL English ttc_1927570_1736.indd 1 11.9.2017 13:54:49...
  • Page 4: Table Of Contents

    Selection table for consumable parts TTC 130, TTC 130F, TTC 160S, TTC 200W, TTC 250WS ............
  • Page 5: Preface

    Kemppi. PRODUCT INTRODUCTION TTC 130, TTC 130F, TTC 160, TTC 160S, TTC 220, TTC 220S, TTC 200W, TTC 250W and TTC 250WS are TIG welding torches designed for demanding use. They are suitable to be used with the Mastertig MLS welding machines.
  • Page 6: Selection Table For Consumable Parts

    1.2.1 Selection table for consumable parts TTC 130, TTC 130F, TTC 160S, TTC 200W, TTC 250WS Normal gas nozzle equipment Welding current SP9878013 DC (A) AC (A) Size ø mm (in) WC20 9873531 9878018* 5 – 80 5 – 50 1,0 (.040) WZ8...
  • Page 7: Selection Table For Consumable Parts Ttc 160, Ttc 220, Ttc 220S, Ttc 250W

    1.2.2 Selection table for consumable parts TTC 160, TTC 220, TTC 220S, TTC 250W Normal gas nozzle equipment Welding current SP9580266 DC (A) AC (A) Size ø mm (in) WC20 9873531 5 – 80 5 – 50 1,0 (.040) 9873520 9876866 7990680 7990766...
  • Page 8: Operation Safety

    OPERATION SAFETY Please study these Operation safety instructions and respect them when installing, operating and servicing the machine. Welding arc and spatters Welding arc hurts unprotected eyes. Be careful also with reflecting arc flash. Welding arc and spatter burn unprotected skin. Use safety gloves and protective clothing. Danger for fire or explosion Pay attention to fire safety regulations.
  • Page 9: Adjustment Of Torch Body And Grips

    RTC 10 (code 6185477) Besides the start-switch there is a potentiometer for controlling the welding current. S = start U (clockwise) = welding current will slope-up D (anticlockwise) = welding current will slope-down RTC 20 (code 6185478) Besides the start-switch there is a seesaw switch for controlling the welding current. S = start U = welding current will slope-up D = welding current will slope-down...
  • Page 10: Choice Of Electrode Size And Flow Amount Of Shielding Gas

    You can without tools move or twist grips on the lower surface of the handle into such position you like that you can get a steady hold on the torch. You can also easily remove one or both of the grips through the front end of the handle. CHOICE OF ELECTRODE SIZE AND FLOW AMOUNT OF SHIELDING GAS Electrode size and shielding gas flow are defined by welding current level.
  • Page 11: Sharpening Of Electrode

    SHARPENING OF ELECTRODE 2.5.1 D.C. welding In D.C. welding the tip of electrode is sharpened into cone shape in order to get a steady arc and to concentrate heat energy on welding point. Size of sharpening angle has an effect on width of welding run and depth of penetration.
  • Page 12: Projection Of Electrode

    PROJECTION OF ELECTRODE Suitable distance of electrode tip from front edge of gas nozzle depends among others on electrode diameter and current type. Formation of weld preparation has a considerable effect on suitable electrode projection. E.g. when you are welding the external angle, you should use a clearly smaller projection than in fillet weld.
  • Page 13: Operation Disturbances

    • There is too much draught at welding place. • Note! With gas lens equipment you get a more balanced gas flow than with normal gas nozzle equipment. ORDERING NUMBERS 16 m TTC 130 627013004 627013008 627013016 TTC 130F 627013104...
  • Page 14: Technical Data

    TECHNICAL DATA Loading capacityDC- Electrode sizes Voltage Cooling Connection to TIG-unit to be used class Gas/current Water 40% ED 100% ED TTC 130 130A ø 1,0 – 2,4 R¼ TTC 130F 130A ø 1,0 – 2,4 R¼ TTC 160 160A ø...
  • Page 15 ttc_1927570_1736.indd 13 11.9.2017 13:54:51...
  • Page 16 78681 EPONE CEDEX myynti.fi@kemppi.com info.ru@kemppi.com FRANCE Tel +33 1 30 90 04 40 KEMPPI SVERIGE AB KEMPPI, TRADING (BEIJING) COMPANY, Telefax +33 1 30 90 04 45 LIMITED Box 717 sales.fr@kemppi.com Room 420, 3 Zone, Building B, S-194 27 UPPLANDS VÄSBY No.12 Hongda North Street,...
