- Page 1 SSEMBLY UIDE ICKSTAND ERSION Installation of the Kickstand for Gocycle G2, G3, GS...
-
Page 2: Table Of Contents
Assembly Guide: Kickstand For Frame Numbers >240000 ONTENTS Contents ......................i Overview ......................1 1. Gocycle Model Identification ................1 2. Kickstand Assembly Parts List ................1 Tool List ......................1 3. Kickstand Preparation ..................1 4. Kickstand Installation ..................2 5. -
Page 3: Overview
Assembly Guide: Kickstand For Frame Numbers >240000 VERVIEW This assembly guide details installation of the Kickstand for G2, G3 and GS Gocycles. If you have any questions, please contact techsupport@gocycle.com. 1. P ARTS Part Code Part Description Quantity KKL-6165-2358-02 Gocycle Kickstand... -
Page 4: Kickstand Installation
Assembly Guide: Kickstand For Frame Numbers >240000 2. K ICKSTAND NSTALLATION 2.1. Remove the rubber cover and M8 nut 2.2. Open the Kickstand carefully. Align the kickstand rubber. © Karbon Kinetics Limited. All Rights Reserved. - Page 5 Assembly Guide: Kickstand For Frame Numbers >240000 2.3. Attach the kickstand in the orientation shown. The legs close towards the front of the Gocycle. 2.4. Thread the M8 nut onto the screw © Karbon Kinetics Limited. All Rights Reserved.
- Page 6 Assembly Guide: Kickstand For Frame Numbers >240000 2.5. Use a 13mm spanner to tighten the nut to 20Nm. 2.6. Kickstand fitted correctly © Karbon Kinetics Limited. All Rights Reserved.
-
Page 7: Kickstand Adjustment
Assembly Guide: Kickstand For Frame Numbers >240000 3. K ICKSTAND DJUSTMENT If required, you can adjust the speed at which the Kickstand closes. Locate the bolts on the Kickstand main body. To slow the closure of the Kickstand, tighten each bolt independently.
