YORKVILLE EXCURSION EX1 Brochure

Features:
· 950 Watt Active Self Contained Loudspeaker System
· 15-inch Active Subwoofer
· 2 x Active 8-inch Woofer with 1-inch Tweeter
Satellite Speakers
· Available in both Black Ozite Carpet (EX1) and
Black Ultrathane (EX1B) painted finishes
45 to 19,000 Hz Frequency Response
·
XLR and 1/4-inch TRS balanced inputs connect easily to any mixer source
·
Solid plywood cabinet construction with Integrated bar handles and
·
standmount adaptors
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only
Overview:
The simple concept behind the élite EX1 was to create a powerful, effective and highly
mobile active stereo live PA / Club System centered around one 15-inch active subwoofer
and two active 8-inch / 1-inch bi-amplified satellite loudspeakers.
The core of the élite EX1 is the single 15-inch loaded subwoofer that houses the input section,
electronic crossover networks and five integrated power amplifier modules that power the
entire EX1 system.
The EX1 system delivers 950 watts total power. 650-watts is dedicated to the subwoofer,
and 150-watts to each of to the two satellite loudspeakers. To ensure system performance
and clarity, the satellite speakers are bi-amplified (125-watts to each 8-inch driver and
25-watts to each 1-inch horn).
The satellite speakers are connected to the subwoofer with two 8m Speakon™ four
connector speaker cables that are included with the package. The system is powered by
one AC line cord ensuring quick and convenient set-up and teardown, with a minimum of
cabling and connectivity around the stage. True to Yorkville loudspeaker design, all of the
cabinets in the élite EX1 are made with plywood, not MDF or composites.
The electronic crossover network ensures an acoustically perfect transition between the
subwoofer and the mid / high satellite speakers. Opto-limiter circuitry in the crossover
network provides an unobtrusive and 'musical sounding' compression that not only
protects the speaker components, but also ensures balanced and clear reproduction from
the satellite cabinets.
The entire system can be connected to any mono or stereo mixer source through either XLR
or 1/4-inch TRS balanced inputs.
To ensure trouble free movement from Point A to Point B, the EX1 comes shipped with a
detachable swivel caster dolly and Velcro™ tie down strap for the satellite cabinets. Unlike
competitive system solutions, the caster kit from the élite EX1 does not remain attached
to the subwoofer when the system is in use, eliminating caster buzz and rattle during live
performances.
The EX1 system is available in two finishes, including a rugged black Ozite carpet covering,
ideal for mobile PA and rental houses (EX1), or in a black painted finish (EX1B) more
suited to institutional or club system applications.
éXcursion EX1
éXcursion EX1
y o r k v i l l e . c o m
Active Self Contained Loudspeaker System
Active Self Contained Loudspeaker System
éXcursion Specifications:
MODEL EX1
SYSTEM TYPE Self Contained Loudspeaker System
ACTIVE OR PASSIVE Active
PROGRAM POWER (Watts) 2x 150 / 650
MAX SPL (dB) 118 / 124
FREQUENCY RESPONSE (Hz +/- 3db) 45 - 19,000
CROSSOVER FREQUENCY (Hz) 130 / 3000
DRIVER CONFIGURATION 2 x 1 x 8-inch / 1 x 15-inch
HF DRIVER(S) 1.4-inch Aluminum
HF PROGRAM POWER (Watts) 25
HF HORN ABS Custom Waveguide
HF DISPERSION (°H x °V) 100 x 25
HF PROTECTION Clip / Thermal / Short Circuit
MF DRIVER(S) 8-inch
MF PROGRAM POWER (Watts) 125
MF PROTECTION Clip / Thermal / Short Circuit
LF DRIVER(S) 15 inch (2.5-inch voicecoil)
SUBWOOFER PROGRAM POWER (Watts) 650
LF PROTECTION Clip / Thermal / Short Circuit
SATELLITE POWER AMPLIFIER (Watts) 25 x 2 (HF) / 125 x 2 (MF)
LF POWER AMPLIFIER (Watts) 650
INPUTS 2 x 1/4" Jacks / 2 x XLR
CONTROLS Subwoofer level control / Left and Right satellite level controls
HARDWARE Wheels (Dolly Board) , Bar Handles, Pole Mount Adapter
ENCLOSURE MATERIALS 15mm 11-ply birch, Perforated Metal Grille
COVERING / FINISH Black Ozite carpet (EX1), Black Painted (EX1B)
SATELLITE SPEAKERS (WxHxD in/cm) 8.5x10.75x15.5 / 21.5x27.3x39.4
17.7lbs / 8.1kgs
SUBWOOFER (WxHxD in/cm) 21.5x17.25x22.25 / 54.6x43.8x56.5
81.2lbs / 36.8kgs
