SERVICE MANUAL
MODEL TYPE: YS1043
éXcursion1000
(EX1)
WEB ACCESS: http://www.yorkville.com
WORLD HEADQUARTERS
CANADA
U.S.A.
Yorkville Sound
Yorkville Sound Inc.
550 Granite Court
4625 Witmer Industrial Estate
Pickering, Ontario
Niagara Falls, New York
L1W-3Y8 CANADA
14305 USA
Voice: (905) 837-8481
Voice: (716) 297-2920
Fax: (905) 837-8746
Fax: (716) 297-3689
Quality and Innovation Since 1963
Printed in Canada
Manual-Service-ex1-00-1v5.pdf

Advertisement

loading
Need help?

Need help?

Do you have a question about the eXcursion1000 and is the answer not in the manual?

Questions and answers

Related Manuals for YORKVILLE eXcursion1000

Summary of Contents for YORKVILLE eXcursion1000

  • Page 1 SERVICE MANUAL MODEL TYPE: YS1043 éXcursion1000 (EX1) WEB ACCESS: http://www.yorkville.com WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance.
  • Page 3 EX1 Parts List 6/8/2010 YS # Description Qty. YS # Description Qty. YS # Description Qty. YS # Description Qty. 5906 RED 3MM LED 1V9 20MA.4SPCER T&R 8570 CORNER,2 LEGS NOTCED BLACK POWDER C 4823 1/4W 1K T&R RES 8773 10-32 X 1 1/4 PN PH TT FULL THD JS5 5907 YEL 3MM LED 1V9 20MA.4SPCER T&R 8592 3X1 1/4 SWIVEL CASTER...
  • Page 4 B l o c k D i a g r a m for E X 1 - Page 1 of 2 D E S I G N E D A N D M A N U F A C T U R E D B Y Y O R K V I L L E S O U N D POWER TO SATELLITE -6dB @ 3kHz...
  • Page 5 B l o c k D i a g r a m for E X 1 - Page 2 of 2 D E S I G N E D A N D M A N U F A C T U R E D B Y Y O R K V I L L E S O U N D SHUT LEFT MUTE FET SENSE...
  • Page 6 1/4W 1N4740A SAT.HORN 10V0 INVERT OR NOT 1/4W **** NOTE **** TO INVERT 4148 SIGNAL TIP142 WHEN ADJUSTING BIAS 150P 1/4W 1/4W U7:B R123 750R R405 CLOCK WISE LOWERS 1/4W U7:A 100V U7:C 1/4W 1/4W R100 6902 4148 470R BIAS FUSIBLE TO218 NE5532N...
  • Page 7 R324 1/4W 1N4740A INVERT OR NOT 10V0 SAT.HORN TO INVERT R385 **** NOTE **** 1/4W 4148 R379 R362 150P TIP142 R394 WHEN ADJUSTING BIAS 1/4W 1/4W U17:A SIGNAL R286 C146 C161 750R R386 R409 CLOCK WISE LOWERS D125 1/4W U17:B 100V U17:C 1/4W...
  • Page 8 W1:A W1:B W1:C U33:B 100N W1:D C125 100N 100N 100N 100N 100V SUB HEADER FOR RIBBON CABLE FROM INPUT PCB R255 R252 R253 R254 C195 C134 C141 C138 NE5532N W1:E 100K 100N 100N 100V 100V 100V 100V 4148 4148 4148 MINI C155 W1:F...
  • Page 9 PCBSA: BRASS PINS PCBSA: BRASS PINS LEFT WOOFER AMP SUB WOOFER AMP LEFT HORN AMP Z678 8787 C190 470N TO218 100N 270K 6853 6853 6891 6953 6953 6953 6891 6853 R381 C189 MPSA63 IRFZ44R IRFZ44R TIP50 IRF4905 IRF4905 IRF4905 TIP50 IRFZ44R TIP142 TIP142...
  • Page 10 SEE LAYOUT DIAGRAM M1213 EX1 PRODUCTION NOTES 1. P.C.B.S.A.: INSERT VIOLET AND BLUE WIRE JUMPERS INTO EYELETS W17 TO W18 AND W15 TO W16. 8. PC# 7494, PUT NUTS ON TOP 2. P.C.B.S.A.: #8761 & #8760 SCREW AND NUT TO ALIGN HEAT SPREADER X 6. 3.

  • Page 11: Pin Configuration

    SEE LAYOUT DIAGRAM M1213 Database History MODEL(S):- DATE VER# DESCRIPTION OF CHANGE MAY-20-2005 V1.00 MAIDEN VOYAGE 30 June, 2005 . Added routing at HS nuts for marconi jig PIN CONFIGURATION SEP-02-2005 V1.10 PC#6959:GT:REMOVED W10,W11,W12,W13 CHANGED #6853,6891,6953 XISTORS TO NO MTGHOLES NOV-03-2005 GT:REPLACED HOLE_189 TO 8787 HEXNUT PARTS AS PER WIRING MODEL, 11 LOCATIONS NOT INCL.
  • Page 12 R373 R303 N129 U19:A 1/4W 1/4W 470R LEFT LIMITER R366 R329 R348 N224 C183 C180 N274 U22:B 1/4W 1/4W 1/4W R403 R404 680N 680N C168 N232 C169 N234 N131 NE5532N 1K07 9K76 7K96 1/4W 1/4W N149 R378 0.1% 0.1% 0.1% 100N 100V 100N...
  • Page 13 R210 1/4W FUSIBLE R211 1/4W FUSIBLE {Function} MJF6388 R263 1/4W R274 UF4004 R255 6815 4148 R258 910R R267 470K 10K0 MINI T221D R264 1/4W MINI MINI 470K MINI UF4004 MINI R270 R271 100U U29:B 151R 151R R259 C108 1N4750A FUSIBLE FUSIBLE 14K0 W20:A...
  • Page 14 R257 BRN=120V&230V RIGHT SATELLITE LEFT SATELLITE LINE_IN 20K0 100N C165 ORG=245V 4056 C110 R273 3819 C171 Hole for Cable SPEAKON 4C SPEAKON 4C EMPTY=120V 2N5401 BLU=230&245V TL072 BLK=120V EMPTY=230V&245V BLU=120V R267 2N5401 WHT FROM 470K TRANSFORMER R265 R255 D83 R269 C113 BLK=230&245V NL4MP-1...
  • Page 15 SEE LAYOUT DIAGRAM M1214.PCB_DATABASE_HISTORY MODEL(S):- M1214 PRODUCTION NOTES: DATE VER# DESCRIPTION OF CHANGE JUN-23-2005 1V0 FIRST RELEASE AUG-15-2005 1V1 PC#6950:GT:ROUTING INCREASED IN CORNER, ADD 1. DO NOT BREAK THE BOARD BEFORE TESTING. HOLE TO UPPER RIGHT CORNER SEP-01-2005 PC#6950:GT:CHANGED HOLE140'S TO HOLE156'S PC#6957:GT:C66&C134 #5208 2N2->#5204 10N, R144&R330 #4813 6R2->#2009 10R JUN-26-2006 1V20...
  • Page 16 R257 RIGHT SATELLITE LEFT SATELLITE LINE_IN BRN=120V&230V 20K0 100N C165 ORG=245V C110 R273 C171 Hole for Cable SPEAKON 4C SPEAKON 4C EMPTY=120V 2N5401 BLU=230&245V TL072 BLK=120V EMPTY=230V&245V BLU=120V R267 2N5401 WHT FROM 470K TRANSFORMER R265 R255 D83 R269 C113 BLK=230&245V NL4MP-1 C114 C112...
  • Page 17 Black 12" CIR. BRK. Black 5" White 3.5" White 12" Black 4" CH13338U EX 1 TRANSFORMER WIRED FOR EURO-245V 245 V- CONNECTIONS ----------------------------------- ORG--------W13 BLU---------W17 BRN---------W12 BLK---------W16 WHT--------W15 YEL/BLK---W11...
  • Page 18 Black 12" CIR. BRK. Black 5" White 3.5" White 12" Black 4" CH13338U EX 1 TRANSFORMER WIRED FOR CE-230V 230 V- CONNECTIONS ----------------------------------- ORG--------W12 BLU---------W17 BRN---------W13 BLK---------W16 WHT--------W15 YEL/BLK---W11...
  • Page 19 Black 12" CIR. BRK. Black 5" White 3.5" White 12" Black 4" CH13338U EX 1 TRANSFORMER WIRED FOR N. A 120V CONNECTIONS ----------------------------- ORG--------------W12 BRN---------------W13 BLK----------------W14 BLU----------------W16 WHT---------------W15 YEL/BLK-----------W11...
  • Page 20 TRANSFORMER SECONDARY CONNECTIONS EX 1 Black 12" CIR. BRK. Black 5" White 3.5" White 12" Black 4" CH13338U...

  • Page 21: Subwoofer Level
