YORKVILLE COLISEUM C2890 Brochure

Features:

· 200 Watt Passive Loudspeaker Cabinet
· Rotatable 90° x 30° Horn Assembly
· 2 x 8-inch Woofer with 1-inch Horn
Can Be Flown Vertically or Horizontally
·
15mm 11-ply Birch Cabinet Construction
·
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only

Overview:

The C2890 is the lowest profile cabinet in the Coliseum line. This 2 x 8-inch / 1-inch horn, 200-
watt loudspeaker is designed as the ultimate box for installations where sight lines might be an
issue. The C2890 can be flown vertically or horizontally. The rotatable 90° x 30° horn means
that high frequency dispersion can be tailored to suit the cabinet's placement. The unique
cabinet shape makes for tighter arrays and the ability to fly the cabinet much closer to walls
and ceilings than conventional design loudspeaker boxes. Optional C2890BRKT mounting
bracket (shown below) maximizes installation options in one simple mounting solution.
Coliseum C2890
Coliseum C2890
y o r k v i l l e . c o m
2 x 8-inch Passive Loudspeaker Cabinet 2 x 8-inch Passive Loudspeaker Cabinet

C2890 Specifications:

Model C2890
SYSTEM TYPE Passive 2-Way
PROGRAM POWER (watts) 200
IMPEDANCE (ohms) 8
FREQ. RESPONSE (Hz +/-3dB) 65 - 16k
SENSITIVITY (dB@1W/1m) 97
MAXIMUM SPL (dB) 120
X-OVER FREQUENCY (Hz) 2500
LF DRIVER(S) 2 x 8"
HF HORN Rotatable Waveguide
HF DRIVER 1" Mylar
HF HORN THROAT DIAMETER 1"
HF DISPERSION (H˚ x V˚) 90 x 30 / 30 x 90
HF PROTECTION CTL™
CONSTRUCTION 15mm 11-ply Birch
STOCK FINISH White Painted
GRILLE Perforated Metal
INPUTS (1/4" / Binding Post) 2 / 1 pair
FLYWARE TYPE / QUANTITY 3/8" x 9
FLYWARE LOCATIONS All Corners / 1 Pull Back
OPTIONAL ACCESSORIES C2890BRKT
15 x 12 x 29 x 6
DIMENSIONS (DxWxHxBW inches)
DIMENSIONS (DxWxHxBW cm) 36 x 29 x 73 x 15
WEIGHT (lbs / kg) 42 / 19.1
