YORKVILLE COLISEUM C2560 Brochure

Features:
· 300 Watt Passive Loudspeaker Cabinet
· 60° x 40° Waveguide Horn Assembly
· 15-inch Woofer with 1-inch Voicecoil
· 2-inch Titanium Diaphragm
Inset input-jack plates
·
Binding Post and 1/4" Phone Connectors
·
9 Fly Points and a Pullback
·
15mm 11-ply Birch Cabinet Construction
·
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only
Overview:
The high power 300 Watt C2560 contains a single 15" speaker and horn. Each enclosure
features a 2" titanium diaphragm, high frequency driver firing through a 1" exit hole to a
60ºx40º waveguide horn for unsurpassed sonic clarity. Time-tested passive crossover
networks (12 dB per octave) ensure sonic accuracy.
In the lower frequency range the higher power woofer combines solid performance with
outstanding reliability. The enclosures feature inset input-jack plates, which contain binding
post and 1/4" phone connectors. The enclosures are painted with a white two-part epoxy
and incorporate curved, anti-resonance speaker grille constructed of perforated 16-gauge
steel. Both enclosure and grille can be easily refinished and feature a grille clip attachment
system for easy removal and recovering. Painstaking attention to details is evidenced by
features such as the safety screw hidden under the embossed Yorkville logo, which ensures
that the grille does not inadvertently come loose.
The Coliseum series enclosures are constructed of highly rigid 15mm (.5906") Baltic birch
plywood. Their trapezoidal shape is conducive to array mounting and minimizes lobing
difficulties. The C2560 is equipped with four flypoints and a pullback. The flypoints are steel
reinforced and engineered to allow easy, flexible and safe enclosure suspension.
Coliseum C2560
Coliseum C2560
y o r k v i l l e . c o m
15-inch Passive Loudspeaker Cabinet 15-inch Passive Loudspeaker Cabinet
C2560 Specifications:
Model C2560
SYSTEM TYPE Passive 2-Way
PROGRAM POWER (watts) 300
IMPEDANCE (ohms) 8
FREQ. RESPONSE (Hz +/-3dB) 60 - 16k
SENSITIVITY (dB@1W/1m) 100
MAXIMUM SPL (dB) 125
X-OVER FREQUENCY (Hz) 1200
LF DRIVER(S) 15"
HF HORN Waveguide
HF DRIVER 2" Titanium
HF HORN THROAT DIAMETER 1"
HF DISPERSION (H˚ x V˚) 60 x 40
HF PROTECTION CTL™
CONSTRUCTION 15mm 11-ply Birch
STOCK FINISH White Painted
GRILLE Perforated Metal
INPUTS (1/4" / Binding Post) 2 / 1 pair
FLYWARE TYPE / QUANTITY 3/8" x 9
FLYWARE LOCATIONS All Corners / 1 Pull Back
OPTIONAL ACCESSORIES -
DIMENSIONS (DxWxHxBW inches) 20 x 21 x 27 x 12
DIMENSIONS (DxWxHxBW cm) 52 x 54 x 68 x 32
WEIGHT (lbs / kg) 71 / 31.8
